DN Solutions DNM 5AX 500

Est. $200,000 - $320,000 Updated 2026-08-10

Key Specifications

X Travel

550 mm (21.7 in)

Y Travel

510 mm (20.1 in)

Z Travel

500 mm (19.7 in)

Max Spindle

12,000 RPM (15,000 RPM optional)

Spindle Taper

BBT 40 (BIG PLUS CAT 40)

Tool Capacity

30 (40/60 optional)

Overview

The DN Solutions DNM 5AX 500 is a compact simultaneous 5-axis machining center built on a trunnion-table configuration with a 500 mm (19.7 in) diameter rotary table. Positioned between the smaller DNM 350 5AX and the larger DVF series, the DNM 5AX 500 offers a practical 5-axis work envelope for medium-sized parts in aerospace, medical, and general precision machining applications. The machine evolved from Doosan's established DNM platform, inheriting the series' reputation for reliability and value.

Axis travel runs 550 x 510 x 500 mm (21.7 x 20.1 x 19.7 in) on X/Y/Z, with the B-axis tilting from -30 to +120 degrees and the C-axis rotating a full 360 degrees continuously. The 500 mm table handles workpieces up to approximately 500 mm diameter and 350 kg (772 lb), covering typical 5-axis part sizes for medical implants, aerospace brackets, turbocharger housings, and complex fixtures. The trunnion-table design keeps the spindle vertical and stationary on the rotary axes, which simplifies programming and provides consistent chip evacuation.

The standard spindle turns at 12,000 RPM with 117 Nm (86 ft-lb) of torque through a BBT 40 (BIG PLUS CAT 40) taper, delivering 18.5 kW (25 hp) of cutting power. An optional 15,000 RPM spindle is available for higher-speed aluminum and composite work. The 30-tool magazine handles most 5-axis jobs, with an optional 40 or 60-tool upgrade for production environments. Tool-to-tool change time is approximately 1.5 seconds.

Rapid traverse hits 36 m/min (1,417 ipm) on X/Y and 30 m/min (1,181 ipm) on Z. At 9,500 kg (20,944 lb), the DNM 5AX 500 is a mid-weight machine that doesn't demand extreme foundation work. The compact footprint of approximately 3,400 x 3,200 x 3,200 mm (134 x 126 x 126 in) fits into most shop layouts. The FANUC 31iB5 control comes standard with 5-axis kinematic functions and RTCP. The DNM 5AX 500 competes with the Haas UMC-500, Mazak VARIAXIS C-600, and Matsuura MX-520 in the compact 5-axis trunnion-table segment.

Full Specifications

Parameter	Value
X-Axis Travel	550 mm (21.7 in)
Y-Axis Travel	510 mm (20.1 in)
Z-Axis Travel	500 mm (19.7 in)
B Axis Range	-30° to +120°
C Axis Range	360° (continuous)
Max Spindle Speed	12,000 RPM (15,000 RPM optional)
Spindle Taper	BBT 40 (BIG PLUS CAT 40)
Spindle Torque	117 Nm (86 ft-lb)
Spindle Motor Power	18.5 kW (25 hp)
Tool Capacity	30 (40/60 optional)
Table Diameter	500 mm (19.7 in)
Max Workpiece Diameter	500 mm (19.7 in)
Table Load Capacity	350 kg (772 lb)
Rapid Traverse Xy	36 m/min (1,417 ipm)
Rapid Traverse Z	30 m/min (1,181 ipm)
Tool Change Time	1.5 sec (tool-to-tool)
Machine Dimensions	3,400 x 3,200 x 3,200 mm (134 x 126 x 126 in)
Machine Weight	9,500 kg (20,944 lb)
CNC Control	FANUC 31iB5
Max Spindle Speed	42000r/min
X Axis Travel Distance	200mm
Y Axis Travel Distance	340mm
Metric	IMPERIAL

Specifications sourced from dn-solutions.com — verified 2026-03-28

Strengths & Limitations

Strengths

Compact 500 mm trunnion-table 5-axis at a competitive price point, delivering accessible simultaneous 5-axis capability for mid-size shops
Proven DNM platform lineage provides established reliability, parts availability, and dealer support network
12,000 RPM / 117 Nm spindle offers a solid balance of speed and torque for mixed-material 5-axis work in aluminum, steel, and titanium
36 m/min rapid traverse on X/Y keeps non-cutting time low for production 5-axis cycle times
FANUC 31iB5 control with standard RTCP simplifies 5-axis programming and provides broad CAM compatibility

Limitations

550 mm X-travel and 500 mm Z-travel are compact — larger 5-axis parts need the DVF 5000 or DVF 8000
350 kg table load limits workpiece weight compared to the DVF 5000's 400 kg capacity
Standard 30-tool magazine fills quickly on complex 5-axis jobs — the 60-tool upgrade is recommended for production work
BBT 40 taper limits heavy roughing torque compared to HSK-A63 machines in titanium and hardened steel applications

Best For

Medical device manufacturers producing orthopedic implants, surgical instruments, and dental prosthetics in 5-axis Aerospace job shops machining brackets, fittings, and turbine components under 500 mm diameter General precision shops adding first 5-axis capability on a proven, cost-effective platform Automotive prototype and motorsport shops producing complex fixtures, intake manifolds, and turbocharger housings

Frequently Asked Questions

01 What does a DN Solutions DNM 5AX 500 cost?

DN Solutions quotes through its distributor network per configuration. On the DNM 5AX 500 the main variables are the spindle (12,000 RPM standard or 15,000 RPM optional), magazine size (30 standard, 40 or 60 optional), probing, and through-spindle coolant — with a 500 mm trunnion table, probing is close to essential for setting work offsets. It sits between the Haas UMC-500, which is less expensive and less capable, and DN Solutions' own DVF 5000, which is the more capable machine, so getting all three quoted with your real option list is the useful comparison. Tooling, fixturing and installation for a 9,500 kg machine are separate.

02 How does the DNM 5AX 500 compare to the DVF 5000?

The DVF 5000 is the step-up machine with a traveling-column design, larger travel (625x450x400 vs 550x510x500 mm), faster 18,000 RPM spindle, quicker tool changes (1.3 vs 1.5 sec), and three control options (Fanuc/Heidenhain/Siemens). The DNM 5AX 500 costs less and has a slightly larger Z-travel (500 vs 400 mm) and wider B-axis tilt range (-30/+120° vs -30/+110°). For budget-conscious shops that don't need the DVF's speed advantages, the DNM 5AX 500 is a capable alternative.

03 Can the DNM 5AX 500 handle titanium?

The 12,000 RPM spindle with 117 Nm torque and BBT 40 taper handles titanium for moderate cuts and finishing passes. For serious titanium roughing, the machine's torque is adequate but the BBT 40 taper is a limitation compared to HSK-A63 machines. For titanium-heavy work, consider the DVF 5000 with the optional 12,000 RPM / 230 Nm high-torque spindle.
