Nakamura-Tome AS-200

Est. $150,000 - $220,000 Specs verified 2026-10-03 · nakamura-tome.com Updated 2026-10-03

Image: nakamura-tome.com, Nakamura-Tome

Key Specifications

Max Spindle

4,500 rpm

Spindle Power

15 / 11 kW

Max Turn Length

300 mm (11.8 in)

chuck size

(6 in optional), 8 in

max turning diameter

290 mm (11.4 in)

distance between centers

427 mm (16.8 in)

How much does the Nakamura-Tome AS-200 cost?

Estimated price range

Est.$150,000 - $220,000

Our best estimate for a cnc lathes / turning center in this class — not a quote from Nakamura-Tome. Configuration moves it a long way.

Overview

The Nakamura-Tome AS-200 is a compact turning center with driven tools and a Y-axis, sized for short bar and chucked parts: 290 mm (11.4 in) maximum turning diameter, 300 mm (11.8 in) maximum turning length and an 8 in chuck on a 4,500 rpm spindle rated 15 / 11 kW. The whole machine fits in 1,655 × 1,665 × 1,852 mm (W × D × H), which is a small floor area for a lathe that also mills off center.

The envelope decides most of the fit. With 427 mm (16.8 in) between centers and 300 mm of turning length, this is a machine for flanges, bushings, valve parts and short pins rather than shafts. Bar capacity is 65 mm (2.6 in) on the standard build, and the table lists a Ø71 mm version that takes 71 mm (2.8 in) bar. A 6 in chuck is offered as an option for smaller work, where a lighter chuck lets the spindle reach its top speed sooner.

Milling is handled by driven tools rated 5.5/3.7 kW (7.4/5.0 hp) at up to 6,000 RPM, with an 82 mm Y-axis stroke and a C-axis speed of 600 RPM. That stroke is enough to put a cross hole, flat or keyway off the part's centerline without a second setup on a mill, though deep pocketing is beyond a driven tool of this rating.

The turret is listed as 12 (max 24), with a 15-station turret as an option, and rapid traverse is 24 m/min in X and 36 m/min in Z. On short-cycle parts those rapids keep the time between cuts small. If your parts are longer, the AS-200L keeps the same 290 mm (11.4 in) turning diameter and extends turning length to 570 mm (22.4 in).

Full Specifications

Parameter	Value
Chuck Size	(6 in optional), 8 in
Max Turning Diameter	290 mm (11.4 in)
Max Turning Length	300 mm (11.8 in)
Distance Between Centers	427 mm (16.8 in)
Spindle Motor Power	15 / 11 kW
Turret Stations	12 (max 24) or 15-station optional
Milling Tool Power	5.5/3.7 kW (7.4/5.0 hp)
Milling Spindle Speed	6,000 RPM
Y Axis Stroke	82 mm
C Axis Speed	600 RPM
Rapid Traverse X	24 m/min
Rapid Traverse Z	36 m/min
CNC Control	FANUC 0i-TF Plus
Max Spindle Speed	4,500 rpm
Spindle Drive Motor	15/11kW
Max Bar Capacity	65 mm (2.6 in) (Ø71 mm: 71 mm (2.8 in))
Floor Space Required	1,655 × 1,665 × 1,852 mm (W × D × H)

Specifications sourced from nakamura-tome.com — verified 2026-10-03

Strengths & Limitations

Strengths

82 mm of Y stroke and 5.5/3.7 kW (7.4/5.0 hp) driven tools at up to 6,000 RPM put cross holes and flats in the same setup
Small footprint of 1,655 × 1,665 × 1,852 mm (W × D × H) for a turning center with Y-axis milling
Bar capacity of 65 mm (2.6 in), or 71 mm (2.8 in) on the Ø71 mm version
Rapid traverse of 36 m/min in Z and 24 m/min in X keeps non-cutting time short on short parts
Turret listed as 12 (max 24), with a 15-station turret available as an option

Limitations

Maximum turning length is 300 mm (11.8 in); longer parts need the AS-200L with 570 mm (22.4 in)
Spindle speed tops out at 4,500 rpm, which limits surface speed on small diameters in aluminium and brass
Driven tools rated 5.5/3.7 kW suit drilling, tapping and light milling rather than heavy material removal
Turning diameter of 290 mm (11.4 in) keeps larger flanges and discs off this machine

Best For

Bar-fed parts up to 65 mm (2.6 in), or 71 mm (2.8 in) on the Ø71 mm version Short turned parts up to 300 mm (11.8 in) long Parts with cross holes or flats within 82 mm of Y Cells where floor space is tight

Frequently Asked Questions

01 What is the difference between the AS-200 and the AS-200L?

Length. The AS-200 turns up to 300 mm (11.8 in) with 427 mm (16.8 in) between centers, while the AS-200L turns up to 570 mm (22.4 in) with 760 mm (29.9 in) between centers. Both have a 290 mm (11.4 in) turning diameter, the 4,500 rpm, 15 / 11 kW spindle and the same turret listing.

02 Does the AS-200 have a Y-axis?

Yes. The table lists a Y-axis stroke of 82 mm, driven tools rated 5.5/3.7 kW (7.4/5.0 hp) at up to 6,000 RPM and a C-axis speed of 600 RPM. That covers off-center holes, flats and slots on the turned part without moving it to a mill.

03 How large a bar can the AS-200 take?

65 mm (2.6 in) in the standard build. The table also lists a Ø71 mm version that takes 71 mm (2.8 in) bar. The chuck is 8 in as standard, with a 6 in chuck as an option for smaller parts.

04 How many tools does the AS-200 turret hold?

The turret is listed as 12 (max 24), with a 15-station turret as an option. Ask Nakamura-Tome how the maximum of 24 is reached with the holders you plan to use before counting on it for a job.

05 How much floor space does the AS-200 need?

The machine measures 1,655 × 1,665 × 1,852 mm (W × D × H). Add space for a bar feeder at the spindle end, for the chip conveyor and for service access around the cabinet.
