Johnford LC-50
Image: johnford.com.tw, Johnford
Key Specifications
Max Spindle
Rapid Traverse
Spindle Power
swing over bed
swing over cross slide
distance between centers
How much does the Johnford LC-50 cost?
Price estimate
We do not have a price for the Johnford LC-50 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Between the two ends of Johnford's flat-bed range, the Johnford LC-50 swings 1,275 mm (50.2 in) over the bed and 910 mm (35.8 in) over the cross slide. That is a large step over the cross slide from the LC-40, which clears 640 mm (25.2 in).
Its drives, though, are those of the LC-40. The spindle motor is 22 / 26 kW (29.5 / 34.9 hp), with 30 / 37 kW (40.2 / 49.6 hp) as an option, the X servo motor 3 kW, the Z servo motor 4 kW and the C-axis motor 2.1 kW. The LC-60 is the model with larger motors throughout. So the LC-50 suits work that needs the clearance without the heaviest cuts: long fabricated cylinders, large pipe, rolls of moderate weight.
For pipe, the wider headstock choices matter. Variants G and H have A2-20 noses with Ø318 mm and Ø360 mm bores, I and J have A2-28 noses with Ø410 mm and Ø535 mm, and K has an A2-32 nose with a Ø610 mm bore, at speeds from 500 rpm down to 220 rpm. Front and rear chucks are an option.
Bed lengths follow the same scheme as on the other LC models, from 2,000 mm between centers up to 20,000 mm. Listed weights run from 23,000 kg (model 5080) to 37,000 kg (model 50360).
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Bed | 1,275 mm (50.2 in) |
| Swing Over Cross Slide | 910 mm (35.8 in) |
| Distance Between Centers | 2,000 / 3,000 / 4,000 / 5,000 / 6,000 / 7,000 / 8,000 / 9,000 mm, up to 20,000 mm |
| Bed Width | 1,145 mm (45 in) |
| Spindle Nose | B: A2-11 / C, D, E, F: A2-15 / G, H: A2-20 / I, J: A2-28 / K: A2-32 |
| Spindle Bore | B: Ø132.5 mm / C: Ø152 mm / D: Ø176 mm / E: Ø236 mm / F: Ø255 mm / G: Ø318 mm / H: Ø360 mm / I: Ø410 mm / J: Ø535 mm / K: Ø610 mm |
| Spindle Transmission | Auto 4-speeds |
| Max Spindle Speed | B: 2,000 rpm / C: 1,200 rpm / D: 1,000 rpm / E: 750 rpm / F: 600 rpm / G: 500 rpm / H: 400 rpm / I: 300 rpm / J: 250 rpm / K: 220 rpm |
| Spindle Bearing Diameter | B: Ø180 mm / C: Ø220 mm / D: Ø240 mm / E: Ø280 mm / F: Ø305 mm / G: Ø381 mm / H: Ø457 mm / I: Ø480 mm / J: Ø610 mm / K: Ø700 mm |
| Turret Stations | 4 / 6 / 8 / 12 position, or Twin turret (Opt.) |
| Square Tool Holder Size | 32 x 32 mm (1.3 x 1.3 in) |
| Tool Shank Size | Ø50 (Std.), Ø60 (Opt.) / VDI 50 (Std.), VDI 60 (Opt.) (mm) |
| Rapid Traverse Rate | X: 6 m/min (236 ipm); Z: 8 m/min (315 ipm) |
| Tailstock Quill Type | Rotary tailstock spindle |
| Tailstock Quill Travel | 250 mm (9.8 in) |
| Tailstock Quill Diameter | Ø250 mm (Ø9.8 in) |
| Tailstock Taper | MT#6 (MT#7 Opt.) |
| Spindle Motor Power | 22 / 26 kW (29.5 / 34.9 hp); 30 / 37 kW (40.2 / 49.6 hp) Opt. |
| Servo Motor X | 3 kW |
| Servo Motor Z | 4 kW |
| Coolant Pump Motor | 0.98 kW |
| Hydraulic Motor | 3.8 kW |
| C Axis Motor | 2.1 kW |
| Machine Weight | LC-5080: 23,000 kg / LC-50120: 25,000 kg / LC-50160: 27,000 kg / LC-50200: 29,000 kg / LC-50240: 31,000 kg / LC-50280: 33,000 kg / LC-50320: 35,000 kg / LC-50360: 37,000 kg |
| Series Models | 5080, 50120, 50160, 50200, 50240, 50280, 50320, 50360, 50400, 50440, 50480 |
Specifications sourced from johnford.com.tw — verified 2026-10-04
Strengths & Limitations
Strengths
- 1,275 mm (50.2 in) swing over the bed and 910 mm (35.8 in) over the cross slide
- Spindle bores up to Ø610 mm with variant K
- Distances between centers up to 20,000 mm
- Front and rear chucks available for pipe
- Optional additional CNC carriage for a boring bar system
Limitations
- Same 22 / 26 kW (29.5 / 34.9 hp) standard motor as the LC-40
- X and Z servo motors of 3 kW and 4 kW
- Supplied without a chuck on the main spindle
- Variant K turns at 220 rpm
Best For
Frequently Asked Questions
01
1,275 mm (50.2 in) over the bed and 910 mm (35.8 in) over the cross slide. The bed is 1,145 mm (45 in) wide, as on the other LC models.
02
It depends on the length. The table lists LC-5080: 23,000 kg, LC-50120: 25,000 kg, LC-50160: 27,000 kg, LC-50200: 29,000 kg, LC-50240: 31,000 kg, LC-50280: 33,000 kg, LC-50320: 35,000 kg and LC-50360: 37,000 kg.
03
No. Both list 22 / 26 kW (29.5 / 34.9 hp) with 30 / 37 kW (40.2 / 49.6 hp) optional, and 3 kW and 4 kW axis motors. The LC-60 has 30 / 37 kW (40.2 / 49.6 hp) as standard and 4 kW and 7 kW axis motors.
04
The standard accessory is a 4-post square turret. The table lists 4 / 6 / 8 / 12 position turrets or a twin turret as an option, with auto indexing, direct mount or VDI tool posts and live tools as an option.
