Palmary VIG-120
Image: palmary.com, Palmary
Key Specifications
Max Spindle
Spindle Taper
Table Size
o d grinding range
max o d grinding length
swing diameter
How much does the Palmary VIG-120 cost?
Price estimate
We do not have a price for the Palmary VIG-120 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Palmary VIG-120 is Palmary's largest CNC vertical grinder. Its face plate is Ø1,250 mm (49.2 in), it grinds outside diameters from Ø65 to 1,200 mm, and it carries workpieces of up to 5,000 kg (11,023 lb).
That load figure is five times the VIG-80's, and it comes from a different table bearing. The standard accessory list gives the VIG-120 alone a hydrostatic working table, with its own oil tank, pump and coolant chiller. A hydrostatic table floats the load on an oil film, which is how a rotary table carries five tonnes and still turns smoothly at grinding speeds. Table speed is 10 to 100 rpm from a 5.5 kW (7.4 hp) motor.
Above the table the machine is close to the VIG-80. The built-in spindle is 22 kW (29.5 hp), 1,800 to 10,000 rpm, on HSK-E100 holders, with wheels of Ø60 to 305 mm and an automatic changer for up to 6 of them. Z travel is 700 mm (27.6 in). The difference is X, which grows to 2,252 mm (88.7 in) so that a wheel can work on either side of a ring more than a metre across.
Maximum workpiece length and outside grinding length are both 500 mm (19.7 in). Palmary's table entry for bore depth on this model is garbled, so ask for it. The machine weighs 16,000 kg (35,273 lb), holds 1,200 L (317.0 gal) of coolant and needs 42 kVA. Control is FANUC with gap control.
Full Specifications
| Parameter | Value |
|---|---|
| O D Grinding Range | Ø65~1,200 mm |
| Max O D Grinding Length | 500 mm (19.7 in) |
| Swing Diameter | Ø1,250 mm (49.2 in) |
| Max Workpiece Length | 500 mm (19.7 in) |
| Max Workpiece Load | 5,000 kg (11,023 lb) |
| Distance Spindle Upper Side to Wheel | 670 mm (26.4 in) |
| Max Spindle Speed | 1,800-10,000 rpm |
| Wheel Diameter | Ø60~305 mm |
| Wheel Peripheral Speed | 45 m/s (8,858 ft/min) |
| Spindle Taper | HSK-E100 |
| Table Size | Ø1,250 mm (49.2 in) |
| Work Spindle Speed | 10-100 rpm |
| X Axis Travel | 2,252 mm (88.7 in) |
| X Axis Feed Speed | 0-10 m/min (0-394 ipm) |
| X Axis Min Setting Unit | 0.0001 mm |
| X Axis Mpg Increments | 0.0001, 0.001, 0.05 mm |
| Z Axis Travel | 700 mm (27.6 in) |
| Z Axis Feed Speed | 0-10 m/min (0-394 ipm) |
| Z Axis Min Setting Unit | 0.0001 mm |
| Z Axis Mpg Increments | 0.0001, 0.001, 0.05 mm |
| Slide Ways | Linear guideway |
| Workhead Motor | 5.5 kW (7.4 hp) |
| Wheel Spindle Motor | 22 kW (29.5 hp) |
| X Axis Motor | 7 kW (9.4 hp) |
| Z Axis Motor | 7 kW (9.4 hp) |
| ATC Motor | 1.4 kW (1.9 hp) |
| High Pressure Coolant Pump Motor | 0.375 & 2.1 kW |
| Hydraulic Pump Motor | 0.75 kW (1.0 hp) |
| Power Requirement | 42 kVA |
| Air Supply | 0.7 MPa & 2,400 NL/min |
| Coolant Tank | 1,200 L (317.0 gal) |
| Machine Weight | 16,000 kg (35,273 lb) |
| CNC Control | FANUC CNC controller (included current gap control function) |
Specifications sourced from palmary.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 5,000 kg (11,023 lb) workpiece load on a hydrostatic working table
- Ø1,250 mm (49.2 in) face plate; outside diameters to 1,200 mm
- 2,252 mm (88.7 in) of X travel
- 22 kW (29.5 hp) HSK-E100 spindle with a 6-wheel automatic changer
- Chiller for the hydrostatic table oil is a standard accessory
Limitations
- Workpiece length limited to 500 mm (19.7 in) despite the large diameter
- Palmary's table does not give a clear bore depth for this model
- 16,000 kg (35,273 lb) and 42 kVA, plus 2,400 NL/min of air
- Z travel of 700 mm (27.6 in) is the same as on the VIG-80
Best For
Frequently Asked Questions
01
Outside diameters from Ø65 to 1,200 mm on a Ø1,250 mm (49.2 in) face plate, with a workpiece length up to 500 mm (19.7 in) and a load of up to 5,000 kg (11,023 lb).
02
It is hydrostatic. Palmary's standard accessories list a hydrostatic working table, an oil tank with pump for the hydrostatic rotary table and a coolant chiller for it, each marked for the VIG-120 only. The table turns at 10 to 100 rpm.
03
The VIG-80 carries 1,000 kg (2,205 lb) on a Ø850 mm (33.5 in) face plate with 1,330 mm (52.4 in) of X travel. The VIG-120 carries 5,000 kg (11,023 lb) on a Ø1,250 mm (49.2 in) face plate with 2,252 mm (88.7 in) of X travel. Spindle, tooling and Z travel are the same.
04
X and Z have a 0.0001 mm minimum setting unit and fully closed loop digital scales as standard. Palmary describes cross roller linear guideways, a honeycomb tubular bed and coolant flow isolated from the bed to reduce heat deformation. No accuracy figure is published.
