TRUMPF TruPunch 7000
Key Specifications
punching force
working area
hit rate max
max sheet thickness mild steel
max sheet thickness stainless
max sheet thickness aluminum
How much does the TRUMPF TruPunch 7000 cost?
Estimated price range
Our best estimate for a cnc punch presse in this class — not a quote from TRUMPF. Configuration moves it a long way.
Overview
The TruPunch 7000 is listed as a servo-electric punch press with 20 tons (200 kN) of force and a 1500 x 2500 mm working area. The 1500 mm dimension is what separates it from the TruPunch 3000, listed with 1,250 mm (49.2 in) of Y travel: wider sheets go on without being cut down first.
Sheets can weigh up to 200 kg, and repositioning speed is given as 100+ m/min with the axes coordinated. The hit rate is up to 900 strokes/min, a figure the listing itself qualifies as material and tool dependent, and the drive is described as servo electric with stroke optimization.
Thickness limits are 6.5 mm in mild steel, 4 mm in stainless and 8 mm in aluminum. Tooling is the TRUMPF MultiTool system on up to 20 stations, with a standard maximum punch diameter of 76.2 mm (3 in).
The automation row is the one to read closely. The machine is listed as ready for SheetMaster, TruStore and TruConnect, and ready describes an interface: the loading, storage and networking equipment is not described as part of the machine. Control is TRUMPF TruControl with TruTops Punch, and machine weight is approx. 9,500 kg.
Full Specifications
| Parameter | Value |
|---|---|
| Punching Force | 20 tons (200 kN) |
| Working Area | 1500 x 2500 mm |
| Hit Rate Max | up to 900 strokes/min (material and tool dependent) |
| Max Sheet Thickness Mild Steel | 6.5 mm |
| Max Sheet Thickness Stainless | 4 mm |
| Max Sheet Thickness Aluminum | 8 mm |
| Turret Stations | up to 20 (MultiTool compatible) |
| Tool System | TRUMPF MultiTool system |
| Max Punch Diameter | 76.2 mm (3 in) standard |
| Sheet Weight Max | 200 kg |
| Drive Type | Servo electric with stroke optimization |
| Repositioning Speed | 100+ m/min coordinated axes |
| CNC Control | TRUMPF TruControl / TruTops Punch |
| Automation Interface | SheetMaster, TruStore, TruConnect ready |
| Machine Weight | approx. 9,500 kg |
Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.
Strengths & Limitations
Strengths
- 1500 x 2500 mm working area with sheets up to 200 kg
- Up to 900 strokes/min, material and tool dependent
- Repositioning at 100+ m/min with coordinated axes
- Listed as ready for SheetMaster, TruStore and TruConnect
- Up to 20 stations, MultiTool compatible
Limitations
- Stainless is limited to 4 mm, against 6.5 mm in mild steel and 8 mm in aluminum
- Standard maximum punch diameter is 76.2 mm (3 in)
- The 900 strokes/min rate is qualified as material and tool dependent
- Automation appears as an interface the machine is ready for, not as equipment listed with it
Best For
Frequently Asked Questions
01
The working area is listed as 1500 x 2500 mm and the maximum sheet weight as 200 kg. Thickness limits are 6.5 mm in mild steel, 4 mm in stainless and 8 mm in aluminum.
02
The hit rate is listed as up to 900 strokes/min and is stated to depend on material and tool. Repositioning speed is given as 100+ m/min for coordinated axes. Treat both as upper figures for planning, not as rates every job will reach.
03
The listing says SheetMaster, TruStore and TruConnect ready. That describes the interface on the machine. Whether a particular machine has loading or storage equipment attached is a separate question to put to the seller.
04
The TRUMPF MultiTool system, on up to 20 stations that are MultiTool compatible. The standard maximum punch diameter is 76.2 mm (3 in), so larger openings need several hits.
