Citizen Miyano ABX-51THY2
This model was not found in Citizen Machinery's current lineup when we checked on 2026-10-02 (lineup page). It may be a superseded or older model; the specifications below are as we last recorded them.
Key Specifications
Max Spindle
Tool Capacity
Spindle Power
max bar capacity
max work length
sub spindle speed
How much does the Citizen Miyano ABX-51THY2 cost?
Estimated price range
Our best estimate for a cnc lathes / turning center in this class — not a quote from Citizen Machinery. Configuration moves it a long way.
Overview
The Citizen Miyano ABX-51THY2 is a 51 mm (2.01 in) twin-spindle turning centre with three turrets and room for 36 tools, all of which may be revolving tools. Main spindle and sub-spindle each run to 5,000 rpm, each takes a 165 mm (6.50 in) power chuck, and each handles a maximum work length of 125 mm (4.92 in). It is not part of Citizen's current lineup.
Thirty-six tools is a lot of capacity for parts of this size. It means a family of similar parts can stay tooled up together, and a part that needs turning, cross drilling, milled flats and threading on both ends can be finished without sharing positions. Each turret indexes in 0.25 sec per position, the revolving tools run to 6,000 rpm with 40 Nm maximum from an AC 4.5 kW motor, and turning tools use 20 mm square shanks.
The Miyano ABX-51SYY2 is the two-turret version, with 24 tools, a 30 m/min Z rapid and a weight of 10,900 kg (24,030 lb). On this three-turret machine Z moves at 20 m/min, X at 16 m/min and Y at 12 m/min. The control is a FANUC 31i-B with 128 KB of storage, or 250 programs, double the 64 KB the two-turret version lists.
Power comes from a 15/11 kW main spindle motor and a 7.5/5.5 kW sub-spindle motor, through a 52 mm (2.05 in) main spindle bore. Installation needs a 49 kVA, 150 A supply, a 400 L coolant tank and space for a 3,290 × 2,204 mm (130 × 86.8 in) footprint at 11,350 kg (25,022 lb).
Full Specifications
| Parameter | Value |
|---|---|
| Max Bar Capacity | 51 mm (2.0 in) |
| Max Work Length | 125 mm (4.92 in) |
| Sub Spindle Speed | 5,000 rpm |
| Sub Spindle Power | AC 7.5 / 5.5 kW |
| Number of Turrets | 3 |
| Turret Stations | 3 |
| Max Live Tools | 36 |
| Live Tool Speed | 6,000 rpm |
| Live Tool Torque | 40 Nm max |
| Rapid Traverse X | 16 m/min |
| Rapid Traverse Z | 20 m/min |
| Rapid Traverse Y | 12 m/min |
| Machine Weight | 11,350 kg (25,022 lb) |
| CNC Control | FANUC 31i-B |
| NC Storage | 128 KB / 250 programs |
| Max Work Length Sp1 | 125 mm |
| Max Work Length Sp2 | 125 mm |
| Max Bar Diameter Sp1 | 51 mm |
| Max Bar Diameter Sp2 | 51 mm |
| Max Power Chuck Diameter Sp1 | 165 mm |
| Max Power Chuck Diameter Sp2 | 165 mm |
| Inner Dia of Draw Tube Sp1 | 52 mm |
| Inner Dia of Draw Tube Sp2 | â 52 mm |
| Chucking System Sp1 Sp2 | Hydraulic cylinder |
| Collet Chuck Type Sp1 | H-S22/177E |
| Collet Chuck Type Sp2 | H-S22 / DIN177E |
| Tool Shank Size | 20 mm Sq. |
| ID Tool Hole Size | 25 mm / 40 mm Dia. |
| Index Time | 0.25 SEC / 1 POS |
| Revolving Tools Max | 36 |
| Drilling Tapping Capacity | Max â 20 / Max M14x2 |
| Hd1 Hd2 | 16 / 20 / 12 |
| Hd3 | 16 / 20 / 12 |
| Sp2 Zs | 30 m / min |
| Spindle Motor Sp1 | AC 15 / 11 kW |
| Spindle Motor Sp2 | AC 7.5 / 5.5 kW |
| Revolving Tool Motor | AC 4.5 kW |
| Coolant Tank Capacity | 400 L |
| Hydraulic Lube Tank | 10 L / 4 L |
| Power Capacity Fuse | 49 KVA / 150A |
| Max Machining Length | 125 mm (4.92 in) |
| Bar Capacity | 51 mm (2.01 in) |
| Chuck Size | 165 mm (6.50 in) |
| Max Spindle Speed | 5,000 rpm |
| Spindle Bore | 52 mm (2.05 in) |
| Tool Capacity | 36 |
| Spindle Motor Power | AC 15 / 11 kW |
| Live Tool Power | AC 4.5 kW |
| Coolant Capacity | 400 L |
| Floor Space Required | 3,290 × 2,204 mm (130 × 86.8 in) |
| Power Consumption | 49 KVA / 150A |
Specifications sourced from marucit.com — verified 2026-09-24
Strengths & Limitations
Strengths
- Three turrets with a capacity of 36 tools, all of which can be revolving tools
- Both spindles run to 5,000 rpm and take 51 mm bar work and a 165 mm (6.50 in) power chuck
- FANUC 31i-B control with 128 KB of storage, or 250 programs
- Revolving tools at 6,000 rpm and 40 Nm maximum from an AC 4.5 kW motor
- 0.25 sec turret indexing per position
Limitations
- Z rapid is 20 m/min, against 30 m/min on the two-turret Miyano ABX-51SYY2
- 11,350 kg (25,022 lb) of machine needs a prepared floor
- Bar capacity is 51 mm (2.01 in); the Miyano ABX-64THY2 takes 64 mm (2.52 in)
- Maximum work length of 125 mm (4.92 in) excludes long shafts
- Requires a 49 kVA supply with a 150 A fuse
Best For
Frequently Asked Questions
01
36, spread over three turrets, and the table gives 36 as the maximum number of revolving tools as well. The two-turret Miyano ABX-51SYY2 holds 24. Each turret indexes in 0.25 sec per position.
02
The main spindle runs to 5,000 rpm on 15/11 kW with a 52 mm (2.05 in) bore. The sub-spindle also runs to 5,000 rpm, on 7.5/5.5 kW. Both take 51 mm bar work, a 165 mm power chuck and 125 mm of work length.
03
Same turret layout and 36 tools. The Miyano ABX-64THY2 takes 64 mm (2.52 in) bar through a 65.5 mm (2.58 in) bore with a 4,000 rpm main spindle, where the Miyano ABX-51THY2 takes 51 mm (2.01 in) bar at 5,000 rpm.
04
A 49 kVA supply with a 150 A fuse, 400 L of coolant, 10 L of hydraulic oil and 4 L of lubricant, and floor space of 3,290 × 2,204 mm (130 × 86.8 in) for a machine of 11,350 kg (25,022 lb).
05
No, Citizen does not list it in the current lineup. On a used machine, check how many of the 36 positions carry driven holders and confirm the control memory of 128 KB or 250 programs.
