DMG Mori DMF 500 Gantry
Key Specifications
X axis travel mm
Y axis travel mm
Z axis travel mm
table size mm
max table load kg
spindle speed rpm
Overview
The DMG Mori DMF 500 Gantry is a large-format vertical machining center designed for heavy-duty cutting of oversized workpieces in aerospace, energy, and rail industries. With 5,000 mm of X-axis travel and a robust gantry structure, the machine provides a stable, thermally symmetrical platform capable of maintaining precision across extended machining cycles on parts that exceed the capacity of conventional VMCs.
The gantry design distributes structural loads evenly across dual Y-axis drives, minimizing deflection and ensuring consistent surface quality over the full working envelope. High-torque spindle options — including a fork-type swivel head for full five-axis interpolation — make the DMF 500 Gantry equally at home on structural aluminum milling and hard-metal roughing operations.
A generously proportioned working table supports workpiece loads of up to 8,000 kg, and the machine's modular configuration allows customers to specify table length, spindle type, and automation interfaces to match their production environment. Chip management is handled by high-capacity conveyors integrated into the machine base, keeping the work zone clear during long unattended runs.
The CELOS control platform provides a unified digital interface for NC programming, tool management, and condition monitoring, ensuring the DMF 500 Gantry can be integrated into connected manufacturing environments with minimal integration effort.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel Mm | 5000 |
| Y Axis Travel Mm | 1500 |
| Z Axis Travel Mm | 1000 |
| Table Size Mm | 5000 × 1500 |
| Max Table Load Kg | 8000 |
| Spindle Speed Rpm | 12000 |
| Spindle Power KW | 52 |
| Spindle Torque Nm | 430 |
| Rapid Traverse M Min | 60 |
| Tool Storage Capacity | 60 |
| Max Tool Diameter Mm | 160 |
| Max Tool Length Mm | 500 |
| Max Tool Weight Kg | 15 |
| Positioning Accuracy Mm | 0.008 |
| Repeatability Mm | 0.005 |
| Drive Type | Ballscrew with dual Y-axis drives |
| CNC Control | Siemens 840D sl / Heidenhain TNC 640 |
| Machine Weight Kg | 55000 |
| 13 In | 340 mm |
| 47 In | 1,185 mm |
| 4 In | 102 mm |
| 19 In | 490 mm |
| 8 In | 200 mm |
| Details | Strongest version for 210 kg payloadFree accessibility to the machine and the automationStrongest version for 210 kg payloadFree accessibility to the machine and the automation |
| Strongest Version For 210 Kg Payloadfree Accessibility To The Machine And The Automation | Strongest version for 210 kg payloadFree accessibility to the machine and the automation |
| Strongest Version For 210 Kg Payload | Free accessibility to the machine and the automation |
| Procedure | User Interface |
| Customer Benefits | MPC Graph: current and learned process values. / MPC Diagnostics: stock condition, number of impact and crash. |
Specifications sourced from no.dmgmori.com — verified 2026-03-28
Strengths & Limitations
Strengths
- 5,000 mm X-axis travel handles the largest structural aerospace and energy components
- Dual Y-axis gantry drives minimize deflection for consistent precision across the full envelope
- High-torque spindle options support both aluminum structural milling and steel roughing
- Modular configuration allows customization of table length and spindle type
Limitations
- Very high capital investment; primarily justifiable for dedicated large-part production
- Requires substantial floor space, reinforced foundations, and overhead crane access
- Long lead times typical for configured gantry machines
Best For
Frequently Asked Questions
01
The DMF 500 Gantry is available with multiple spindle configurations including high-speed motor spindles and fork-type swivel heads that enable full five-axis interpolation, making it suitable for both three-axis production work and complex five-axis aerospace parts.
02
The gantry design uses dual Y-axis drives that distribute structural loads symmetrically, reducing cantilevered deflection. This results in more consistent positioning accuracy and surface finish across the full 5,000 mm working length compared to a single-column traveling-column design.
03
Yes. DMG Mori offers automation interfaces for pallet systems and workpiece handling equipment. The machine's CELOS control supports integration with factory-level MES and ERP systems for scheduling, condition monitoring, and production reporting.
