Kjellberg HiFocus 600i neo

Q: How much does the Kjellberg HiFocus 600i neo cost?

The price estimate for the Kjellberg HiFocus 600i neo is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/kjellberg-hi-focus-600i-neo#price; the request is passed to Kjellberg or an authorised dealer.

Specs verified 2026-10-06 · kjellberg.de Updated 2026-10-06

Kjellberg HiFocus 600i neo plasma cutting power source

Image: kjellberg.de, Kjellberg

Key Specifications

cutting current

600 A

cutting current range

10 - 600 A

cutting current hifocus 360i neo

10 - 360 A (at 100 % duty cycle)

cutting current power module

100 - 300 A (at 100 % duty cycle)

marking current

5 - 50 A

cutting range

0.5 - 160 mm (0.02 - 6.3 in)

How much does the Kjellberg HiFocus 600i neo cost?

Price estimate

Uncertain

We do not have a price for the Kjellberg HiFocus 600i neo that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The Kjellberg HiFocus 600i neo is not one cabinet but two. Kjellberg builds the system from a HiFocus 360i neo power source and a power module, and together they reach a maximum cutting current of 600 A. The cutting range is 0.5 - 160 mm (0.02 - 6.3 in), the widest of the HiFocus neo range.

For plate this heavy, the recommended and piercing figures are the ones to plan with. The recommended cutting range is 0.5 - 120 mm (0.02 - 4.7 in) and piercing is listed at 80 mm (3.1 in). Beyond the piercing figure, and up to the 160 mm limit, the cut is started from an edge. The system is also described as suited for marking, bevel and underwater cutting, with a marking current of 5 - 50 A.

The two-cabinet design shows in every installation row. The table lists the 360i neo part at 10 - 360 A and the power module at 100 - 300 A. Mains voltage is 3x 400 V, 50 Hz (2x), the slow fuse is 160 A (2x), and the connected load is given as "max. 104 + 87 kVA". Dimensions are 1030 x 680 x 1450 mm (2x) and the weight row reads "519 + 491 kg". Floor space, feeders and cable runs are therefore planned twice.

Gases match the larger single units: plasma gases O2, N2, Air, Ar, H2 and F5, swirl gases O2, N2, Air and F5. Contour Cut for contours, holes and webs in mild steel is part of the system. Duty cycle is 100 % at an ambient temperature of 40 °C.

Full Specifications

Parameter	Value
Cutting Current	600 A
Cutting Current Range	10 - 600 A
Cutting Current Hifocus 360i Neo	10 - 360 A (at 100 % duty cycle)
Cutting Current Power Module	100 - 300 A (at 100 % duty cycle)
Marking Current	5 - 50 A
Cutting Range	0.5 - 160 mm (0.02 - 6.3 in)
Cutting Range Recommended	0.5 - 120 mm (0.02 - 4.7 in)
Piercing	80 mm (3.1 in)
Duty Cycle	100 % (ambient temperature 40 °C)
Plasma Gases	O2, N2, Air, Ar, H2, F5
Swirl Gases	O2, N2, Air, F5
Mains Voltage	3x 400 V, 50 Hz (2x)
Fuse Slow	160 A (2x)
Connected Load	max. 104 + 87 kVA
Machine Dimensions	1030 x 680 x 1450 mm (2x)
Machine Weight	519 + 491 kg

Specifications sourced from kjellberg.de — verified 2026-10-06

Strengths & Limitations

Strengths

Maximum cutting current of 600 A from two coupled power sources
Cutting range of 0.5 - 160 mm (0.02 - 6.3 in), with a recommended range up to 120 mm
Piercing listed at 80 mm (3.1 in)
Suited for marking, bevel and underwater cutting
100 % duty cycle at an ambient temperature of 40 °C

Limitations

Two cabinets of 1030 x 680 x 1450 mm each, with a weight row of "519 + 491 kg"
Two mains connections on 160 A slow fuses, and a connected load of "max. 104 + 87 kVA"
Plate between the 80 mm piercing figure and the 160 mm limit needs an edge start
The product page lists no torch model for the system

Best For

Heavy plate inside the 0.5 - 120 mm recommended range Edge-started cuts in sections up to 160 mm Thick stainless steel and aluminium with the Ar/H2 Mix technology Underwater and bevel cutting of heavy sections

Frequently Asked Questions

01 What does the HiFocus 600i neo consist of?

Kjellberg describes it as a system of two power sources: a HiFocus 360i neo and the power module HiFocus 600i neo. The table lists a cutting current of 10 - 360 A for the first and 100 - 300 A for the module, and the system reaches a maximum cutting current of 600 A.

02 How thick can the HiFocus 600i neo cut and pierce?

The cutting range is 0.5 - 160 mm (0.02 - 6.3 in). The series brochure lists a recommended range of 0.5 - 120 mm and a piercing figure of 80 mm. Sections thicker than the piercing figure are cut from an edge start.

03 What power connection does the HiFocus 600i neo need?

Each of the two cabinets has its own connection. The brochure lists the mains voltage as 3x 400 V, 50 Hz (2x), the slow fuse as 160 A (2x) and the connected load as "max. 104 + 87 kVA". Other voltages and frequencies are available upon request.

04 Does the HiFocus 600i neo also cut thin sheet?

The listed cutting range starts at 0.5 mm and the current range starts at 10 A, so the system is not restricted to heavy plate. Marking is possible at 5 - 50 A, and Contour Cut is used for contours, holes and webs in mild steel.
