Citizen Miyano ABX-51SYY2
This model was not found in Citizen Machinery's current lineup when we checked on 2026-10-02 (lineup page). It may be a superseded or older model; the specifications below are as we last recorded them.
Key Specifications
Max Spindle
Tool Capacity
Spindle Power
max bar capacity
max work length
sub spindle speed
How much does the Citizen Miyano ABX-51SYY2 cost?
Estimated price range
Our best estimate for a cnc lathes / turning center in this class — not a quote from Citizen Machinery. Configuration moves it a long way.
Overview
The Citizen Miyano ABX-51SYY2 is a twin-spindle, two-turret CNC turning centre for bar up to 51 mm (2.01 in), with matched spindles: both main and sub-spindle run to 5,000 rpm, both take a 165 mm (6.50 in) power chuck and both accept 51 mm bar work over a 125 mm (4.92 in) maximum work length. The main spindle is rated 15/11 kW and the sub-spindle 7.5/5.5 kW. Citizen no longer lists the model in its current lineup.
That symmetry is useful in practice. A part handed to the sub-spindle can be gripped on the same diameter it was cut from on the main side, in a chuck of the same size or in an H-S22 / DIN177E collet, so the second-side operation does not need a smaller step machined just for transfer. Both spindles are clamped by hydraulic cylinder, and the main spindle bore is 52 mm (2.05 in).
Two turrets carry up to 24 tools, all of which can be revolving tools rated at 6,000 rpm and 40 Nm maximum from an AC 4.5 kW motor. Rapids are 16 m/min on X, 30 m/min on Z and 12 m/min on Y. Tools are 20 mm square shank for turning and 25 mm or 40 mm diameter for boring holders, and drilling is listed to 20 with tapping to M14x2.
Against the three-turret Miyano ABX-51THY2, which holds 36 tools and weighs 11,350 kg (25,022 lb), this machine is lighter at 10,900 kg (24,030 lb) and keeps the faster Z axis. The FANUC 31i-B control here stores 64 KB, or 125 programs. The footprint is 3,290 × 2,204 mm (130 × 86.8 in) and the coolant tank holds 400 L.
Full Specifications
| Parameter | Value |
|---|---|
| Max Bar Capacity | 51 mm (2.0 in) |
| Max Work Length | 125 mm (4.92 in) |
| Sub Spindle Speed | 5,000 rpm |
| Sub Spindle Power | AC 7.5 / 5.5 kW |
| Number of Turrets | 3 |
| Turret Stations | 2 |
| Max Live Tools | 24 |
| Live Tool Speed | 6,000 rpm |
| Live Tool Torque | 40 Nm max |
| Rapid Traverse X | 16 m/min |
| Rapid Traverse Z | 30 m/min |
| Rapid Traverse Y | 12 m/min |
| CNC Control | FANUC 31i-B |
| NC Storage | 64 KB / 125 programs |
| Max Work Length Sp1 | 125 mm |
| Max Work Length Sp2 | 125 mm |
| Max Bar Diameter Sp1 | 51 mm |
| Max Bar Diameter Sp2 | 51 mm |
| Max Power Chuck Diameter Sp1 | 165 mm |
| Max Power Chuck Diameter Sp2 | 165 mm |
| Inner Dia of Draw Tube Sp1 | 52 mm |
| Inner Dia of Draw Tube Sp2 | â 52 mm |
| Chucking System Sp1 Sp2 | Hydraulic cylinder |
| Collet Chuck Type Sp1 | H-S22/177E |
| Collet Chuck Type Sp2 | H-S22 / DIN177E |
| Tool Shank Size | 20 mm Sq. |
| ID Tool Hole Size | 25 mm / 40 mm Dia. |
| Index Time | 0.25 SEC / 1 POS |
| Revolving Tools Max | 36 |
| Drilling Tapping Capacity | Max â 20 / Max M14x2 |
| Hd1 Hd2 | 16 / 20 / 12 |
| Hd3 | 16 / 20 / 12 |
| Sp2 Zs | 30 m / min |
| Spindle Motor Sp1 | AC 15 / 11 kW |
| Spindle Motor Sp2 | AC 7.5 / 5.5 kW |
| Revolving Tool Motor | AC 4.5 kW |
| Coolant Tank Capacity | 400 L |
| Hydraulic Lube Tank | 10 L / 4 L |
| Machine Weight | 10,900 kg (24,030 lb) |
| Power Capacity Fuse | 49 KVA / 150A |
| Max Machining Length | 125 mm (4.92 in) |
| Bar Capacity | 51 mm (2.01 in) |
| Chuck Size | 165 mm (6.50 in) |
| Max Spindle Speed | 5,000 rpm |
| Spindle Bore | 52 mm (2.05 in) |
| Tool Capacity | 24 |
| Spindle Motor Power | AC 15 / 11 kW |
| Live Tool Power | AC 4.5 kW |
| Coolant Capacity | 400 L |
| Floor Space Required | 3,290 × 2,204 mm (130 × 86.8 in) |
| Power Consumption | 48 KVA / 150A |
Specifications sourced from marucit.com — verified 2026-09-24
Strengths & Limitations
Strengths
- Main spindle and sub-spindle both run to 5,000 rpm and both take a 165 mm (6.50 in) power chuck
- 51 mm (2.01 in) bar capacity on both spindles with a 125 mm (4.92 in) maximum work length
- Up to 24 revolving tools on two turrets, rated at 6,000 rpm and 40 Nm maximum
- 30 m/min Z rapid, with 16 m/min on X and 12 m/min on Y
- Main spindle rated 15/11 kW, sub-spindle 7.5/5.5 kW
Limitations
- Tool capacity is 24, against 36 on the three-turret Miyano ABX-51THY2
- Program storage is 64 KB or 125 programs on this version of the FANUC 31i-B
- Bar capacity stops at 51 mm (2.01 in); the Miyano ABX-64SYY2 takes 64 mm (2.52 in)
- Weighs 10,900 kg (24,030 lb) and needs a 3,290 × 2,204 mm footprint
Best For
Frequently Asked Questions
01
In capacity, yes. Both take 51 mm bar work, a 165 mm power chuck and a 125 mm maximum work length, and both run to 5,000 rpm. They differ in power: the main spindle is rated 15/11 kW and the sub-spindle 7.5/5.5 kW.
02
The Miyano ABX-51THY2 has three turrets, 36 tools, a 20 m/min Z rapid and weighs 11,350 kg (25,022 lb). The Miyano ABX-51SYY2 has two turrets and 24 tools, moves Z at 30 m/min and weighs 10,900 kg (24,030 lb).
03
The main spindle is listed for H-S22/177E collets and the sub-spindle for H-S22 / DIN177E, both actuated by hydraulic cylinder. A 165 mm power chuck can be fitted on either spindle for chucked work.
04
Revolving tools run to 6,000 rpm with 40 Nm maximum torque from an AC 4.5 kW motor, and up to 24 can be mounted on the two turrets. Turret indexing takes 0.25 sec per position.
05
Citizen does not list it in the current lineup. On a used machine, confirm the turret tooling and the control memory, listed here as 64 KB or 125 programs on a FANUC 31i-B.
