OMAX GlobalMax 1530

The OMAX GlobalMax 1530 is a sheet-size waterjet with 10′ x 5' (3.04 m x 1.53 m) of X-Y cutting travel, 5″ (127 mm) of Z travel and a listed speed of 500 in/min (12.7 m/min). The table is 10′ 2″ x 5' 5″ (3.10 m x 1.65 m).

Three rows show where it differs from the sibling closest to it in table size. The 55100 Jet Machining Center, with a 10′ 6″ x 5' 5″ (3.20 m x 1.65 m) table, lists 8″ (203 mm) of Z travel and a table load of 400 lbs/sq ft (1,950 kg/sq meter). The GlobalMax 1530 lists 5″ (127 mm) and 100 lbs/sq ft (488 kg/sq meter). Its linear positional accuracy is ±0.003″ (±0.076 mm), with repeatability of ±0.001″ (±0.025 mm).

Read together, those figures describe a machine for sheet and moderate plate. A table load of 100 lbs/sq ft (488 kg/sq meter) is a quarter of the sibling's rating, so thick steel plate covering the bed needs to be worked out against that limit before it is loaded. The 5″ (127 mm) of Z caps the height of anything under the nozzle, fixtures included. Repeatability tighter than positional accuracy means a proven program will reproduce its parts closely from one run to the next, while absolute dimensions over a long sheet carry the wider figure.

For the site, the footprint is 12′ 8″ x 11′ 8″ (3.84 m x 3.53 m) and the height 9′ (2.74 m). The machine weighs 4,824 lb (2,188 kg) with the tank empty and 12,093 lb (5,485 kg) in operation. Noise is below 80 dBA at one meter for submerged cutting. OMAX's table for this model has no pump, pressure or electrical rows, so those have to be confirmed for the configuration being offered.
