Yawei PBH(A)-2500/12000
Key Specifications
bending force
table length
distance between columns
throat depth
ram stroke
max opening height
How much does the Yawei PBH(A)-2500/12000 cost?
Price estimate
We do not have a price for the Yawei PBH(A)-2500/12000 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Yawei PBH(A)-2500/12000 is rated at 25,000 kN on a 12,000 mm (472.4 in) table, second from the top of the PBH(A) series.
Its envelope is the largest Yawei lists. The throat opening reaches 1,500 mm (59.1 in) and the maximum opening height 1,900 mm (74.8 in), with a slider stroke of 600 mm (23.6 in). The top model, the PBH(A)-3000/12000, prints the same three figures, so in working space the two are equals and force is the only reason to go higher.
From the PBH(A)-2000/12000 the machine inherits its drive unchanged: 2 x 75 kW and a 3,600 L tank. More force on equal power shows up in the return speed. The slider row reads 70 mm/s; 7 mm/s; 50 mm/s, where the PBH(A)-2000/12000 returns at 60 mm/s.
The frame is the widest in the table. Overall dimensions are 12,200 x 5,300 x 9,900 mm (480.3 x 208.7 x 389.8 in). Column spacing is 9,500 mm (374.0 in). Weight is not printed.
A throat a metre and a half deep is an unusual thing on a press brake. It allows a twelve-metre plate to be fed a long way into the machine, so that wide plates can be bent near their centre line. That is what large open troughs and big-radius shells need. Yawei does not publish application examples by model; its list for the series names engineering machinery, railway and metal curtain wall work among others.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Force | 25,000 kN |
| Table Length | 12,000 mm (472.4 in) |
| Distance Between Columns | 9,500 mm (374.0 in) |
| Throat Depth | 1,500 mm (59.1 in) |
| Ram Stroke | 600 mm (23.6 in) |
| Max Opening Height | 1,900 mm (74.8 in) |
| Ram Speed | 70 mm/s; 7 mm/s; 50 mm/s |
| Main Motor Power | 2 x 75 kW |
| Oil Tank Volume | 3,600 L |
| Machine Dimensions | 12,200 x 5,300 x 9,900 mm (480.3 x 208.7 x 389.8 in) |
Specifications sourced from en.yawei.cc — verified 2026-10-05
Strengths & Limitations
Strengths
- Throat opening of 1,500 mm (59.1 in), the deepest in the series
- Maximum opening height of 1,900 mm (74.8 in)
- 25,000 kN over a 12,000 mm (472.4 in) table
- Motors and oil tank no larger than on the PBH(A)-2000/12000
- 9,500 mm (374.0 in) between the columns
Limitations
- Return speed of 50 mm/s, down from the PBH(A)-2000/12000
- Widest frame in the table
- No machine weight is printed by Yawei
- Stroke of 600 mm (23.6 in), a third of the opening height
Best For
Frequently Asked Questions
01
25,000 kN of nominal force on a 12,000 mm (472.4 in) table. Throat opening is 1,500 mm (59.1 in), slider stroke 600 mm (23.6 in), maximum opening height 1,900 mm (74.8 in) and column spacing 9,500 mm (374.0 in).
02
No. The PBH(A)-3000/12000 lists the same throat, stroke and opening height, with 30,000 kN, motors printed as 2 x 90 kW and a tank of 4,200 L.
03
The motor row is printed as 2 x 75 kW, which reads as two main motors. The oil tank volume is 3,600 L and slider speeds are 70 mm/s; 7 mm/s; 50 mm/s.
04
Yawei lists 12,200 x 5,300 x 9,900 mm (480.3 x 208.7 x 389.8 in) for length, width and height. The total weight row is empty apart from a slash, so no weight can be quoted.
