Mazak INTEGREX i-350S NEO
Image: mazak.com, Yamazaki Mazak
Key Specifications
X Travel
Y Travel
Z Travel
Max Spindle
Spindle Taper
Tool Capacity
How much does the Mazak INTEGREX i-350S NEO cost?
Estimated price range
Our best estimate for a mill-turn / multi-tasking machine in this class — not a quote from Yamazaki Mazak. Configuration moves it a long way.
Overview
The Mazak INTEGREX i-350S NEO pairs two 10 in chuck turning spindles on Mazak's 1500U bed class, which gives it 60 in (1,524 mm) of maximum turning length and 62 in (1,575 mm) of Z travel. Swing is Ø26 in (660 mm), both turning spindles reach 4,000 rpm, and a 12,000 rpm milling spindle with a 36-tool magazine works at either end.
Length is the first thing that separates this table from the tailstock model. The INTEGREX i-350 NEO is listed with 40 in (1,016 mm) of turning length and 42 in (1,067 mm) of Z at 29,652 lb (13,450 kg). Here the bed is long enough to stand off the second spindle from the main chuck and still machine a part of real length in between, and the weight rises to 33,179 lb (15,050 kg). The floor plan stretches too, to 197 in (5,004 mm) × 123 in (3,124 mm).
The S is Mazak's second spindle configuration. Its second spindle is a full-size unit, with the same 10 in chuck, 4,000 rpm and 22 kW (30 HP) continuous as the main one. The 40% ED ratings are 30 kW (40 HP) on the main spindle and 26 kW (35 HP) on the second. Because the continuous figures are equal, second-operation turning does not have to be programmed more gently than the first.
Above the bed the milling spindle is rated 22 kW (30 HP) continuous with 91.3 Nm (67 ft-lb) of continuous torque, swivels from -30° to +210°, and has 27 in (686 mm) of X and 12 in (305 mm) of Y. Z rapid traverse is 1,969 ipm (50 m/min), which matters on a 62 in (1,575 mm) axis where the spindle regularly crosses from one chuck to the other. No tailstock is listed for this configuration.
Full Specifications
| Parameter | Value |
|---|---|
| Bed Length Type | 1500U |
| Max Turning Diameter | Ø26 in (660 mm) |
| Max Turning Length | 60 in (1,524 mm) |
| Chuck Size | 10 in |
| Max Spindle Speed | 4,000 rpm |
| Spindle Power Intermittent | 30 kW (40 HP) (40% ED) |
| Spindle Motor Power | 22 kW (30 HP) continuous |
| Sub Spindle Chuck Size | 10 in |
| Sub Spindle Speed | 4,000 rpm |
| Sub Spindle Power Intermittent | 26 kW (35 HP) (40% ED) |
| Sub Spindle Power | 22 kW (30 HP) continuous |
| Milling Spindle Speed | 12,000 rpm |
| Milling Spindle Torque Intermittent | 124 Nm (91 ft-lb) (40% ED) |
| Milling Spindle Torque | 91.3 Nm (67 ft-lb) continuous |
| Milling Spindle Power Intermittent | 24 kW (32 HP) (40% ED) |
| Milling Spindle Power | 22 kW (30 HP) continuous |
| B Axis Indexing Increment | 0.0001° |
| Spindle Taper | HSK-T63, HSK-A63 |
| Tool Capacity | 36 tools |
| Max Tool Diameter (full magazine) | Ø4 in (102 mm) |
| Max Tool Diameter (adjacent pockets empty) | Ø5 in (127 mm) |
| Max Tool Length | 16 in (406 mm) |
| Max Tool Weight | 26 lb (12 kg) |
| X-Axis Travel | 27 in (686 mm) |
| Y-Axis Travel | 12 in (305 mm) |
| Z-Axis Travel | 62 in (1,575 mm) |
| B Axis Range | -30° - +210° |
| Rapid Traverse X | 1,969 ipm (50 m/min) |
| Rapid Traverse Y | 1,575 ipm (40 m/min) |
| Rapid Traverse Z | 1,969 ipm (50 m/min) |
| Floor Space Required | 197 in (5,004 mm) × 123 in (3,124 mm) (W × L) |
| Machine Height | 107 in (2,718 mm) |
| Machine Weight | 33,179 lb (15,050 kg) |
Specifications sourced from mazak.com — verified 2026-10-02
Strengths & Limitations
Strengths
- 60 in (1,524 mm) of turning length and 62 in (1,575 mm) of Z travel, against 40 in (1,016 mm) and 42 in (1,067 mm) on the INTEGREX i-350 NEO
- Full-size second spindle: 10 in chuck, 4,000 rpm and 22 kW (30 HP) continuous, the same as the main spindle
- Z rapid traverse of 1,969 ipm (50 m/min) shortens the long moves between the two chucks
- Three spindles each rated 22 kW (30 HP) continuous: main, second and milling
- B-axis range of -30° to +210° in 0.0001° increments
Limitations
- Footprint grows to 197 in (5,004 mm) × 123 in (3,124 mm) and weight to 33,179 lb (15,050 kg), well above the 29,652 lb (13,450 kg) of the INTEGREX i-350 NEO
- The table lists no tailstock, so a long shaft cannot be run on a centre in this configuration
- 36 tools serve both spindles along a 60 in (1,524 mm) turning length, with no turret listed to carry extra tools
- Second spindle power at 40% ED is 26 kW (35 HP), below the 30 kW (40 HP) of the main spindle
Best For
Frequently Asked Questions
01
Maximum turning length is 60 in (1,524 mm) and maximum turning diameter is Ø26 in (660 mm). Z travel is 62 in (1,575 mm). The table is for Mazak's 1500U bed class. For comparison, the INTEGREX i-350 NEO is listed at 40 in (1,016 mm) of turning length with 42 in (1,067 mm) of Z.
02
Nearly. Both have a 10 in chuck, a 4,000 rpm maximum and 22 kW (30 HP) continuous. The difference is the 40% ED rating: 30 kW (40 HP) on the main spindle and 26 kW (35 HP) on the second. Heavy interrupted roughing is better placed on the main spindle; ordinary turning can go on either.
03
The footprint is 197 in (5,004 mm) × 123 in (3,124 mm) (W × L) and the height is 107 in (2,718 mm). The machine weighs 33,179 lb (15,050 kg), so check floor loading as well as floor area, and leave room at the ends for loading long stock and removing finished parts.
04
The milling spindle runs to 12,000 rpm and is rated 22 kW (30 HP) continuous and 24 kW (32 HP) at 40% ED. Torque is 91.3 Nm (67 ft-lb) continuous and 124 Nm (91 ft-lb) at 40% ED. The taper is listed as HSK-T63, HSK-A63, and tools can be up to 16 in (406 mm) long and 26 lb (12 kg).
05
Neither appears in Mazak's table for this model. Its configuration on Mazak's model list is Second Spindle. Mazak states that a lower turret specification is also available in the INTEGREX i NEO series; that is a different configuration and should be asked for by name.
