Citizen Miyano BNE-51SY
Key Specifications
Max Spindle
Max Turn Length
max bar capacity sp1
max bar capacity sp2
main spindle speed
main spindle power
Overview
The Citizen Miyano BNE-51SY is a dual-spindle, twin-turret CNC turning center with Y-axis and 51mm bar, the previous-generation platform preceding BNE-51SY6. Widely installed across automotive, medical, and hydraulic manufacturing.
Main spindle: 5,000 RPM, 15/11 kW. Sub-spindle: 5,000 RPM, 5.5/3.7 kW, 42mm bar. Y-axis +/-40mm. Twin turrets with 24 live tools at 6,000 RPM.
Simultaneous machining provides 30-50% cycle time reductions. Y-axis on HD1 adds off-center machining for flats, keyways, and cross-holes.
Used BNE-51SY machines available as cost-effective entry to twin-turret Y-axis turning. Citizen continues full support.
Proven production platform with extensive installed base for shops seeking reliability at 51mm bar capacity.
Full Specifications
| Parameter | Value |
|---|---|
| Max Bar Capacity Sp1 | 51 mm (2.0 in) |
| Max Bar Capacity Sp2 | 42 mm (1.65 in) |
| Max Turning Length | 90 mm (3.54 in) |
| Main Spindle Speed | 5,000 RPM |
| Main Spindle Power | 15 / 11 kW (20 / 15 hp) |
| Sub Spindle Speed | 5,000 RPM |
| Sub Spindle Power | 5.5 / 3.7 kW (7.5 / 5 hp) |
| Number Of Turrets | 2 (HD1 + HD2) |
| Turret Stations | 12 + 12 (24 total) |
| Max Live Tools | 24 |
| Live Tool Speed | 6,000 RPM |
| Tool Shank Size | 20 mm square |
| Sub Spindle Travel Z3 | 450 mm (17.72 in) |
| Machine Weight | 7,800 kg (17,196 lb) |
| CNC Control | Mitsubishi M80 (Citizen Miyano) |
| Y Axis Stroke | +/-40 mm (80 mm total) |
| Machine Height | 1,925 mm (75.8 in) |
| Item | VIII |
| Max Machining Diameter | 32 mm Dia. |
| Max Machining Length | GB: 320 mm / 1 chucking, GBL: 2.5D |
| Max Front Drilling Diameter | 12 mm Dia. |
| Max Front Tapping Diameter | M12 |
| Spindle Through Hole Diameter | 39 mm Dia. |
| Max Chuck Diameter Of The Back Spindle | 32 mm Dia. |
| Max Protrusion Length Of The Back Spindle Workpiece | 80 mm |
| Max Protrusion Length | 150 mm |
| Max Drilling Diameter For The Back Spindle | 10 mm Dia. |
| Max Tapping Diameter For The Back Spindle | M10 |
| Gang Rotary Tool | 4 – 6 |
| Max Tapping Diameter | M6 |
| Max Spindle Speed | Max. 6,000 min⁻¹ (Rating: 3,000 min⁻¹) |
| Front Rotary Tool 2 | Max. drilling diameter |
| Number Of Tools To Be Mounted Max | 19 – 30 |
| Gang Turning Tool | 6 |
| Front Drilling Tool | 4 – 9 |
| Tool Size | Gang turning tool |
| Sleeve | 25.4 mm Dia. |
| Chuck And Bushing | Main spindle collet chuck |
| Rotary Tool Collet Chuck | ER11, ER16 |
| Chuck For Drill Sleeves | ER11, ER16 |
| Guide Bushing | FG531-M (FG581-M: 38 mm Dia. spec.) |
| Rapid Feed Rate | All axes (except Y2) |
| Motors | Spindle drive |
| Gang Tool Post Rotary Tool Drive | 1.0 kW |
| Front Rotary Tool Drive 2 | 1.0 kW |
| Coolant Oil | 0.4 kW |
| Lubricating Oil | 0.003 kW |
| Rated Power Consumption | 13.2 KVA |
| Full Load Current | 36 A |
| Main Breaker Capacity | 60 A |
| Air Pressure And Air Flow Rate For Pneumatic Devices | 0.5 MPa, 64.2 NL/min |
| Centre Height | 1,050 mm |
Specifications sourced from citizenmachinery.co.uk — verified 2026-03-28
Strengths & Limitations
Strengths
- [object Object]
- [object Object]
- [object Object]
- [object Object]
- [object Object]
- [object Object]
Limitations
- [object Object]
- [object Object]
- [object Object]
- [object Object]
Best For
Frequently Asked Questions
01
New: $180,000 - $260,000.
02
Same architecture plus +/-40mm Y.
03
IEMCA, LNS, FMB, Edge Technologies for 51mm bar.
04
Yes. 15/11 kW handles stainless, Inconel, titanium at 51mm.
