Takisawa TCN-2100

Specs verified 2026-10-03 · takisawa.co.jp Updated 2026-10-03

Image: takisawa.co.jp, Takisawa

Key Specifications

Max Spindle

3,200 rpm (option 5,000 rpm)

Rapid Traverse

X 24 / Z 30 m/min (945 / 1,181 in/min)

Spindle Power

11 / 9 kW (14.8 / 12.1 hp), 30-min, S3 60% / continuous

Max Turn Length

L3: 300 mm (11.8 in); L6: 600 mm (23.6 in); TCN-2100CM L3 / L6: 208 / 508 mm (8.2 / 20.0 in)

chuck size

8 in (203 mm)

bed lengths

L3 and L6; turning (TCN-2100) and turning & milling (TCN-2100CM) versions

How much does the Takisawa TCN-2100 cost?

Price estimate

Uncertain

We do not have a price for the Takisawa TCN-2100 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

The Takisawa TCN-2100 is an 8 in (203 mm) chuck CNC lathe that comes as four machines in one family: two bed lengths, L3 and L6, each as a turning lathe or as the TCN-2100CM for turning and milling. The headline figures are 410 mm (16.1 in) of turning diameter, 600 mm (23.6 in) of turning length on the long bed and an 11 kW (14.8 hp) spindle motor.

The L3 turns 300 mm (11.8 in) and the L6 twice that. The long bed adds to one side of the footprint only, 2,095 × 1,532 mm (82.5 × 60.3 in) against 1,750 × 1,532 mm (68.9 × 60.3 in), and takes the weight from 2,700 kg (5,952 lb) to 3,200 kg (7,055 lb). With 600 mm of turning length and a hydraulic tailstock only on the options list, anyone buying the L6 for shaft work should add the tailstock to the order.

Choosing the TCN-2100CM changes the envelope more than the name suggests. Its 12-station rotary-tool turret drives tools at 6,000 rpm with 5.5 kW (7.4 hp) on the 15-min rating and 3.7 kW (5.0 hp) continuous, but the maximum turning diameter drops to 280 mm (11.0 in) and turning length to 208 mm (8.2 in) on the L3 or 508 mm (20.0 in) on the L6. The CM machines weigh 2,800 and 3,300 kg. The table gives no Y-axis travel, so check what the milling version can reach before planning off-centre features around it.

On the turning machines the turret is a direct-mount type with 8 stations as standard and 12 as an option, and the larger turret limits turning diameter to 340 mm (13.4 in). The spindle runs to 3,200 rpm, or 5,000 rpm as an option, and the motor is rated 11 kW at 30-min, S3 60%, and 9 kW (12.1 hp) continuous. Bar capacity is 51 mm (2.0 in), depending on chuck and cylinder. Rapids are X 24 / Z 30 m/min (945 / 1,181 in/min).

For automation Takisawa lists the TCN-2100G with a gantry loader: workpieces up to φ160 × 100 mm and 3 kg, marked ×2 in the table, and a 16-pallet stocker at 40 kg per pallet with a 450 mm stacking height.

Full Specifications

Parameter	Value
Chuck Size	8 in (203 mm)
Bed Lengths	L3 and L6; turning (TCN-2100) and turning & milling (TCN-2100CM) versions
Turret Stations	8 stations standard, 12 stations optional (direct-mount); 12-station rotary-tool turret on TCN-2100CM
Max Turning Diameter	410 mm (16.1 in) with 8-station turret; 340 mm (13.4 in) with 12-station turret; 280 mm (11.0 in) on TCN-2100CM
Max Turning Length	L3: 300 mm (11.8 in); L6: 600 mm (23.6 in); TCN-2100CM L3 / L6: 208 / 508 mm (8.2 / 20.0 in)
Bar Capacity	51 mm (2.0 in) (depends on chuck and cylinder)
Max Spindle Speed	3,200 rpm (option 5,000 rpm)
Spindle Motor Power	11 / 9 kW (14.8 / 12.1 hp), 30-min, S3 60% / continuous
Live Tool Speed	6,000 rpm (TCN-2100CM)
Live Tool Power	5.5 / 3.7 kW (7.4 / 5.0 hp), 15-min / continuous (TCN-2100CM)
Rapid Traverse Rate	X 24 / Z 30 m/min (945 / 1,181 in/min)
Tailstock	Hydraulic tailstock (optional)
Machine Dimensions	L3: 1,750 × 1,532 mm (68.9 × 60.3 in); L6: 2,095 × 1,532 mm (82.5 × 60.3 in); height 1,700 mm (66.9 in)
Machine Weight	L3: 2,700 kg (5,952 lb); L6: 3,200 kg (7,055 lb) (TCN-2100CM: 2,800 / 3,300 kg)
Automation Version	TCN-2100G gantry loader: workpiece up to φ160 × 100 mm, 3 kg (×2); 16-pallet stocker, 40 kg per pallet, 450 mm stacking height

Specifications sourced from takisawa.co.jp — verified 2026-10-03

Strengths & Limitations

Strengths

600 mm (23.6 in) of turning length on the L6 bed, twice the 300 mm (11.8 in) of the L3, on the same 1,532 mm (60.3 in) depth
410 mm (16.1 in) maximum turning diameter with the standard 8-station direct-mount turret
TCN-2100CM version adds a 12-station rotary-tool turret with 6,000 rpm driven tools
9 kW (12.1 hp) continuous spindle rating, against 7.5 kW (10.1 hp) on the TCC-2100
TCN-2100G version pairs the lathe with a gantry loader and a 16-pallet stocker

Limitations

The TCN-2100CM turns only 280 mm (11.0 in) in diameter and 208 / 508 mm (8.2 / 20.0 in) in length, well under the turning-only figures
The optional 12-station turret reduces turning diameter to 340 mm (13.4 in)
Hydraulic tailstock is optional even on the 600 mm (23.6 in) L6 bed
Bar capacity is 51 mm (2.0 in); the TCN-2600 passes 74 mm (2.9 in)

Best For

Shaft and long-part turning up to 600 mm (23.6 in) on the L6 bed Chucking work up to 410 mm (16.1 in) in diameter with the 8-station turret Turned parts with drilled or milled features on the TCN-2100CM, within 280 mm (11.0 in) Bar work up to 51 mm (2.0 in), depending on chuck and cylinder Loader-fed runs of parts up to 3 kg on the TCN-2100G

Frequently Asked Questions

01 What do L3 and L6 mean on the TCN-2100?

They are the two bed lengths. The L3 has 300 mm (11.8 in) of maximum turning length and the L6 has 600 mm (23.6 in). Floor space is 1,750 × 1,532 mm (68.9 × 60.3 in) for the L3 and 2,095 × 1,532 mm (82.5 × 60.3 in) for the L6, both 1,700 mm (66.9 in) high. Weight is 2,700 kg (5,952 lb) and 3,200 kg (7,055 lb).

02 What changes on the TCN-2100CM turning and milling version?

The turret becomes a 12-station rotary-tool turret with tools driven at up to 6,000 rpm by a 5.5 / 3.7 kW (7.4 / 5.0 hp) motor, 15-min against continuous. The working envelope shrinks: 280 mm (11.0 in) of turning diameter, and 208 mm (8.2 in) of turning length on the L3 or 508 mm (20.0 in) on the L6. Weight is listed as 2,800 kg for the L3 and 3,300 kg for the L6.

03 What is the spindle rating of the TCN-2100?

The motor is listed at 11 / 9 kW (14.8 / 12.1 hp), where the higher figure is the 30-min, S3 60% rating and the lower one is continuous. Maximum speed is 3,200 rpm on the standard spindle, and a 5,000 rpm spindle is optional. Bar capacity is 51 mm (2.0 in), which the table says depends on the chuck and cylinder.

04 How is the TCN-2100 different from the TCN-2600?

The TCN-2600 carries a 10 in (254 mm) chuck and passes 74 mm (2.9 in) bar, with 90 mm (3.5 in) as an option, but its turning lengths are shorter at 250 mm (9.8 in) and 550 mm (21.7 in). The TCN-2100 has the 8 in (203 mm) chuck, 51 mm (2.0 in) of bar capacity, and 300 mm and 600 mm of turning length. Both list an 11 / 9 kW motor, 3,200 rpm as standard and the same weights, so the choice is about chuck and bar size.

05 Does the TCN-2100 come with a tailstock?

No. The table lists a hydraulic tailstock as optional. On the L3 bed, with 300 mm (11.8 in) of turning length, many chucking jobs will not need one. On the L6 bed, with 600 mm (23.6 in), slender parts generally need tail support, so the tailstock should be specified at order.
