Pullmax P9 CNC Turret Punch Press
This model was not found in Pullmax's current lineup when we checked on 2026-10-03 . It may be a superseded or older model; the specifications below are as we last recorded them.
Key Specifications
punching force
sheet size
sheet thickness
turret stations
drive
stroke rate
How much does the Pullmax P9 CNC Turret Punch Press cost?
Estimated price range
Our best estimate for a cnc punch presse in this class — not a quote from Pullmax. Configuration moves it a long way.
Overview
The Pullmax P9 is a hydraulic CNC turret punch press listed at 30 ton (300 kN) of punching force, for sheets up to 2500x1250 mm (98x49 in). It is not in Pullmax's current lineup, so the listed figures are a guide for assessing a used machine and should be confirmed on the machine itself.
The frame is a C-frame and the punching drive is hydraulic. Sheet thickness is listed as 0.5 – 6.0 mm in mild steel, and that range should be read together with the punching force. The force a hole needs grows with its perimeter and with the sheet thickness, so the largest tools in the turret will not punch the full 6.0 mm. No thickness limit is listed for stainless or aluminium.
The turret has 33 stations, a count that includes multi-tool positions. The number of full-size stations is therefore lower, and worth checking against the tooling a job needs. Stroke rate is listed as up to 400 strokes/min and repositioning speed as 90 m/min. The top stroke rate applies to short moves between hits, as in nibbling. Widely spaced holes are paced by repositioning instead.
An automatic waste conveyor is listed for slugs, which saves stopping to clear scrap on long runs. The listed figures include a CNC control but give no station sizes, no auto-index stations and no machine weight or floor area.
Full Specifications
| Parameter | Value |
|---|---|
| Punching Force | 30 ton (300 kN) |
| Sheet Size | Up to 2500x1250 mm (98x49 in) |
| Sheet Thickness | 0.5 – 6.0 mm mild steel |
| Turret Stations | 33 (including multi-tool positions) |
| Drive | Hydraulic C-frame |
| Stroke Rate | Up to 400 strokes/min |
| Repositioning Speed | 90 m/min |
| CNC Control | Delem DA-65T |
| Frame | C-frame hydraulic |
| Slug System | Automatic waste conveyor |
Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.
Strengths & Limitations
Strengths
- 30 ton (300 kN) punching force on a hydraulic C-frame
- Takes sheets up to 2500x1250 mm (98x49 in)
- 33 turret stations, including multi-tool positions
- Up to 400 strokes/min with 90 m/min repositioning
- Automatic waste conveyor for slug removal
Limitations
- Sheet thickness tops out at 6.0 mm in mild steel; no figure is listed for stainless or aluminium
- The 33-station count includes multi-tool positions, so fewer full-size stations are available
- Not in Pullmax's current lineup; confirm the listed figures and the state of the hydraulics on the machine itself
- No station sizes, auto-index stations or machine weight appear in the listed figures
Best For
Frequently Asked Questions
01
The listed figures give a sheet size up to 2500x1250 mm (98x49 in) and a thickness range of 0.5 – 6.0 mm in mild steel. No thickness is listed for other materials. Punching force is 30 ton (300 kN), which limits how large a hole can be punched in the thickest sheet.
02
The turret is listed with 33 stations, and that count includes multi-tool positions. The listed figures do not break the stations down by size or say whether any of them index, so check the turret layout on the machine against the tooling you plan to run.
03
Stroke rate is listed as up to 400 strokes/min and repositioning speed as 90 m/min. The stroke figure is a maximum that applies to closely spaced hits. On parts with widely spaced holes, the time between hits is set by how far the sheet has to move.
04
The drive is hydraulic, so look at the condition of the hydraulic unit, hoses and seals. Count the usable turret stations, since the listed 33 includes multi-tool positions. Confirm the 30 ton (300 kN) rating on the machine plate, and run the automatic waste conveyor.
