Mazak INTEGREX i-800V/8

Est. $700,000 - $1,100,000 Specs verified 2026-10-02 · mazak.com Updated 2026-10-02

Image: mazak.com, Yamazaki Mazak

Key Specifications

X Travel

67 in (1,702 mm)

Y Travel

59 in (1,499 mm)

Z Travel

45 in (1,143 mm)

Spindle Taper

CAT No.50

Tool Capacity

43 tools

max machining diameter od

Ø59 in (1,499 mm)

How much does the Mazak INTEGREX i-800V/8 cost?

Estimated price range

Est.$700,000 - $1,100,000

Our best estimate for a mill-turn / multi-tasking machine in this class — not a quote from Yamazaki Mazak. Configuration moves it a long way.

Overview

The Mazak INTEGREX i-800V/8 is a 5-axis vertical mill-turn machine sized for parts up to 59 in (1,499 mm) in diameter and 59 in (1,499 mm) tall, with a table load of 6,614 lb (3,000 kg). Travels are 67 in (1,702 mm) in X, 59 in (1,499 mm) in Y and 45 in (1,143 mm) in Z, and Mazak's model list gives its configuration as a 2 pallet changer.

Y travel matching the maximum part diameter is the detail to notice. The milling spindle can cross the full width of the largest workpiece by linear motion alone, which keeps face milling and bolt-hole patterns free of long tool reaches. Z is the shorter axis at 45 in (1,143 mm), less than the 59 in (1,499 mm) part height, so on tall workpieces the reach to low features should be worked out with the 150° B-axis tilt and the 26 in (660 mm) maximum tool length in mind.

For turning, the table runs to 500 rpm on a 45 kW (60 HP) continuous motor with 3,120 Nm (2,301 ft-lb) of continuous torque. The INTEGREX i-630V/6 has 56 in (1,422 mm) of X, 41 in (1,041 mm) of Y and Z and a 3,858 lb (1,750 kg) table load; the i-800V/8 keeps the same 2,047 ipm (52 m/min) rapids and 43-tool CAT No.50 magazine while carrying about 71% more weight on the table.

The milling spindle is rated 30 kW (40 HP) and 248 Nm (183 ft-lb) continuous, 37 kW (50 HP) and 353 Nm (260 ft-lb) at 40% ED, with a 10,000 rpm top speed. B and C both index in 0.0001° increments. The machine weighs 87,412 lb (39,649 kg) and needs 237 in (6,020 mm) × 344 in (8,738 mm) of floor under a 157 in (3,988 mm) height.

Full Specifications

Parameter	Value
Max Machining Diameter OD	Ø59 in (1,499 mm)
Max Workpiece Size	Ø59 in (1,499 mm) × 59 in (1,499 mm)
Max Table Load	6,614 lb (3,000 kg)
Table Max Spindle Speed	500 rpm
Table Max Torque Cont Rating	3,120 Nm (2,301 ft-lb) (cont. rating)
Table Spindle Motor Cont Rating	45 kW (60 HP) (cont. rating)
Table Rapid Traverse Rate C Axis	50 rpm
Table Min Indexing Angle Increment C Axis	0.0001°
Milling Spindle Speed	10,000 rpm
Milling Spindle Torque Intermittent	353 Nm (260 ft-lb) (40% ED)
Milling Spindle Torque	248 Nm (183 ft-lb) continuous
Milling Spindle Power Intermittent	37 kW (50 HP) (40% ED)
Milling Spindle Power	30 kW (40 HP) continuous
Milling Spindle Rapid Traverse Rate B Axis	30 rpm
Milling Spindle Min Indexing Angle Increment B Axis	0.0001°
Spindle Taper	CAT No.50
Tool Capacity	43 tools
Max Tool Diameter (full magazine)	Ø5 in (127 mm)
Max Tool Diameter (adjacent pockets empty)	Ø10 in (254 mm)
Max Tool Length	26 in (660 mm)
Max Tool Weight	66 lb (30 kg)
X-Axis Travel	67 in (1,702 mm)
Y-Axis Travel	59 in (1,499 mm)
Z-Axis Travel	45 in (1,143 mm)
B Axis Range	150°
C Axis Range	360°
Rapid Traverse X	2,047 ipm (52 m/min)
Rapid Traverse Y	2,047 ipm (52 m/min)
Rapid Traverse Z	2,047 ipm (52 m/min)
Floor Space Required	237 in (6,020 mm) × 344 in (8,738 mm) (W × L)
Machine Height	157 in (3,988 mm)
Machine Weight	87,412 lb (39,649 kg)

Specifications sourced from mazak.com — verified 2026-10-02

Strengths & Limitations

Strengths

59 in (1,499 mm) of Y travel, equal to the maximum workpiece diameter
Table load of 6,614 lb (3,000 kg), about 71% above the 3,858 lb (1,750 kg) of the INTEGREX i-630V/6
45 kW (60 HP) continuous table motor with 3,120 Nm (2,301 ft-lb) of continuous torque for turning
Rapids of 2,047 ipm (52 m/min) on X, Y and Z, faster than the 1,654 ipm (42 m/min) of the INTEGREX e-1250V/8
Tools up to 26 in (660 mm) long in the 43-tool magazine
A 2 pallet changer is the configuration on Mazak's model list

Limitations

Z travel of 45 in (1,143 mm) is shorter than the 59 in (1,499 mm) maximum workpiece height
Table speed is limited to 500 rpm for turning
The INTEGREX e-1250V/8 offers more X and Z travel: 74 in (1,880 mm) and 53 in (1,346 mm)
Tool diameter is 5 in (127 mm) with a full magazine; 10 in (254 mm) tools need empty adjacent pockets
Takes 237 in (6,020 mm) × 344 in (8,738 mm) of floor and weighs 87,412 lb (39,649 kg)

Best For

Large housings, rings and discs up to 59 in (1,499 mm) in diameter Heavy castings up to the 6,614 lb (3,000 kg) table load Face and multi-side milling that needs 59 in (1,499 mm) of Y Turned and milled parts finished in one setup on a two-pallet machine

Frequently Asked Questions

01 What size workpiece does the INTEGREX i-800V/8 accept?

Maximum workpiece size is 59 in (1,499 mm) in diameter by 59 in (1,499 mm) high, with a maximum table load of 6,614 lb (3,000 kg). The maximum machining diameter on the outside of a part is also 59 in (1,499 mm).

02 How does the i-800V/8 differ from the e-1250V/8?

The INTEGREX e-1250V/8 has longer X and Z travels at 74 in (1,880 mm) and 53 in (1,346 mm), but less Y at 49 in (1,245 mm) against 59 in (1,499 mm). The INTEGREX e-1250V/8 rapids at 1,654 ipm (42 m/min), carries 5,952 lb (2,700 kg) on the table, holds 42 tools and weighs 109,127 lb (49,499 kg). The i-800V/8 is the faster and lighter machine at 2,047 ipm (52 m/min) and 87,412 lb (39,649 kg), with the higher table load.

03 What are the turning figures of the table?

Maximum table speed is 500 rpm. The table motor is rated 45 kW (60 HP) continuous and the continuous torque is 3,120 Nm (2,301 ft-lb). Used as a C axis the table rotates 360°, indexes in 0.0001° increments and rapids at 50 rpm.

04 Is the Z travel enough for a full-height part?

Z travel is 45 in (1,143 mm) and the maximum workpiece height is 59 in (1,499 mm), so the stroke alone does not span the tallest part. Reach to features low on a tall workpiece also depends on tool length, up to 26 in (660 mm), and on tilting the spindle within the 150° B-axis range. Check the part against Mazak's machining-range drawing.

05 What does Mazak say about the structure of the i-V series?

The series description lists linear roller guides on the X, Y and Z axes, a backlash-free roller gear cam on the B axis across its 150-degree range, and a slanted mounting surface for the Y-axis roller guides to absorb cutting load. Pallet and table are clamped by cone couplings for repeatable positioning at each pallet change.
