Citizen Miyano BNE-42SY6
Image: cmj.citizen.co.jp, Citizen Machinery
Key Specifications
power chuck sp1 sp2
maximum machining diameter of bar work sp1
maximum machining diameter of bar work sp2
standard turning length sp1
type of turret hd1
type of turret hd2
How much does the Citizen Miyano BNE-42SY6 cost?
Estimated price range
Our best estimate for a cnc lathes / turning center in this class — not a quote from Citizen Machinery. Configuration moves it a long way.
Overview
The Citizen Miyano BNE-42SY6 is the Y-axis version of the 42 mm BNE: a fixed-headstock lathe with two spindles, two 12-station turrets and ±40 mm of Y travel on the upper turret, HD1. Both spindles machine bar up to 42 mm dia.; SP1 turns at up to 6,000 rpm and SP2 at up to 5,000 rpm.
Y travel is the only row in which it differs from the Miyano BNE-42S6. Everything else in the table is shared: the 15/11 kW SP1 motor, the 5.5/3.7 kW SP2 motor, the 5" hydraulic chucks on both spindles, the strokes and the 7,600 kg weight. So the decision comes down to the part. If drawings show bolt circles off centre, keyways, hex or square flats, or cross holes that do not pass through the axis, the Y axis lets HD1 mill them in the same cycle instead of sending the part to a second machine.
Only HD1 has a Y row. HD2, the lower turret, works in X2 (145 mm) and Z2 (175 mm), so off-centre features belong on the HD1 side of the process plan. HD1 itself has 175 mm in X1 and 380 mm in Z1. Each turret can be fully equipped with revolving tools, 12+12 in total, taking 20 mm Sq. turning tools and 25 mm dia. tool holes.
The back spindle has 450 mm of travel, and the standard turning length on SP1 is 90 mm. Footprint is 2,690×2,160 mm and height 1,925 mm. For larger bar with the same Y arrangement, the Miyano BNE-51SY6 takes 51 mm dia. on SP1.
Full Specifications
| Parameter | Value |
|---|---|
| Power Chuck Sp1 Sp2 | 5"/5" hydraulic drive |
| Maximum Machining Diameter of Bar Work Sp1 | 42 mm dia. |
| Maximum Machining Diameter of Bar Work Sp2 | 42 mm dia. |
| Standard Turning Length Sp1 | 90 mm |
| Type of Turret Hd1 | 12St.Turret |
| Type of Turret Hd2 | 12St.Turret |
| Slide Stroke Hd1 X1 Axis | 175 mm |
| Slide Stroke Hd1 Z1 Axis | 380 mm |
| Slide Stroke Hd1 Y Axis | ±40 mm |
| Slide Stroke Hd2 X2 Axis | 145 mm |
| Slide Stroke Hd2 Z2 Axis | 175 mm |
| R Spindle Travel | 450 mm |
| Shank Height of Square Turning Tool | 20 mm Sq. |
| Tool Hole Diameter | 25 mm dia. |
| Maximum Number of Revolving Tools | 12+12 |
| Main Spindle Speed Range Sp1 | 6,000 rpm |
| Main Spindle Speed Range Sp2 | 5,000 rpm |
| Spindle Motor Sp1 | 15/11 kW |
| Spindle Motor Sp2 | 5.5/3.7 kW |
| Machine Height | 1,925 mm |
| Floor Space | 2,690×2,160 mm |
| Machine Weight | 7,600 kg |
Specifications sourced from cmj.citizen.co.jp — verified 2026-10-03
Strengths & Limitations
Strengths
- Y axis of ±40 mm on the HD1 turret for off-centre drilling, flats and keyways
- 42 mm dia. capacity on both SP1 and SP2, with a 5" hydraulic chuck on each
- Up to 12+12 revolving tools on two 12-station turrets
- SP1 at 6,000 rpm on a 15/11 kW motor
- 450 mm of travel on the back spindle
Limitations
- Y travel is only on HD1; the lower turret has no Y row in the table
- Bar capacity tops out at 42 mm dia., below the 51 mm dia. of the Miyano BNE-51SY6
- SP2 motor is 5.5/3.7 kW, so heavy back-end cuts are limited
- Weighs 7,600 kg and needs a 2,690×2,160 mm floor area
Best For
Frequently Asked Questions
01
HD1. The table lists ±40 mm of Y on the HD1 slide, together with 175 mm in X1 and 380 mm in Z1. HD2 is listed with X2 and Z2 strokes only, 145 mm and 175 mm, so plan off-centre milling on HD1.
02
No. The Miyano BNE-42S6 and the BNE-42SY6 share the 7,600 kg weight, the 1,925 mm height and the 2,690×2,160 mm floor space. The SY6 adds the ±40 mm Y axis on HD1 without changing the listed envelope.
03
The Miyano BNE-51SY6 has the same Y axis and turrets but takes 51 mm dia. bar on SP1 with a 6" chuck, runs SP1 to 5,000 rpm and weighs 7,800 kg. The BNE-42SY6 keeps 6,000 rpm on SP1 and matches SP2 to SP1 at 42 mm dia.
04
Up to 12 revolving tools on each of the two turrets, written 12+12 in the table. Turning tools are 20 mm Sq. and the tool hole diameter is 25 mm dia.
