Palmary OCD-45150
Image: palmary.com, Palmary
Key Specifications
swing over table
distance between centers
max grinding diameter
max load between centers
wheel size
wheel peripheral speed
How much does the Palmary OCD-45150 cost?
Price estimate
We do not have a price for the Palmary OCD-45150 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Palmary OCD-45150 opens the heavy duty OCD range: a CNC cylindrical grinder with Ø450 mm (17.7 in) of swing, 1,500 mm (59.1 in) between centers and, the figure that defines the series, 800 kg (1,764 lb) between centers. Maximum grinding diameter is Ø420 mm (16.5 in).
Compare that with the standard OCD-42150, which has the same center distance and carries 150 kg (331 lb). The heavy duty machine is a different build. Palmary describes a reinforced Meehanite cast iron base and longitudinal and traverse slides with a hydrostatic structure, and the scale shows in the weight of 12,000 kg (26,455 lb).
The grinding end is sized to match. An 11 kW (14.8 hp) motor drives a Ø510 mm wheel that can be anything from 50 to 125 mm wide, at 33 m/s (6,496 ft/min). The wheelhead strokes 350 mm (13.8 in) and the table 1,970 mm (77.6 in), each at 10 m/min (394 ipm), on AC servo motors of 2.8 kW (3.8 hp) and 4.4 kW (5.9 hp).
Some flexibility is given up for stiffness. The work spindle head is fixed at 0°, so there is no swivelling it for face or angle work, and it turns at 0 to 210 rpm on a 2.9 kW (3.9 hp) servo motor. The table swivels from -1° to 5°, the widest range of the four OCD-45 lengths. The tailstock is hydraulic with 60 mm (2.4 in) of motion. FANUC control, a linear scale on X and a semi-enclosed splash guard are standard.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Table | Ø450 mm (17.7 in) |
| Distance Between Centers | 1,500 mm (59.1 in) |
| Max Grinding Diameter | Ø420 mm (16.5 in) |
| Max Load Between Centers | 800 kg (1,764 lb) |
| Wheel Size | Ø510 x 50~125 x Ø152.4 mm |
| Wheel Peripheral Speed | 33 m/s (6,496 ft/min) |
| X Axis Rapid Traverse | 10 m/min (394 ipm) |
| X Axis Travel | 350 mm (13.8 in) |
| X Axis Min Setting Unit | 0.001 mm |
| Z Axis Rapid Traverse | 10 m/min (394 ipm) |
| Z Axis Travel | 1,970 mm (77.6 in) |
| Z Axis Min Input Increment | 0.001 mm |
| Table Swivel Angle | -1°~5° |
| Workhead Swivel Angle | 0° (Fixed Type) |
| Workhead Center Taper | M.T. No. 5 / M.T. No. 6 (opt.) |
| Work Spindle Speed | 0-210 rpm |
| Tailstock Center Taper | M.T. No. 5 |
| Tailstock Type of Motion | Hydraulic |
| Tailstock Max Motion Distance | 60 mm (2.4 in) |
| Wheel Spindle Motor | 11 kW (14.8 hp) |
| Workhead Motor | 2.9 kW (3.9 hp) |
| Wheelhead Feed Motor | 2.8 kW (3.8 hp) |
| Table Feed Motor | 4.4 kW (5.9 hp) |
| Hydrostatic Pump Motor | 0.37 kW (0.5 hp) (4P) |
| Wheel Spindle Lubrication Pump Motor | 0.37 kW (0.5 hp) (4P) |
| Coolant Pump Motor | 0.37 kW (0.5 hp) (2P) |
| Ballscrew Lubrication | Auto lubricator (LUBE) |
| Internal Grinding Spindle Motor Optional | 0.75 kW (1.0 hp) (2P) |
| Power Requirement | 30 kVA |
| Wheel Spindle Lubrication Tank | 31 L (8.2 gal) |
| Lubrication Tank | 31 L (8.2 gal) |
| Hydraulic Tank | 31 L (8.2 gal) |
| Ballscrew Lubrication Tank | 0.7 L (0.2 gal) |
| Coolant Tank | 230 L (60.8 gal) |
| Machine Weight | 12,000 kg (26,455 lb) |
| CNC Control | FANUC CNC controller |
Specifications sourced from palmary.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 800 kg (1,764 lb) between centers on a 1,500 mm (59.1 in) bed
- 11 kW (14.8 hp) wheel motor with wheels from 50 to 125 mm wide
- Hydraulic tailstock with 60 mm (2.4 in) of motion is a standard accessory
- Table swivel of -1° to 5°, the widest of the OCD-45 lengths
- Hydrostatic slide structure on both the longitudinal and traverse tables, according to Palmary
Limitations
- Work spindle head is fixed at 0° and cannot swivel
- Splash guard is semi-enclosed, not fully enclosed as on the standard OCD models
- 12,000 kg (26,455 lb) machine weight and 30 kVA of total power need planning for foundation and supply
- Wheel balancing is manual with a vibration meter; the automatic balancer is an option
Best For
Frequently Asked Questions
01
800 kg (1,764 lb). The centers are No. 5 Morse taper as standard, with No. 6 offered as an option on the work spindle head. The tailstock is hydraulically operated and has a maximum motion distance of 60 mm (2.4 in).
02
Distance between centers is 1,500 mm (59.1 in). The table (Z axis) has a maximum stroke of 1,970 mm (77.6 in) and the wheelhead (X axis) 350 mm (13.8 in). Both rapid at 10 m/min (394 ipm) and both have a minimum increment of 0.001 mm.
03
Load and mass. The OCD-42150 carries 150 kg (331 lb) between centers and weighs 5,000 kg (11,023 lb). The OCD-45150 carries 800 kg (1,764 lb), has an 11 kW (14.8 hp) wheel motor and weighs 12,000 kg (26,455 lb), but its work spindle head is fixed and its splash guard is semi-enclosed.
04
With an option. The accessory list includes an internal grinding attachment, and the table lists an optional internal grinding spindle of 0.75 kW (1.0 hp). Other options are heavy type steady rests, a live work center, gap control and an automatic in-process gauge.
