Brother Industries Vertical Machining Centers (VMC)

Brother TC-32BN

Est. $25,000 - $60,000 (used) Discontinued Specs verified 2026-10-03 · machinetool.global.brother Updated 2026-10-03

Key Specifications

X Travel

550 mm (21.7 in)

Y Travel

400 mm (15.7 in)

Z Travel

415 mm (16.3 in)

Max Spindle

12,000 rpm (16,000 rpm optional)

Tool Capacity

26 tools (+1)

Rapid Traverse

70 / 70 / 70 m/min (2,756 / 2,756 / 2,756 ipm)

How much does the Brother TC-32BN cost?

Estimated price range

Est.$25,000 - $60,000 (used)

Our best estimate for a vertical machining centers (vmc) in this class — not a quote from Brother Industries. Configuration moves it a long way.

Overview

The Brother TC-32BN is a tapping center with the longest X axis of the TC models compared here: 550 mm (21.7 in) of X, 400 mm (15.7 in) of Y and 415 mm (16.3 in) of Z, a 12,000 rpm spindle (16,000 rpm optional), a magazine of 26 tools (+1) and 70 m/min (2,756 ipm) rapids. Brother has discontinued the model.

It pairs the long X axis with the bigger magazine. The TC-22B uses the same spindle and rapids but holds 18 tools (+1) and has 500 mm (19.7 in) of X, while giving more Y at 450 mm (17.7 in). The TC-32BN is the one for long parts, or for several fixtures in a row along X, and for jobs that keep many tools loaded at once.

Coolant through the spindle is listed as an option. It helps deep drilling and blind tapping by flushing chips from the hole, but it is not standard, so on a used machine check whether it was ordered.

The footprint is 1,890 × 3,669 mm (74.4 × 144.4 in), large for a tapping center, so check the floor space and the route into the building before committing.

Full Specifications

Parameter	Value
Max Spindle Speed	12,000 rpm (16,000 rpm optional)
X-Axis Travel	550 mm (21.7 in)
Y-Axis Travel	400 mm (15.7 in)
Z-Axis Travel	415 mm (16.3 in)
Tool Capacity	26 tools (+1)
Rapid Traverse Rate	70 / 70 / 70 m/min (2,756 / 2,756 / 2,756 ipm)
Floor Space Required	1,890 × 3,669 mm (74.4 × 144.4 in)
Coolant Through Spindle	Optional

Specifications sourced from machinetool.global.brother — verified 2026-10-03

Strengths & Limitations

Strengths

550 mm (21.7 in) of X, the longest of the TC models listed beside it, including the 500 mm (19.7 in) TC-22B
26 tools (+1) in the magazine
70 m/min (2,756 ipm) rapids on X, Y and Z
415 mm (16.3 in) of Z for tall parts and long drills
Coolant through the spindle is available as an option for deep holes

Limitations

Y travel of 400 mm (15.7 in) is less than the 450 mm (17.7 in) of the TC-22B
Coolant through the spindle is optional, not standard
The 1,890 × 3,669 mm (74.4 × 144.4 in) footprint is large for a tapping center
Discontinued by Brother, so each used unit has to be checked for its spindle and options

Best For

Long parts or multi-fixture rows along 550 mm (21.7 in) of X Jobs that keep up to 26 tools (+1) loaded Deep drilling on machines fitted with coolant through the spindle

Frequently Asked Questions

01 How does the TC-32BN compare with the TC-22B?

Same spindle, 12,000 rpm with a 16,000 rpm option, and the same 70 m/min (2,756 ipm) rapids. The TC-32BN has 550 × 400 × 415 mm (21.7 × 15.7 × 16.3 in) of travel and 26 tools (+1). The TC-22B has 500 × 450 × 410 mm (19.7 × 17.7 × 16.1 in) and 18 tools (+1), so it wins only on Y.

02 Does the TC-32BN have coolant through the spindle?

Only as an option. A used machine may or may not have it, so check for the through-spindle supply before quoting deep drilling or blind tapping that relies on it. The standard spindle runs to 12,000 rpm and the optional one to 16,000 rpm.

03 How much floor space does the TC-32BN need?

Brother gives the footprint as 1,890 × 3,669 mm (74.4 × 144.4 in). Brother has discontinued the model, so when buying one used, also check the access route and doorway sizes before arranging transport.
