Vision Wide MHN-6040 / MHN-6047
Image: visionwide-tech.com, Vision Wide
Key Specifications
Table Size
x axis travel
y axis travel
z axis travel box way single ballscrew
z axis travel linear way enclosed box ram dual ballscrews
max table load
How much does the Vision Wide MHN-6040 / MHN-6047 cost?
Price estimate
We do not have a price for the Vision Wide MHN-6040 / MHN-6047 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The option list of the Vision Wide MHN-6040 / MHN-6047 is short, and three of its items change the machine's role. They are an auto measurement system, a rotary table and XYZ-axis linear scale feedback.
The base machine is a very large three-axis mill with attachment-head capability. X travel is 6,100 mm (240.2 in), Y travel 4,000 mm (157.5 in) or 4,700 mm (185.0 in), and the 6,000×3,500 mm (236.2×137.8 in) table carries 28,000 kg (61,728 lb). No tool magazine is listed.
With scales, it becomes a machine that can hold position over those distances regardless of screw temperature. With measurement, it can find a rough casting on the table and set its own datums, the task that otherwise takes the longest on parts this size. With a rotary table, it can index a part and mill its faces in turn, which is a reasonable substitute for five-face heads on parts that fit the table.
None of the three is described beyond its name on the page.
Standard equipment covers the cutting basics: a box way 4,000rpm 2-step gear type spindle with 22/26 kW (29.5/34.9 hp), spindle and cutting fluid cooling, and chip conveyors. X/Y rapid is 8 m/min.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 6,100 mm (240.2 in) |
| Y Axis Travel | 4,000/ 4,700 mm (157.5/ 185.0 in) |
| Z Axis Travel Box Way Single Ballscrew | 920 / 1,020 mm (36.2 / 40.2 in)(Opt.) |
| Z Axis Travel Linear Way Enclosed Box Ram Dual Ballscrews | 1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.) |
| Table Size | 6,000×3,500 mm (236.2×137.8 in) |
| Max Table Load | 28,000 kg (61,728 lb) |
| Spindle Power Cont 30 Min | 22/26 kW (29.5/34.9 hp)(30/37 kW (40.2/49.6 hp) Opt.) |
| Spindle Speed Box Way 2 Step Gear | 4,000 / 6,000 rpm(Opt.) |
| Spindle Speed Linear Way Enclosed Box Ram 2 Step Gear | 4,000 / 6,000 rpm(Opt.) |
| Spindle Speed Linear Way Enclosed Box Ram Direct Driven | 10,000 rpm(Opt.) |
| Cutting Feed Rate | 1-7,000 mm/min |
| Rapid Traverse Xy | 8 m/min |
| Rapid Traverse Z Box Way or Linear Way | 15 m/min |
| Rapid Traverse Z Enclosed Box Ram | 12 m/min |
Specifications sourced from visionwide-tech.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Auto measurement system, rotary table and linear scales available
- 6,000×3,500 mm (236.2×137.8 in) table for 28,000 kg (61,728 lb)
- Y travel of up to 4,700 mm (185.0 in) on the MHN-6047
- 22/26 kW (29.5/34.9 hp) geared spindle as standard
Limitations
- Measurement, rotary table and scales are options with no published detail
- No tool magazine is listed for the series
- X/Y rapid of 8 m/min over the long table
Best For
Frequently Asked Questions
01
The option list includes a 6,000 rpm gear spindle, linear way or enclosed box ram heads, through-spindle coolant at 20/70 bar, oil mist cooling, XYZ-axis linear scale feedback, an auto measurement system and a rotary table.
02
None is listed. The MHN specification table has no tool changer rows and the page does not mention a tool magazine. The HF-6040, with the same travels and table, lists three changer types.
03
X 6,100 mm (240.2 in). Y 4,000 mm (157.5 in), or 4,700 mm (185.0 in) on the MHN-6047. Z 920 mm on the standard head, up to 1,400 mm on the optional heads.
04
28,000 kg (61,728 lb) on a 6,000×3,500 mm (236.2×137.8 in) table, the same rating as the MHN-6035 with its 6,000×3,000 mm (236.2×118.1 in) table.
