Hyundai WIA KF5700
Key Specifications
Max Spindle
Spindle Taper
Table Size
Spindle Power
Accuracy
Repeatability
Overview
The Hyundai WIA KF5700 is a large-table 3-axis vertical machining center built for shops that regularly machine large prismatic components requiring a wide, long worksurface. With a 1,270 x 570 mm (50.0 x 22.4 in) table, 1,050/570/550 mm (X/Y/Z) travels, and a 12,000 RPM BT40 spindle with 22/18.5 kW (30/25 hp), the KF5700 targets the larger-format production VMC segment occupied by the Haas VF-4, Doosan DNM 5700, and DN Solutions NHP 5000.
The extended X-travel of 1,050 mm (41.3 in) and 570 mm Y-travel make the KF5700 suitable for multi-fixture pallets, tombstone fixturing, and large single-part setups that the smaller KF4600 cannot accommodate. Rapid traverse of 42 m/min (1,654 ipm) in X and Y, and 36 m/min (1,417 ipm) in Z, maintains competitive cycle times across long-travel programs.
A 30-tool arm-type ATC is standard, providing ample capacity for complex programs requiring many tool changes. The FANUC 0i-MF Plus control with nano-interpolation is standard, ensuring smooth surface finish and broad CAM compatibility. Hyundai WIA's reinforced one-piece cast iron column and T-slot table are designed to handle the higher workpiece weights and cutting forces typical of this table size.
At $140,000-$200,000 new, the KF5700 is priced competitively against comparable Haas VF-4 and Doosan DNM 5700 configurations. For aerospace, mold and die, and heavy equipment shops requiring a large-format VMC at a price point below European machines, the KF5700 delivers a strong value proposition with FANUC control and Korean manufacturing quality.
Full Specifications
| Parameter | Value |
|---|---|
| Table Size | 1,270 x 570 mm (50.0 x 22.4 in) |
| X Travel | 1,050 mm (41.3 in) |
| Y Travel | 570 mm (22.4 in) |
| Z Travel | 550 mm (21.7 in) |
| Max Spindle Speed | 12,000 RPM |
| Spindle Motor Power | 22/18.5 kW (30/25 hp) |
| Spindle Taper | BT40 |
| Spindle Type | Inline direct drive |
| Atc Capacity | 30 tools |
| Atc Type | Arm-type ATC |
| Guideway Type | Linear roller guides |
| Rapid Traverse Xy | 42 m/min (1,654 ipm) |
| Rapid Traverse Z | 36 m/min (1,417 ipm) |
| Max Workpiece Weight | 800 kg (1,764 lb) |
| Positioning Accuracy | ±0.005 mm (±0.0002 in) |
| Repeatability | ±0.003 mm (±0.00012 in) |
| Machine Weight | 46,402.46 kg |
| CNC Control | FANUC 0i-MF Plus |
| Tucson Hybrid | |
| 42075 As Shown | $41,295 as shown |
| Tucson Plug In Hybrid | |
| Ioniq 5 | |
| 45075 As Shown | $54,300 as shown |
| Santa Fe Hybrid | |
| 48700 As Shown | $47,850 as shown |
| Palisade Hybrid | |
| Ioniq 9 | |
| Elantra Hybrid | |
| 29800 As Shown | $29,800 as shown |
| Sonata Hybrid | |
| Sonata Gas Hybrid | |
| Ioniq 6 | |
| Venue | |
| 22825 As Shown | $23,450 as shown |
| Kona | |
| Tucson | |
| 39425 As Shown | $38,645 as shown |
| Santa Cruz | |
| 43700 As Shown | $42,750 as shown |
| Santa Fe | |
| 47600 As Shown | $46,850 as shown |
| Palisade | |
| 54560 As Shown | $51,000 as shown |
| Elantra | |
| 27175 As Shown | $26,775 as shown |
| 35100 As Shown | $34,350 as shown |
| Sonata | |
| 36050 As Shown | $35,500 as shown |
| Concept Vehicle | |
| Power | 329hp Combined |
| Available | 17inch Alloy wheels |
| Power Up To | 201 hp/150 kW |
| Combined | 139hp |
| Standard | HTRAC AWDHTRAC AWD is available on all trims. |
| Up To | 320 hp/239 kW320 hp/239 kW standard on AWD models. |
| Optional | HTRAC AWDHTRAC All Wheel Drive (AWD) available on all trims. |
| Manufacturer | Hyundai - Wia |
| Model | LV1100R |
| Horsepower | 30 hp |
| Spindle Bore | 4,500 mm |
Specifications sourced from machinio.com — verified 2026-03-28
Strengths & Limitations
Strengths
- 1,270 x 570 mm table with 1,050 mm X-travel accommodates large workpieces, multi-fixture pallets, and tombstone setups
- 22 kW (30 hp) spindle provides strong material removal capability for productive roughing in steel and cast iron
- 30-tool ATC offers broad tooling flexibility for complex programs without requiring a tool magazine expansion
- FANUC 0i-MF Plus control delivers operator familiarity and compatibility with all major CAM and DNC systems
- 42 m/min X/Y rapids reduce non-cutting time on long-travel programs involving multiple fixture positions
- One-piece reinforced cast iron column provides long-term rigidity and thermal stability for production accuracy
- Competitive pricing at $140K-$200K versus comparable Haas VF-4 and Doosan DNM 5700 configurations
Limitations
- BT40 taper is appropriate for 3-axis VMC work but limits torque at low RPM compared to BT50 machines in the same table class
- 12,000 RPM base speed is adequate for steel and aluminum but may benefit from optional higher-speed spindle for aggressive aluminum work
- Large footprint and 11,500 kg weight require significant floor space and load-bearing capacity — plan foundation requirements carefully
- Hyundai WIA's North American service network is smaller than Haas or Doosan, potentially affecting response times in some regions
- 30-tool ATC may still be limiting for very complex aerospace programs requiring 40+ unique tools — optional extended ATC may be required
Best For
Frequently Asked Questions
01
New KF5700 vertical machining centers typically sell in the $140,000-$200,000 range depending on options and regional dealer pricing. Used machines appear less frequently than compact VMCs due to lower production volumes, but are typically priced between $80,000-$130,000 in good condition. The KF5700 competes directly with the Haas VF-4 and Doosan DNM 5700.
02
The KF5600 features a 1,020 x 460 mm table with 600 mm X-travel, while the KF5700 steps up to a 1,270 x 570 mm table with 1,050 mm X-travel. The KF5700 is the appropriate choice when workpiece width or the need for multi-fixture pallet setups exceeds the KF5600's 460 mm Y-travel. The KF5700 is also heavier and requires more floor space.
03
Yes. The KF5700's 1,270 x 570 mm table with T-slots and 800 kg workpiece weight capacity is well suited for tombstone fixturing and multi-fixture pallets. Running multiple parts per cycle is a common strategy for improving utilization on this size machine. Shops running high-mix, low-volume work commonly use this approach to reduce setup-to-setup time.
04
The KF5700 provides ±0.005 mm (±0.0002 in) positioning accuracy and ±0.003 mm (±0.00012 in) repeatability — appropriate for production machining of precision components. For tighter tolerances, optional Heidenhain or Mitutoyo linear scales are available to upgrade to full-closed-loop feedback, improving accuracy to ±0.003 mm or better.
