Huron MTX 300
Image: huron.fr, Huron
Key Specifications
Max Spindle
Tool Capacity
Spindle Power
Max Turn Length
swing over bed
max turning diameter
How much does the Huron MTX 300 cost?
Price estimate
We do not have a price for the Huron MTX 300 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Huron MTX 300 is the heavy shaft machine of the MTX multi-tasking series. It comes in three bed lengths, turning 1,250/2,150/3,150 mm between centres with a 520 mm (20.5 in) swing, and its main spindle delivers 785/585 Nm.
That torque, from a 47/35 kW motor spindle on an A2-8 nose with a 304 mm chuck, is three times what the MTX 200 offers. If more is needed, the alternative main spindle is an A2-11 unit with a 115 mm bore, 51/37 kW and 1,902/1,380 Nm at 3,300 rpm. Such figures belong to oilfield tooling, landing-gear parts and large hydraulic components.
Milling is done by a B-axis spindle with HSK 63T tooling, 35/26 kW and 12,000 rpm, swivelling ± 110°. Y travel is ± 150 mm, which Huron highlights for off-centre machining. The main magazine holds 40 tools up to 500 mm long and 15 kg.
The MTX 300 is also equipped for deep-hole work. A separate sub tool magazine holds 6 tools up to 1,000 mm long and 100 kg, which is how long boring bars are loaded automatically. A servo-driven steady rest covers 8 to 101 mm with the lower turret in place and up to 360 mm without it. The tailstock is MT 5 with a 120 mm quill. Weight is 18,000/20,000/22,000 kg.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Bed | 520 mm (20.5 in) |
| Max Turning Diameter | 520 mm (20.5 in) (with milling spindle) |
| Max Turning Diameter Lower Turret | 350 mm (13.8 in) |
| Distance Main Spindle to Sub Spindle | 1,400/2,300/3,300 mm (55.1/90.6/129.9 in) |
| Max Turning Length | 1,250/2,150/3,150 mm (49.2/84.6/124.0 in) |
| Distance Main Spindle to Tailstock | 1,400/2,300/3,300 mm (55.1/90.6/129.9 in) |
| X1 Axis Travel | 620 (-20, +600) mm (24.4 (-0.8, +23.6) in) |
| Y Axis Travel | ± 150 mm (± 5.9 in) |
| Z1 Axis Travel | 1,250/2,150/3,150 mm (49.2/84.6/124.0 in) |
| X2 Axis Travel | 230 mm (9.1 in) |
| Z2 Z3 Axis Travel | 1,250/2,000/3,000 mm (49.2/78.7/118.1 in) |
| B Axis Range | ± 110° |
| Rapid Traverse X1 Y Z1 | 40/40/40 m/min |
| Rapid Traverse X2 Z2 | 26/30 m/min |
| Rapid Traverse Z3 | 30 m/min |
| B Axis Speed | 30 rpm |
| Main Spindle Nose | A2-8 |
| Chuck Size | 304 mm (12.0 in) |
| Spindle Bore | 77 mm (3.0 in) |
| Spindle Motor Power | 47/35 kW (63.0/46.9 hp) (S6-40% / S1 continuous) |
| Spindle Torque | 785/585 Nm (579.0/431.5 lb-ft) (S6-40% / S1 continuous) |
| Max Spindle Speed | 4,000 rpm |
| Alternative Main Spindle Nose | A2-11 |
| Alternative Main Spindle Chuck Size | 380 (450)* mm (15.0 (17.7)* in) |
| Alternative Main Spindle Bore | 115 mm (4.5 in) |
| Alternative Main Spindle Power | 51/37 kW (68.4/49.6 hp) (S6-40% / S1 continuous) |
| Alternative Main Spindle Torque | 1,902/1,380 Nm (1,402.9/1,017.9 lb-ft) (S6-40% / S1 continuous) |
| Alternative Main Spindle Speed | 3,300 rpm |
| Tailstock Taper | MT 5 |
| Tailstock Travel | 1,250/2,150/3,150 mm (49.2/84.6/124.0 in) |
| Tailstock Quill Diameter | 120 mm (4.7 in) |
| Sub Spindle Nose | A2-8 |
| Sub Spindle Chuck Size | 304 mm (12.0 in) |
| Sub Spindle Bore | 77 mm (3.0 in) |
| Sub Spindle Power | 47/35 kW (63.0/46.9 hp) (S6-40% / S1 continuous) |
| Sub Spindle Torque | 785/585 Nm (579.0/431.5 lb-ft) (S6-40% / S1 continuous) |
| Sub Spindle Speed | 4,000 rpm |
| Milling Spindle Taper | HSK 63T (CAPTO C6)* |
| Milling Spindle Power | 35/26 kW (46.9/34.9 hp) (S6-40% / S1 continuous) |
| Milling Spindle Torque | 167/125 (200)* Nm (123.2/92.2 (147.5)* lb-ft) (S6-40% / S1 continuous) |
| Milling Spindle Speed | 12,000 (6,000)* rpm |
| Turret Stations | 12 |
| Turret Tooling | VDI 50 |
| Live Tool Speed | 3,000 rpm |
| Live Tool Power | 8.8 kW (11.8 hp) |
| Live Tool Torque | 50/42 Nm (36.9/31.0 lb-ft) (S6-40% / S1 continuous) |
| Max Boring Bar Diameter | 50 mm (2.0 in) |
| Tool Capacity | 40 (80, 120)* |
| Max Tool Diameter (full magazine) | 90/160 mm (3.5/6.3 in) (all / adjacent empty) |
| Max Tool Length | 500 mm (19.7 in) |
| Max Tool Weight | 15 kg (33 lb) |
| Sub Magazine Tool Capacity | 6 |
| Sub Magazine Max Tool Diameter | 100 mm (3.9 in) |
| Sub Magazine Max Tool Length | 1,000 mm (39.4 in) |
| Sub Magazine Max Tool Weight | 100 kg (220 lb) |
| Steady Rest Diameter with Turret | 8 to 101 mm (0.3 to 4.0 in) |
| Steady Rest Max Diameter Without Turret | 360 mm (14.2 in) |
| Machine Weight | 18,000/20,000/22,000 kg (39,683/44,092/48,501 lb) |
Specifications sourced from huron.fr — verified 2026-10-04
Strengths & Limitations
Strengths
- Main spindle torque of 785/585 Nm, with a 1,902/1,380 Nm alternative
- Three bed lengths, up to 3,150 mm of turning length
- Y travel of ± 150 mm on the B-axis milling spindle
- Sub tool magazine for 6 tools up to 1,000 mm long
- Steady rest for 8 to 101 mm with the lower turret
Limitations
- B axis swivels at 30 rpm, half the rate of the MTX 200
- Lower turret and sub spindle rapids are 30 m/min
- Milling spindle uses HSK 63T, a small interface for a machine of this torque
- Long-bed versions weigh up to 22,000 kg
Best For
Frequently Asked Questions
01
Three: maximum turning length is 1,250/2,150/3,150 mm, and the distance between main spindle and sub spindle or tailstock is 1,400/2,300/3,300 mm. Machine weight is 18,000/20,000/22,000 kg.
02
Standard is an A2-8 spindle with a 304 mm chuck, 77 mm bore, 47/35 kW, 785/585 Nm and 4,000 rpm. The alternative is A2-11 with a 115 mm bore, 51/37 kW, 1,902/1,380 Nm and 3,300 rpm.
03
Through a sub tool magazine with 6 stations for tools up to 100 mm in diameter, 1,000 mm long and 100 kg. Huron's feature list describes an optional ATC for long boring bars and deep boring up to a metre.
04
A B-axis milling spindle with HSK 63T tooling, 35/26 kW and 12,000 rpm, swivelling ± 110° at 30 rpm. Travels are 620 mm in X1 and ± 150 mm in Y. A lower turret adds 12 driven stations on VDI 50 at up to 3,000 rpm.
