Hartford HSA-636EA

Q: How much does the Hartford HSA-636EA cost?

The price estimate for the Hartford HSA-636EA is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/hartford-hsa-636ea#price; the request is passed to Hartford or an authorised dealer.

Specs verified 2026-10-04 · hartfordcnc.com Updated 2026-10-04

Image: hartfordcnc.com, Hartford

Key Specifications

Spindle Taper

#50

Tool Capacity

A: 32 (40 / 60) pcs

Table Size

6,000 x 3,000 mm (236.2 x 118.1 in)

Spindle Power

18.5 / 22 opt. 30 / 35 kW (Cont. / 30 min)

max table load

24,000 kg (52,910 lb)

t slots

28 x 250 (23) mm

How much does the Hartford HSA-636EA cost?

Price estimate

Uncertain

We do not have a price for the Hartford HSA-636EA that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The Hartford HSA-636EA puts a 6,000 x 3,000 mm (236.2 x 118.1 in) table under a cross-beam with 3,600 mm (141.7 in) of Y travel. X travel is 6,000 mm (236.2 in), the table rating 24,000 kg (52,910 lb). It is a double-column five-face machine with linear guideways.

Both of Hartford's ballscrew support rules work in this model's favour. X support is standard because the machine is longer than 5 meters, and Y support is standard because it belongs to the HSA-x36 series. Buyers of the smaller or narrower models have to order one or both.

A table this large invites big single parts, but read the rating before planning the job: 24,000 kg is only 1,000 kg more than the narrower HSA-628EA carries. Large fabrications, mould frames and aluminium structures are comfortable here. A solid steel block covering the table is not.

Cutting is done by a #50 spindle, either a gear head at 6,000 rpm (8,000 rpm optional) or a 10,000 rpm hybrid, with 18.5 / 22 kW as standard and 30 / 35 kW optional. Automatic angular heads from the switching compartment handle the four sides, and Z travel is 1,000 mm or 1,200 mm.

Full Specifications

Parameter	Value
Table Size	6,000 x 3,000 mm (236.2 x 118.1 in)
Max Table Load	24,000 kg (52,910 lb)
T-Slots	28 x 250 (23) mm
X Axis Travel	6,000 mm (236.2 in)
Y Axis Travel	3,600 mm (141.7 in)
Z Axis Travel	1,000 (1,200) mm
Spindle Taper	#50
Spindle Speed Gear	6,000 (8,000) rpm
Spindle Speed Hybrid	10,000 rpm
Tool Capacity	A: 32 (40 / 60) pcs
Tool Shank	BT-50 (CAT-50 / DIN50 / BBT-50)
Spindle Motor Power	18.5 / 22 opt. 30 / 35 kW (Cont. / 30 min)

Specifications sourced from hartfordcnc.com — verified 2026-10-04

Strengths & Limitations

Strengths

6,000 x 3,000 mm (236.2 x 118.1 in) table with 3,600 mm (141.7 in) of Y travel
Ballscrew support standard on both X and Y, by Hartford's statements
24,000 kg (52,910 lb) table load
Optional 30 / 35 kW spindle motor for heavier cuts

Limitations

Load rating is low relative to the table area
Base spindle speed is 6,000 rpm; 8,000 rpm and the 10,000 rpm hybrid are separate choices
Standard Z travel of 1,000 mm limits tall parts once an angular head is mounted

Best For

Large mould frames and fabricated structures up to 6,000 x 3,000 mm Aluminium tooling and jigs for aircraft and rail Wide parts requiring accurate Y positioning

Frequently Asked Questions

01 What size is the HSA-636EA table?

6,000 x 3,000 mm (236.2 x 118.1 in), with twenty-three T-slots and a load rating of 24,000 kg (52,910 lb). Travels are 6,000 mm in X and 3,600 mm (141.7 in) in Y.

02 Are the ballscrews supported on the HSA-636EA?

On both horizontal axes, according to Hartford. X axis support is standard for models above 5 meters and Y axis support is standard for the HSA-x36 series, and this six-metre x36 machine meets both conditions.

03 How does the HSA-636EA compare with the HSA-736EA?

The HSA-736EA is a metre longer: a 7,000 x 3,000 mm (275.6 x 118.1 in) table with a 27,000 kg (59,524 lb) rating. Y travel is 3,600 mm on both, and the spindle and magazine options are the same.

04 What spindle speeds does the HSA-636EA offer?

6,000 rpm from the standard gear head, 8,000 rpm from the optional gear head and 10,000 rpm from the hybrid spindle. All use the #50 taper with BT-50 shanks, and Hartford states spindle deflection is within 5 μm.
