DN Solutions VC 630

$250,000 - $380,000 Updated 2026-03-12

Key Specifications

X Travel

762 mm (30 in)

Y Travel

510 mm (20 in)

Z Travel

560 mm (22 in)

Max Spindle

12,000 RPM (15,000 RPM optional)

Spindle Taper

BIG-PLUS CAT 40 (BT40)

Tool Capacity

30 (60, 90 optional)

Overview

The DN Solutions VC 630 is a high-performance vertical machining center designed for 5-axis simultaneous machining of complex parts in aerospace, medical, and precision mold applications. Built around a trunnion-style rotary tilting table with a 630 mm diameter, the VC 630 provides full 5-axis capability within a compact footprint. The A/C axis configuration enables complete part access in a single setup, dramatically reducing cycle times and improving accuracy by eliminating re-fixturing operations.

The VC 630 features a direct-drive 12,000 RPM spindle with 22 kW (30 hp) of power through a BIG-PLUS CAT 40 taper, delivering the speed and rigidity needed for both roughing and finishing in aluminum, steel, and titanium. Axis travels of 762 x 510 x 560 mm (30 x 20 x 22 in) combined with a 300 kg (661 lb) table load capacity make this machine well-suited for medium-sized 5-axis work. The roller linear guideways on all linear axes provide smooth motion and positioning accuracy essential for complex contour machining.

The FANUC 31i-B5 control with 5-axis simultaneous capability and AICC II (AI Contour Control) delivers smooth surface finishes on sculpted surfaces. With rapid traverse rates of 36 m/min (1,417 ipm) on X/Y/Z, the VC 630 keeps non-cutting time low. The machine competes with the DMG MORI CMX 70 U, Mazak VARIAXIS C-600, and Hermle C 250—delivering DN Solutions' proven build quality at a competitive price point for the 5-axis segment.

Full Specifications

Parameter	Value
X-Axis Travel	762 mm (30 in)
Y-Axis Travel	510 mm (20 in)
Z-Axis Travel	560 mm (22 in)
Travel A	+30° to -120°
Travel C	360° (continuous)
Max Spindle Speed	12,000 RPM (15,000 RPM optional)
Spindle Motor Power	22 kW (30 hp)
Spindle Torque	166 Nm (122 ft-lb)
Spindle Taper	BIG-PLUS CAT 40 (BT40)
Tool Capacity	30 (60, 90 optional)
Tool Change Time	1.5 sec (tool-to-tool)
Table Diameter	630 mm (24.8 in)
Table Load Capacity	300 kg (661 lb)
Rapid Traverse Xyz	36 m/min (1,417 ipm)
Guideway Type	Roller linear guideways
Machine Weight	8,500 kg (18,739 lb)
CNC Control	FANUC 31i-B5 with AICC II
Max Spindle Speed	12000r/min
X Axis Travel Distance	1270mm
Y Axis Travel Distance	670mm
Metric	IMPERIAL

Specifications sourced from dn-solutions.com — verified 2026-03-28

Strengths & Limitations

Strengths

Full 5-axis simultaneous capability with trunnion A/C axis enables complex part machining in a single setup
Direct-drive spindle provides smooth, vibration-free cutting at high speeds for superior surface finish quality
FANUC 31i-B5 with AICC II delivers advanced contour control for smooth sculpted surfaces in aerospace and medical parts
BIG-PLUS CAT 40 interface provides enhanced rigidity over standard CAT 40 for improved performance in harder materials
Competitive pricing versus European 5-axis machines (Hermle, DMG MORI) with comparable build quality

Limitations

300 kg table load capacity limits workpiece size compared to larger 5-axis platforms
CAT 40 taper limits heavy roughing capability versus CAT 50 or HSK-A100 5-axis machines
630 mm table diameter constrains maximum part envelope for larger aerospace components
Smaller dealer network for 5-axis service compared to DMG MORI or Mazak in North America

Best For

Aerospace shops machining complex aluminum and titanium components requiring 5-axis simultaneous contouring Medical device manufacturers producing implants, instruments, and complex geometries in a single setup Mold and die shops that need 5-axis access for deep-cavity molds and complex core geometries Contract manufacturers looking to add 5-axis capability at a competitive price point versus European machines

Frequently Asked Questions

01 What does a DN Solutions VC 630 cost?

A new DN Solutions VC 630 typically runs between $250,000 and $380,000 depending on configuration. The base machine with 12,000 RPM spindle and 30-tool ATC starts around $250,000-$280,000. Adding the 15,000 RPM spindle, through-spindle coolant, probing package, and expanded tool magazine pushes pricing to $300,000-$340,000. A fully loaded machine with 90-tool ATC, high-pressure coolant, and automation interface reaches $350,000-$380,000.

02 How does the VC 630 compare to the DMG MORI CMX 70 U?

Both are trunnion-style 5-axis VMCs targeting the same market segment. The DMG MORI CMX 70 U offers slightly larger axis travels and the CELOS control ecosystem, while the VC 630 delivers competitive specifications at a typically lower price point. The DN Solutions machine uses the proven FANUC 31i-B5 control, which many shops prefer for its reliability and industry-wide familiarity. The CMX 70 U benefits from DMG MORI's larger global service network.

03 Can the VC 630 machine titanium?

Yes. The VC 630's rigid construction, direct-drive spindle, and BIG-PLUS CAT 40 interface are well-suited for titanium machining. The high torque output at lower RPMs provides the cutting force needed for titanium roughing, while the 5-axis capability enables optimal tool engagement angles that reduce cutting forces and extend tool life. Through-spindle coolant is recommended for titanium work.

04 What CAM software works with the VC 630?

All major CAM packages support the VC 630 with FANUC 31i-B5. Mastercam, NX, CATIA, hyperMILL, and Fusion 360 all generate 5-axis toolpaths with appropriate post-processors. DN Solutions and their dealers can typically provide or recommend post-processors for the most common CAM systems. The FANUC 31i-B5 control supports standard G-code with 5-axis extensions.
