Yawei PBG-110/4100 Curtain wall
Key Specifications
bending force
bending length
distance between columns
throat depth
ram stroke
die setting height
How much does the Yawei PBG-110/4100 Curtain wall cost?
Price estimate
We do not have a price for the Yawei PBG-110/4100 Curtain wall that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Yawei PBG-110/4100 Curtain wall is a dual servo press brake adapted for architectural panels. It has 1,100 kN of bending pressure over 4,100 mm (161.4 in), and its throat depth is 550 mm (21.7 in), where the standard PBG-110/3100 has 410 mm (16.1 in).
Throat depth is the dimension that curtain wall work uses up. Cladding cassettes are wide, shallow trays with return flanges on all four sides. To fold the long sides of a panel longer than the gap between the columns, the sheet has to pass back into the throat, and a deeper throat means a wider panel can be handled.
The mould height is raised as well, to 630 mm (24.8 in), which gives room for the tall gooseneck tools that return flanges need. Stroke is 215 mm (8.5 in). Distance between columns is 3,600 mm (141.7 in).
In drive and speed this is the 1,100 kN PBG: 2 x 7.9 kW, 2 x 60 L of oil and slider speeds of 220 mm/s; 18 mm/s; 200 mm/s. Weight is 8,800 kg (19,400 lb) and the overall size 4,670 x 1,700 x 2,780 mm (183.9 x 66.9 x 109.4 in). Yawei lists the metal curtain wall industry among the applications of the series, and names the two curtain wall versions as separate columns of its table. Aluminium composite and solid aluminium sheet bend at low force, so the pressure is ample for the purpose.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Force | 1,100 kN |
| Bending Length | 4,100 mm (161.4 in) |
| Distance Between Columns | 3,600 mm (141.7 in) |
| Throat Depth | 550 mm (21.7 in) |
| Ram Stroke | 215 mm (8.5 in) |
| Die Setting Height | 630 mm (24.8 in) |
| Ram Speed | 220 mm/s; 18 mm/s; 200 mm/s |
| Main Motor Power | 2 x 7.9 kW |
| Oil Tank Volume | 2 x 60 L |
| Machine Dimensions | 4,670 x 1,700 x 2,780 mm (183.9 x 66.9 x 109.4 in) |
| Machine Weight | 8,800 kg (19,400 lb) |
Specifications sourced from en.yawei.cc — verified 2026-10-05
Strengths & Limitations
Strengths
- Throat depth of 550 mm (21.7 in), deeper than the standard PBG models
- Mould height of 630 mm (24.8 in) for tall return-flange tooling
- 4,100 mm (161.4 in) bending length at 1,100 kN
- Dual servo drive, 2 x 7.9 kW, with 2 x 60 L of oil
- Slider speeds of 220 mm/s; 18 mm/s; 200 mm/s
Limitations
- 1,100 kN only: not a plate machine
- Stroke remains 215 mm (8.5 in)
- Panels longer than 4,100 mm need the PBG-110/4500 Curtain wall
- The page does not describe the special equipment beyond the frame figures
Best For
Frequently Asked Questions
01
The frame. Throat depth is 550 mm (21.7 in) and mould height 630 mm (24.8 in); the standard PBG-110/3100 lists 410 mm (16.1 in) and 550 mm (21.7 in). Drive, stroke and slider speeds are the same.
02
Bending pressure is 1,100 kN and bending length is 4,100 mm (161.4 in). Distance between columns is 3,600 mm (141.7 in).
03
Machine weight is 8,800 kg (19,400 lb). Overall dimensions are 4,670 x 1,700 x 2,780 mm (183.9 x 66.9 x 109.4 in) as length, width and height.
04
The PBG dual servo drive: main motor power of 2 x 7.9 kW and an oil tank volume of 2 x 60 L, with slider speeds of 220 mm/s; 18 mm/s; 200 mm/s.
