Yawei PBG-220/3100
Key Specifications
bending force
bending length
distance between columns
throat depth
ram stroke
die setting height
How much does the Yawei PBG-220/3100 cost?
Price estimate
We do not have a price for the Yawei PBG-220/3100 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Yawei PBG-220/3100 is the short-bed, high-force model of the PBG dual servo series. It delivers 2,200 kN over 3,100 mm (122.0 in), and it is the size at which the PBG drive gets larger.
Main motor power becomes 2 x 11 kW and the oil tank volume 2 x 80 L; the PBG-160/3100 uses 2 x 7.9 kW. Slider speeds come down to 180 mm/s; 15 mm/s; 180 mm/s. Even so, the first figure is above the 160 mm/s that the conventional PBC-220/3100 lists in the same position.
Weight is 10,800 kg (23,810 lb) and the overall dimensions are 3,710 x 1,750 x 2,850 mm (146.1 x 68.9 x 112.2 in). Among Yawei's 2,200 kN three-metre brakes it is one of the lightest: the PBC-220/3100 weighs 12,300 kg (27,116 lb) and the hybrid PBM-220/3100 13,000 kg (28,660 lb).
Before choosing it for heavy work, look at the open height. Stroke is 215 mm (8.5 in) and mould height 550 mm (21.7 in). Thick plate needs wide dies, which are tall, and the part needs room to come out. The PBC-220/3100 lists 265 mm (10.4 in) of slider travel and 600 mm (23.6 in) of mould height. Throat depth is 410 mm (16.1 in), with 2,600 mm (102.4 in) between columns.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Force | 2,200 kN |
| Bending Length | 3,100 mm (122.0 in) |
| Distance Between Columns | 2,600 mm (102.4 in) |
| Throat Depth | 410 mm (16.1 in) |
| Ram Stroke | 215 mm (8.5 in) |
| Die Setting Height | 550 mm (21.7 in) |
| Ram Speed | 180 mm/s; 15 mm/s; 180 mm/s |
| Main Motor Power | 2 x 11 kW |
| Oil Tank Volume | 2 x 80 L |
| Machine Dimensions | 3,710 x 1,750 x 2,850 mm (146.1 x 68.9 x 112.2 in) |
| Machine Weight | 10,800 kg (23,810 lb) |
Specifications sourced from en.yawei.cc — verified 2026-10-05
Strengths & Limitations
Strengths
- 2,200 kN from a 2 x 11 kW dual servo drive
- First speed position of 180 mm/s, above the 160 mm/s of the PBC-220/3100
- Light for a 2,200 kN three-metre brake at 10,800 kg (23,810 lb)
- Oil tank volume of 2 x 80 L
- Pressure control that Yawei says improves stability and saves energy
Limitations
- Stroke of 215 mm (8.5 in) is short for thick-plate tooling
- Mould height of 550 mm (21.7 in); the PBC-220/3100 lists 600 mm (23.6 in)
- Slower than the PBG-160/3100, which lists 220 mm/s first
- Crowning is not mentioned on the PBG page
Best For
Frequently Asked Questions
01
Dual servo motors with dual oil pumps. Main motor power is 2 x 11 kW and oil tank volume is 2 x 80 L. Yawei credits the design with fast speed and high efficiency.
02
Pressure and length match. The PBG-220/3100 lists 180 mm/s; 15 mm/s; 180 mm/s, a 215 mm (8.5 in) stroke and 10,800 kg (23,810 lb). The PBC-220/3100 lists 160 mm/s; 14 mm/s; 160 mm/s, 265 mm (10.4 in) and 12,300 kg (27,116 lb).
03
Distance between columns 2,600 mm (102.4 in), throat depth 410 mm (16.1 in), slider stroke 215 mm (8.5 in) and mould height 550 mm (21.7 in).
04
Overall dimensions are 3,710 x 1,750 x 2,850 mm (146.1 x 68.9 x 112.2 in) (length, width, height). Machine weight is 10,800 kg (23,810 lb).
