Amada EGB 1303e
Image: amada.com, Amada
Key Specifications
control
press capacity
max bending length
distance between frames
open height
stroke
How much does the Amada EGB 1303e cost?
Estimated price range
Our best estimate for a cnc press brake in this class — not a quote from Amada. Configuration moves it a long way.
Overview
The Amada EGB 1303e is a 1300 kN press brake with a maximum bending length of 3110 mm, 2700 mm between the frames and 10 axes under the AMNC 4ie control. Its oil capacity is listed as 0 l, so there is no hydraulic oil to fill, change or dispose of.
The gap between 3110 mm of bending length and 2700 mm between frames matters for deep parts. A full-length bend fits over the bed, but a part that has to pass down between the side frames, such as a panel with deep return flanges, is limited to 2700 mm. The 450 mm throat depth gives room at the ends for work that overhangs the frames.
Tooling space comes in two heights. The standard machine has an open height of 520 mm, and a high body version raises that to 620 mm. Stroke is 250 mm. The high body is the one to look at for tall punches and deep box work.
The ram approaches and returns at 250 mm/s and bends at 25 mm/s. On long parts with few bends the handling time dominates, but on multi-bend parts the fast approach and return shorten each cycle.
The machine is 3980 mm long, 2120 mm wide and 3120 mm high, and it weighs 11400 kg. Check the 3120 mm height against door and crane clearances. For scale among Amada's brakes, the HFE-M2 130-3 is listed at 8150 kg and the HFE3 170-3 at 11600 kg, so plan the floor for a load close to the latter.
Full Specifications
| Parameter | Value |
|---|---|
| CNC Control | AMNC 4ie |
| Press Capacity | 1300 kN |
| Max Bending Length | 3110 mm |
| Distance Between Frames | 2700 mm |
| Open Height | 520 mm / 620 mm (high body) |
| Stroke | 250 mm |
| Throat Depth | 450 mm |
| Oil Capacity | 0 l |
| Approach Speed | 250 mm/s |
| Bending Speed | 25 mm/s |
| Return Speed | 250 mm/s |
| Number of Axes | 10 |
| Machine Length | 3980 mm |
| Machine Width | 2120 mm |
| Machine Height | 3120 mm |
| Machine Weight | 11400 kg |
Specifications sourced from amada.eu — verified 2026-10-03
Strengths & Limitations
Strengths
- 1300 kN over a maximum bending length of 3110 mm
- Oil capacity is listed as 0 l, so there is no hydraulic oil to maintain
- Approach and return speeds of 250 mm/s with a 25 mm/s bending speed
- A high body version raises open height from 520 mm to 620 mm
- 10 axes under the AMNC 4ie control, with a 450 mm throat depth
Limitations
- Distance between frames is 2700 mm, less than the 3110 mm bending length, which limits deep parts passing between the frames
- The standard open height is 520 mm, and 620 mm requires the high body version
- At 11400 kg and 3120 mm high it needs a floor and clearance check, against 8150 kg for the HFE-M2 130-3
- Stroke is 250 mm in the table, with no longer-stroke option listed
Best For
Frequently Asked Questions
01
Press capacity is 1300 kN and the maximum bending length is 3110 mm. The distance between frames is 2700 mm and throat depth is 450 mm, so parts longer than 2700 mm cannot drop between the side frames.
02
Open height. Amada lists 520 mm for the standard machine and 620 mm for the high body. The table gives a single stroke of 250 mm. Choose the high body where tall tooling or deep boxes need the extra opening.
03
Amada lists the oil capacity as 0 l. The table does not describe the drive in more detail, but a 0 l oil capacity means there is no oil tank to fill or service on this machine.
04
Approach speed is 250 mm/s, bending speed is 25 mm/s and return speed is 250 mm/s. The bending speed is a tenth of the approach speed, so cycle time on short strokes is set mostly by how far the ram has to open.
