Amada HRB 1303

$170,000 - $230,000 Updated 2026-03-19

Key Specifications

Press Capacity

1,300 kN / 130 metric tons (146 US tons)

Bending Length

3,100 mm (122 in)

Stroke

200 mm (7.9 in)

Open Height

440 mm (17.3 in)

Throat Depth

350 mm (13.8 in)

Approach Speed

200 mm/s (7.9 in/s)

Overview

The Amada HRB 1303 is a 130-ton, 3-meter hybrid servo-hydraulic press brake that extends the HRB series into heavier bending territory. With 1,300 kN of pressing force across a 3,100 mm bending length, the HRB 1303 provides 30% more tonnage than the HRB 1003 on the same bed length, enabling heavier gauge work on standard 10-foot sheets without stepping up to the significantly larger HRB 2204.

The hybrid servo-hydraulic drive system operates identically to the rest of the HRB series — servo motors control hydraulic pressure on demand, generating flow only during the bending stroke. This reduces energy consumption by up to 30% compared to conventional hydraulic press brakes and extends oil change intervals by reducing heat generation. Ram repeatability is ±0.01 mm for consistent bend quality across production shifts.

The AMNC 3i CNC control with a 15.6-inch touchscreen provides the same comprehensive programming environment as the rest of the HRB lineup, including bend simulation, automatic sequencing, collision checking, and VPSS 3i offline programming integration. The 6-axis backgauge and CNC automatic crowning compensate for table deflection across the full 3-meter bed.

The HRB 1303 fills the gap between the 100-ton HRB 1003 and the 220-ton HRB 2204, serving fabricators who regularly work with material thicknesses that push the HRB 1003 to its limits. Shops bending 6-8 mm mild steel, 5-6 mm stainless, or heavy aluminum on a 3-meter bed will find the extra 30 tons of the HRB 1303 provides comfortable overhead for consistent production without over-investing in the much larger HRB 2204.

Full Specifications

Parameter	Value
Press Capacity	1,300 kN / 130 metric tons (146 US tons)
Bending Length	3,100 mm (122 in)
Stroke	200 mm (7.9 in)
Open Height	440 mm (17.3 in)
Throat Depth	350 mm (13.8 in)
Approach Speed	200 mm/s (7.9 in/s)
Pressing Speed	10-20 mm/s (0.4-0.8 in/s)
Return Speed	200 mm/s (7.9 in/s)
Ram Repeatability	±0.01 mm (±0.0004 in)
Drive System	Hybrid servo-hydraulic
Control	Amada AMNC 3i (15.6-inch touchscreen)
Backgauge Axes	6-axis
Crowning	CNC automatic crowning
Energy Savings	Up to 30% vs conventional hydraulic
Machine Weight	Approximately 10,000 kg (22,046 lb)

Specifications sourced from amada.com — verified 2026-03-28

Strengths & Limitations

Strengths

130 tons provides 30% more bending force than the HRB 1003 on the same 3-meter bed, enabling heavier gauge work without oversizing to the HRB 2204
Hybrid servo-hydraulic drive reduces energy consumption up to 30% and extends maintenance intervals vs conventional hydraulic systems
AMNC 3i control with bend simulation, auto sequencing, and collision checking delivers the same programming environment across all HRB models
6-axis backgauge and CNC automatic crowning ensure consistent angles across the full 3-meter bending length on heavier material
Made in USA at Amada's North Carolina facility with strong domestic service support
Competitively priced below the HG series and all-electric EGB 1303e at comparable tonnage

Limitations

±0.01 mm ram repeatability is adequate for most work but less precise than the HG or EGB series at ±0.001 mm
No Automatic Tool Changer option — shops running high-mix work with frequent tool changes should consider the HG series
Amada proprietary tooling system restricts third-party punch and die options
AMNC 3i control is one generation behind the AMNC 4ie on the newer EGB-e series

Best For

Fabrication shops regularly bending 6-8 mm mild steel or 5-6 mm stainless on 3-meter sheets Structural and heavy fabricators who need more tonnage than 100 tons without the size and cost of a 220-ton machine Job shops handling mixed work from thin gauge through mid-heavy plate on a versatile 3-meter platform Shops upgrading from 100-ton machines that consistently operate near tonnage limits on heavier gauge work Fabricators prioritizing energy efficiency and domestic manufacturing in their 130-ton press brake selection

Frequently Asked Questions

01 When should I choose the HRB 1303 over the HRB 1003?

Choose the HRB 1303 if you regularly bend material thicker than 5 mm mild steel at full 3-meter bed length, or if your current 100-ton machine frequently operates near its tonnage limit. The 30% additional force provides comfortable overhead for heavier gauge work and reduces the need to recalculate tonnage when switching between materials.

02 What material thickness can the HRB 1303 bend at full length?

With 130 metric tons across 3,100 mm, the HRB 1303 air-bends mild steel up to approximately 8 mm at full bed length. Stainless capacity is approximately 6 mm. On shorter bends, proportionally thicker material can be handled within the tonnage limit.

03 How does the HRB 1303 compare to the EGB 1303e?

Both deliver 130 tons across 3 meters. The EGB 1303e is all-electric with ±0.001 mm repeatability, zero hydraulic maintenance, and the newer AMNC 4ie control. The HRB 1303 is hybrid servo-hydraulic with ±0.01 mm repeatability and the AMNC 3i. The EGB 1303e costs significantly more upfront but eliminates hydraulic maintenance entirely.

04 Can the HRB 1303 handle structural steel bending?

For light structural work — angle iron, channel, and flat bar within the tonnage and throat depth limits — yes. For heavy structural bending of thick plate, wide flanges, or beams, a purpose-built structural brake or a larger machine like the HRB 2204 or HG 8025 is more appropriate.
