Makino MCD2016-5XA
Key Specifications
X Travel
Y Travel
Z Travel
Max Spindle
Spindle Taper
Tool Capacity
Overview
The Makino MCD2016-5XA is a precision 5-axis vertical machining center that extends the MCD platform's ultra-precision capabilities to a slightly larger work envelope. Designed for high-accuracy die and mold finishing, optical components, and precision medical devices, the 2016-5XA offers more travel than the MCD1516 while maintaining the same sub-micron accuracy class.
Axis travel of 200 x 150 x 150 mm (7.9 x 5.9 x 5.9 in) on X/Y/Z provides additional reach compared to the smaller MCD1516 variant, accommodating slightly larger precision components and multi-cavity mold inserts. The A-axis tilts through 180 degrees (+90 to -90) and the C-axis provides full 360-degree continuous rotation for complete 5-axis simultaneous machining capability.
The high-speed spindle runs at 40,000 RPM with an HSK-E32 taper, delivering 3.7 kW (5.0 hp) for micro-milling and ultra-fine finishing operations. Positioning accuracy of 0.5 microns and repeatability of 0.2 microns on linear axes place this machine firmly in the ultra-precision category. Glass scales on all axes provide direct position feedback.
The 200 x 150 mm (7.9 x 5.9 in) table handles workpieces up to 50 kg (110 lb), and the 20-tool magazine covers typical precision finishing tool requirements. Temperature-controlled construction with advanced thermal compensation maintains dimensional stability during extended finishing runs. The MCD2016-5XA sits between the smaller MCD1516 and the larger MCD2016-5XB in Makino's precision machining lineup, offering the best balance of precision and work envelope for medium-sized precision components.
Full Specifications
| Parameter | Value |
|---|---|
| X-Axis Travel | 200 mm (7.9 in) |
| Y-Axis Travel | 150 mm (5.9 in) |
| Z-Axis Travel | 150 mm (5.9 in) |
| A Axis Range | +90° to -90° (180° total) |
| C Axis Range | 360° (continuous) |
| Max Spindle Speed | 40,000 RPM |
| Spindle Taper | HSK-E32 |
| Spindle Motor Power | 3.7 kW (5.0 hp) |
| Tool Capacity | 30, (60,99,120) |
| Table Size | 200 x 150 mm (7.9 x 5.9 in) |
| Table Load Capacity | 50 kg (110 lb) |
| Positioning Accuracy | 0.5 µm |
| Repeatability | 0.2 µm |
| Rapid Traverse Xyz | 20 m/min (787 ipm) |
| Machine Weight | ~4,500 kg (9,921 lb) |
| CNC Control | Makino Professional 6 (Pro 6) |
| Eventscontent Librarywebinar Archiveownersmakino Expertisesafety Data Sheetsnewsroomfinancing | Financing OptionsMakino makes it easy to upgrade with flexible financing optionsLearn More |
| Metric | English |
| Pallet | 39.4" |
| A Axis | 115° (-100°to +15°) |
| B Axis | 360° |
| C Axis | None |
| Spindle Rpm | 6,000 rpm |
| Rapid Traverse Rate | 630 in/min |
| Cutting Feedrate | 630 in/min |
| Maximum Workpiece | Ø78.7" x 60" R |
| Maximum Payload | 5,060 lbs. |
| Maximum Tool Diameter | 11.81" |
Specifications sourced from makino.com — verified 2026-03-28
Strengths & Limitations
Strengths
- 200 x 150 mm travel extends the MCD platform's reach to accommodate larger precision components than the MCD1516
- 40,000 RPM HSK-E32 spindle enables ultra-fine finishing with micro-diameter tools for optical-quality surfaces
- 0.5 micron positioning accuracy with glass scales on all axes ensures sub-micron dimensional precision
- Temperature-controlled construction maintains thermal stability during extended precision machining cycles
- 50 kg table load provides additional capacity for heavier fixtures and workpiece materials
- 5-axis simultaneous capability enables complex freeform surfaces in a single setup without re-fixturing
Limitations
- 200 x 150 x 150 mm travel still limits workpiece size to small-to-medium precision components
- 3.7 kW spindle power is insufficient for roughing—this is strictly a semi-finishing and finishing platform
- 20-tool magazine is limited for parts requiring extensive tool variety
- Premium price of $400K-$550K reflects precision engineering rather than production capacity
- Requires temperature-controlled environment for optimal accuracy, adding facility infrastructure costs
Best For
Frequently Asked Questions
01
A new Makino MCD2016-5XA typically runs between $400,000 and $550,000 depending on configuration and options. The base machine starts around $400,000, with precision probing, enhanced thermal compensation, and automation adding to the price. The premium over the MCD1516-5XA reflects the larger travel envelope while maintaining the same ultra-precision accuracy specifications.
02
The primary difference is travel: the 2016-5XA offers 200 x 150 mm versus the 1516's 150 x 100 mm, providing 33% more X-travel and 50% more Y-travel. Table load increases from 30 kg to 50 kg. Both share the same 40,000 RPM spindle, sub-micron accuracy specifications, and control platform. Choose the 2016 if your precision components exceed the 1516's envelope; choose the 1516 if smaller parts fit and you want the lowest cost of entry.
03
The MCD2016-5XA machines a wide range of materials in precision finishing applications: hardened tool steels (up to 62 HRC), stainless steels, titanium alloys, cobalt-chrome, copper alloys, aluminum, brass, and engineering plastics. The 3.7 kW spindle and small tool diameters mean it excels at finishing rather than roughing. For hard materials, CBN and micro-grain carbide tooling at high RPM delivers excellent surface finishes.
04
The MCD2016-5XA routinely achieves mirror-quality surface finishes below Ra 0.1 µm on mold steels, with optical-quality finishes below Ra 0.05 µm possible on non-ferrous materials with optimized parameters. The 40,000 RPM spindle enables very fine step-overs at productive feed rates, and the sub-micron positioning accuracy ensures consistent surface quality across the entire machined surface.
