Dener DD-M-17535
Key Specifications
bending length
bending capacity
stroke
distance between tables
approach speed
bending speed
How much does the Dener DD-M-17535 cost?
Price estimate
We do not have a price for the Dener DD-M-17535 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Dener DD-M-17535 stretches Dener's servo electric press brake to a 3,570 mm (140.6 in) bending length with 175 ton behind it. Electric brakes of this length are less common than hydraulic ones, and the reason is mechanical: the servo drive has to hold a long beam parallel under load.
Dener's answer is the O-frame, which it credits with maximum rigidity and more precise bending, and a heavy build. This model weighs 11,500 kg (25,353 lb).
The 22 kW (29.5 hp) motor moves the ram at 90 mm/sec on approach and return and at 20 mm/sec in the bend. The stroke is 300 mm and the distance between tables 660 mm.
Floor planning needs attention. The machine is 5,340 mm long, far more than its bending length, 2,100 mm deep and 2,680 mm high, with a maximum height of 2,950 mm.
On a bed over three and a half metres, the optional equipment is where the machine is finished. Crowning (manual or automatic), a sheet follower for long panels and a backgauge with independent fingers are all extras. The standard machine has Y1, Y2, X and R.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Length | 3,570 mm (140.6 in) |
| Bending Capacity | 175 ton |
| Stroke | 300 mm (11.8 in) |
| Distance Between Tables | 660 mm (26 in) |
| Approach Speed | 90 mm/sec |
| Bending Speed | 20 mm/sec |
| Return Speed | 90 mm/sec |
| Motor Power | 22 kW (29.5 hp) |
| Machine Weight | 11,500 kg (25,353 lb) |
| Machine Length | 5,340 mm (210.2 in) |
| Machine Depth | 2,100 mm (82.7 in) |
| Machine Height | 2,680 mm (105.5 in) |
| Maximum Height | 2,950 mm (116.1 in) |
Specifications sourced from en.dener.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 3,570 mm bending length without hydraulics
- 175 ton maximum tonnage on an electric drive
- 90 mm/sec ram travel and 20 mm/sec bending speed
- O-frame that Dener credits with maximum rigidity
Limitations
- 5,340 mm overall length for a 3,570 mm bed
- Crowning and sheet follower are optional on a long machine
- Maximum stroke of 300 mm limits tall tooling
Best For
Frequently Asked Questions
01
The bending length is 3,570 mm (140.6 in) and the maximum tonnage is 175 ton. The machine itself is 5,340 mm long overall.
02
Approach speed and return speed are 90 mm/sec, and bending speed is 20 mm/sec. The DD-M-20040 above it travels at 75 mm/sec.
03
A 22 kW (29.5 hp) motor, on a 380 V, 50-60 Hz, 3-phase electrical system according to the standard equipment list. Cabinet cooling is included.
04
11,500 kg (25,353 lb). Depth is 2,100 mm, height 2,680 mm and maximum height 2,950 mm, so check the door and the crane before delivery.
