Palmary PCB-6030
Image: palmary.com, Palmary
Key Specifications
grinding diameter range
wheel size
wheel peripheral speed
grinding wheel dressing device
regulating wheel size
regulating wheel speed
How much does the Palmary PCB-6030 cost?
Price estimate
We do not have a price for the Palmary PCB-6030 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Palmary PCB-6030 is a heavy CNC centerless grinder with a Ø610 mm grinding wheel 305 mm wide and a standard grinding range of Ø1 to Ø150 mm. It marks the point in the PCB series where the grinding wheel spindle changes from single-sided to double support.
Palmary explains the reason. With a bearing at each end of the spindle, grinding force is even across the contact face and stress is equal at both ends, which avoids taper-shaped workpieces. On a 305 mm wheel that matters; an overhung spindle deflects more at the free end.
The feed slide is one V and one flat, hand scraped, and the regulating wheel is driven through an adjustable worm shaft that takes out backlash. The regulating wheel itself is Ø355 mm by 305 mm on a 5 kW (6.7 hp) servo, 10 to 200 rpm. Its tilt is +5° to -1° and its swivel ±2°, both different from the smaller PCB machines.
The grinding wheel motor is 30 HP (22 kW) and wheel speed 45 m/s (8,858 ft/min). Lubrication of the grinding wheel spindle is by oil mist, which Palmary says also helps cleaning and temperature control. Palmary describes CNC control as available from 1 to 6 axes to suit the customer. Standard accessories include a FANUC CNC controller and a vibration meter for manual wheel balancing; a grinding wheel exchanger and a jib crane are optional. The machine weighs 7,000 kg (15,432 lb).
Full Specifications
| Parameter | Value |
|---|---|
| Grinding Diameter Range | Ø1~Ø150 mm |
| Wheel Size | Ø610 x 305 x Ø304.8 mm (24.0 x 12.0 x 12.0 in) |
| Wheel Peripheral Speed | 45 m/s (8,858 ft/min) |
| Grinding Wheel Dressing Device | Single-point dressing device / (opt.) Diamond roller dressing device |
| Regulating Wheel Size | Ø355 x 305 x Ø203.2 mm (14.0 x 12.0 x 8.0 in) |
| Regulating Wheel Speed | 10-200 rpm (variable speed) |
| Regulating Wheel Tilt Angle | +5°~-1° |
| Regulating Wheel Swivel Angle | ±2° |
| Regulating Wheel Dresser Swivel Angle | ±5° |
| Regulating Wheel Dresser Offset | 0~20 mm |
| Grinding Wheel Motor | 30 HP x 4P (22 kW) |
| Regulating Wheel Motor | 5 kW (6.7 hp) servo motor |
| Coolant Pump Motor | 1 HP x 2P (0.75 kW) |
| Grinding Wheel Spindle Lubrication | Oil mist type |
| Regulating Wheel Spindle Lubrication | Oil grease type |
| Slide Lubrication | Auto lubricator (LUBE) |
| CNC Control | FANUC |
| Coolant Tank | 140 L (37.0 gal) |
| Wheel Spindle Lubrication Tank | 1.0 L (0.3 gal) |
| Slide Lubrication Tank | 4 L (1.1 gal) |
| Machine Weight | 7,000 kg (15,432 lb) |
Specifications sourced from palmary.com — verified 2026-10-05
Strengths & Limitations
Strengths
- Double support grinding wheel spindle to avoid tapered work on a wide wheel
- Standard range up to Ø150 mm
- 30 HP (22 kW) on a Ø610 x 305 mm wheel at 45 m/s (8,858 ft/min)
- Hand scraped V and flat feed slide and an adjustable regulating wheel worm shaft
Limitations
- Regulating wheel tilt is +5° to -1°
- Wheel changes on a double-support spindle need the optional exchanger or jib crane to be practical
- 140 L (37.0 gal) coolant tank
- 7,000 kg (15,432 lb) installation weight
Best For
Frequently Asked Questions
01
A standard grinding range of Ø1 to Ø150 mm. The grinding wheel is Ø610 x 305 mm on a 304.8 mm bore and the regulating wheel Ø355 x 305 mm on a 203.2 mm bore. Machine weight is 7,000 kg (15,432 lb).
02
Palmary says the double support bearing type spindle gives even grinding force on the contact surface, with equal stress at both ends of the spindle during grinding, so that workpieces do not come out taper shaped.
03
The PCB-6040 has 405 mm wide wheels and a 40 HP (30 kW) grinding wheel motor. The PCB-6030 has 305 mm wide wheels and a 30 HP (22 kW) motor. The lubrication columns also differ: oil mist and grease on the PCB-6030, automatic lubricators on the PCB-6040.
04
Palmary describes computer numerical control from 1 to 6 axes to satisfy customized specifications. The page does not list travels per axis, so the axis set is agreed per order. The controller is FANUC.
