LVD Easy-Form 110/42
Image: lvdgroup.com, LVD
Key Specifications
pressing force
hydraulic pressure
bending length
width between columns
ram stroke
open height
How much does the LVD Easy-Form 110/42 cost?
Price estimate
We do not have a price for the LVD Easy-Form 110/42 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The LVD Easy-Form 110/42 has a working length of 4,270 mm (168.1 in), the fourteen-foot size, at 1,100 kN. What sets it apart from the four-metre model is less the extra bed than the frame around it.
Look at the distance between uprights: 3,820 mm (150.4 in). On the Easy-Form 110/40 that figure is 3,150 mm. So this machine passes a much longer part straight through the frame, with no need to slide it into the gap. For anyone bending deep boxes or wide panels close to four metres long, that is the practical gain, and it is worth more than the added working length suggests.
It weighs 12,000 kg (26,455 lb). Motor, tank and speeds are common to the 1,100 kN group: 22 kW, 250 L, 180 mm/s approach, 22 mm/s working speed and 200 mm/s return, at 245 bar.
Force is the limit. No Easy-Form of this length has less, and full-length bends are confined to thin material. The table is 120 mm (4.7 in) wide and rated at 2,000 kN/m; stroke is 200 mm (7.9 in), open height and gap 400 mm (15.7 in) each.
Standard equipment includes Easy-Form Laser adaptive bending, turbo hydraulic drive, a knuckle arm for the control and LED lighting of the work zone.
Full Specifications
| Parameter | Value |
|---|---|
| Pressing Force | 1,100 kN |
| Hydraulic Pressure | 245 bar |
| Bending Length | 4,270 mm (168.1 in) |
| Width Between Columns | 3,820 mm (150.4 in) |
| Ram Stroke | 200 mm (7.9 in) |
| Open Height | 400 mm (15.7 in) |
| Throat Depth | 400 mm (15.7 in) |
| Table Width | 120 mm (4.7 in) |
| Max Table Load | 2,000 kN/m |
| Working Height | 970 mm (38.2 in) |
| Approach Speed | 180 mm/s |
| Bending Speed | 22 mm/s |
| Return Speed | 200 mm/s |
| Motor Power | 22 kW |
| Machine Weight | 12,000 kg (26,455 lb) |
| Oil Tank Capacity | 250 L |
Specifications sourced from lvdgroup.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 3,820 mm (150.4 in) between uprights, far more than the Easy-Form 110/40
- 4,270 mm (168.1 in) working length
- 12,000 kg (26,455 lb) with a 22 kW motor
- Full Easy-Form standard equipment, including laser angle correction
- Fast ram: 180 mm/s approach, 22 mm/s working
Limitations
- 1,100 kN is the minimum offered at this length
- 200 mm (7.9 in) stroke with 400 mm (15.7 in) of open height
- Table width 120 mm (4.7 in)
- Long thin blanks need the optional front supports or sheet followers
Best For
Frequently Asked Questions
01
For the frame opening. The Easy-Form 110/40 has 3,150 mm between uprights and weighs 11,000 kg. This model has 3,820 mm (150.4 in) between uprights and a 4,270 mm working length, and weighs 12,000 kg.
02
LVD's table gives a working length of 4,270 mm (168.1 in) for the columns ending in 42, and 1,100 kN for those beginning with 110. The page itself does not explain the naming, so read the name as a label for those two table values.
03
The Easy-Form 135/42 has the same 4,270 mm working length, 3,820 mm between uprights and 12,000 kg, with 1,350 kN. The Easy-Form 170/42 and Easy-Form 220/42 also have this length, with 1,700 kN and 2,200 kN.
04
LVD lists the Easy-Form Laser system, turbo hydraulic drive, knuckle arm, LED work zone lighting, a second foot pedal, a barcode reader and an air conditioner for the electrical cabinet.
