Amada TECHSTER 104
Key Specifications
standard chuck size
traverse travel
cross travel
spindle center height
wheel spindle power
grinding wheel size
Overview
The Amada TECHSTER 104 is the mid-range model in Amada’s TECHSTER series of CNC forming surface grinders, featuring a 1,000 x 400 mm standard chuck size for larger die blocks and tooling. It shares the ball screw with direct drive system for smooth backlash-free positioning on all three axes.
Axis travels span 1,200 mm (traverse) and 460 mm (cross), with a spindle center height of 750 mm -- significantly taller than the TECHSTER 84 at 500 mm, accommodating taller workpieces. The 7.5 kW (peak) / 4 kW (continuous) spindle drives the same 355 x 38-50 x 127 mm grinding wheels.
The larger table and longer traverse suit grinding progressive die plates, larger mold components, and precision parts exceeding the 800 mm capacity of the TECHSTER 84.
New TECHSTER 104 systems typically price between $150,000 and $250,000.
Full Specifications
| Parameter | Value |
|---|---|
| Standard Chuck Size | 800 x 400 |
| Traverse Travel | 1,200 mm (47.2 in) |
| Cross Travel | 460 mm (18.1 in) |
| Spindle Center Height | 750 mm (29.5 in) |
| Wheel Spindle Power | 7.5 kW peak / 4 kW continuous |
| Grinding Wheel Size | 355 x 38-50 x 127 mm |
| Drive System | Traverse |
| Model | TECHSTER 84 |
| Nc Control Axis | Simultaneous 2 Axis + 1 Axis |
| Travels | 1000/450 |
| Spindle Center Height From Table | 500 |
| Wheel Spindle | 7.5 ~ 4 |
| Wheel Spindle Grinding Wheel Size | 355 x 38 ~ 50 x 127 |
| Cross | Ball Screw Drive & Direct Drive |
| Vertical | Ball Screw Drive & Direct Drive |
Specifications sourced from amadamca.com — verified 2026-03-28
Strengths & Limitations
Strengths
- 1,000 x 400 mm table handles larger die blocks and progressive die plates
- 750 mm spindle center height accommodates taller workpieces than TECHSTER 84
- 1,200 mm traverse for grinding longer workpieces in a single setup
- Same 7.5 kW spindle and 355 mm wheel as the TECHSTER 84
- Ball screw with direct drive for consistent positioning accuracy
- Mid-range pricing between TECHSTER 84 and 126
Limitations
- Medium-duty precision does not match WINSTAR or MEISTER ultra-precision
- Same 400 mm table width as TECHSTER 84 -- the 126 offers 600 mm
- No published ATC or automation options
- Larger footprint than the TECHSTER 84
Best For
Frequently Asked Questions
01
TECHSTER 104 has larger table (1,000 x 400 mm vs 800 x 400 mm), longer traverse (1,200 vs 1,000 mm), and taller spindle (750 vs 500 mm). Same spindle power and wheel capacity.
02
Determines max workpiece height clearance. The 750 mm height accommodates taller workpieces, fixtures, and grinding approaches.
03
Yes. Both use 355 x 38-50 x 127 mm wheels with 7.5 kW peak spindle.
04
TECHSTER 104 at $150K-$250K vs $120K-$200K for the 84.
