Yamazaki Mazak Vertical Machining Centers

Mazak VCN-700D

$185,000 - $300,000 Updated 2026-03-19

Key Specifications

X Travel

1,537 mm (60.5 in)

Y Travel

700 mm (27.5 in)

Z Travel

650 mm (25.6 in)

Max Spindle

12,000 RPM (standard); 18,000 RPM optional

Spindle Taper

CAT 40 (No. 40)

Tool Capacity

30 (standard); up to 48

Overview

The Mazak VCN-700D is the current-generation variant of the VCN-700, featuring Mazak's integral spindle/motor design and updated SmoothG CNC. With travel of 1,537 x 700 x 650 mm (60.5 x 27.5 x 25.6 in), it is the largest machine in the VCN lineup and targets shops machining long, heavy workpieces that exceed the capacity of standard 40-inch VMCs.

The 'D' designation indicates the integral spindle/motor construction that eliminates belts and couplings between spindle and motor. This direct-drive approach reduces vibration, heat generation, and maintenance while delivering smoother power delivery across the full RPM range. The standard spindle turns at 12,000 RPM with 30 kW (40 hp) through a CAT 40 taper, with an 18,000 RPM high-speed option available for aluminum and non-ferrous work.

The table measures 1,740 x 700 mm (68.5 x 27.5 in) with 2,000 kg (4,409 lb) load capacity. This combination of long table and high load rating makes the VCN-700D a natural choice for heavy mold bases, large structural components, and multi-part fixture setups. The 30-tool arm-type ATC delivers 1.3-second tool-to-tool changes, with a 48-tool option for complex programs.

Meehanite cast iron C-frame construction with a wide-base A-frame column provides mass and rigidity. Linear roller guides on all axes ensure positioning accuracy across the extended travel range. The MAZATROL SmoothG CNC with Quick Mazatrol conversational programming handles both shop-floor programming and complex CAM-generated toolpaths.

New VCN-700D machines run $185,000-$300,000 depending on spindle options and accessories. The VCN-700D competes with the Okuma GENOS M660-V, Haas VF-10, and DMG Mori CMX 1100 V in the long-bed VMC segment.

Full Specifications

Parameter	Value
X-Axis Travel	1,537 mm (60.5 in)
Y-Axis Travel	700 mm (27.5 in)
Z-Axis Travel	650 mm (25.6 in)
Max Spindle Speed	12,000 RPM (standard); 18,000 RPM optional
Spindle Taper	CAT 40 (No. 40)
Spindle Motor Power	30 kW (40 hp)
Spindle Type	Integral spindle/motor (direct drive)
Tool Capacity	30 (standard); up to 48
Tool Change Time	1.3 seconds (tool-to-tool)
Table Size	1,740 x 700 mm (68.5 x 27.5 in)
Max Table Load	2,000 kg (4,409 lb)
Rapid Traverse Rate	42 m/min (1,654 ipm)
Machine Weight	8,500 kg (18,739 lb)
CNC Control	MAZATROL SmoothG CNC with Quick Mazatrol
Guide Type	Linear roller guides (all axes)
Series Name	Pallet size
Simultaneous 5 Axis Controlintegrex I Neo	6" / 8"
8 To 12	Φ26.38"
Simultaneous 5 Axis Controlintegrex I H	6" / 8"
Simultaneous 5 Axis Controlintegrex I 150	6″
Simultaneous 4 Axis Controlentry Modelintegrex J	8" to 12"
Simultaneous 4 Axis Controlentry Modelenvironmentally Friendlyintegrex J 200 Neo	8"
Simultaneous 5 Axis Controlintegrex I 500	10″
Simultaneous 5 Axis Controlfor Long And Large Diameter Workpiecesintegrex E H	15" to 32"
Verticalsimultaneous 5 Axis Controlfor Large Workpiecesintegrex I V	CAT No.40 / CAT No.50
Double Columnsimultaneous 5 Axis Controlfor Large Workpieceintegrex E V	CAT No.50
Integration Of Gear Machining And Measurementintegrex Ag	8" to 12"
315 To 5512	Φ41.34" to Φ90.55"
Environmentally Friendlyvariaxis I Neo	Φ27.56" × width 19.69"
315 Width 248	BIG-PLUS No.50
Best Selling Machinesvariaxis I	Φ19.69" × width 15.75" to Φ23.62" × width 19.69"
4134 Width 315	BIG-PLUS No.50 / CAT No.50
Compact Entry Modelautomation Availablevariaxis C	Φ23.62" × width 19.69"
Compact Entry Modelvariaxis J	Φ19.69" × width 15.75"
Simultaneous 5 Axis Controlvc Ez X	37.4" × 14.17" to 49.21" × 19.37"
High Mix Low Volume Productionautomation Availablevariaxis I 300 Awc	Clamp interfaceHSK-A100 holder
Tilt Spindle Verticalfor Large Workpiecesvortex I V	24.8" × 24.8"
Tilt Spindle Double Columnfor Large Workpiecesvortex E V	31.5" × 31.5"
From 3937 3927	CAT No.50
Tilt Spindle Fixed Tablefor Long Workpiecesvtc	137.8" × 32.28"
Aerospace Industrytilt Spindle Vortex Ii	127.56" × 31.89" / 157.48" ×49.21"
High Speed 5 Axis Machiningtilt Spindle Vortex Horizontal Profiler	157.48" × 49.21" / 157.48" ×62.99"
Horizontalhigh Speed 5 Axis Machininghcr	19.69" × 19.69"
Die And Moldhigh Accuracy And Ultra Precision Machiningud	12.6" × 12.6"
5 Axis Double Column Machining Centeruniversal Headversatech	118.11" × 82.68" to393.7" × 122.05"
Best Selling Machinesquick Turn	6" to 21"
Cost Performance Modelqt Ez	8" to 12"
Cost Performance Modelqte	6" to 10"
Compact 2 Axis Turning Centersqt Primos	5" to 8"
Turret Lathe For Heavy Duty Machiningslant Turn	18" to 24"
Flat Turning Centers For Heavy Duty Cutting Turning Center	12"
Flat Turning Centers For Heavy Duty Cutting Power Master	15"
Milling2 Spindles And 2 Turretsmultiplex W	8″
2 Spindles And 2 Turretsdual Turn 200	8″
Milling2 Spindles And 3 Turretshqr Neo	8" / 10"
Milling2 Spindle And Upper And Lower Turrethqr	6″
8 To 10	Φ13.54"
Milling Upper And Lower Turretsqrx 50	6"
Vertical Turning Centersmirror Modelmega Turn	12" to Φ59.06"
Unique Turn Face Headstockorbitec 20	24.8"
High Speed Small Precise Parts Productionsyncrex	Φ0.375" to Φ1.5"
Cost Performance Modelvc Ez	CAT No.40
Fixed Tablelong Workpiecesvtc Ez	CAT No.40
Cat No50	6000 min-1 (rpm)
High Rigidity And High Torqueheavy Duty Cuttingmtv	CAT No.50
Fixed Tablespace Savingvtc	CAT No.40
Fixed Tablelong Workpiecesultra High Speedsvc	CAT No.40
Mass Production Linepallet Size 400 Mm 400 Mmun	CAT No.30
Double Columnhigh Accuracy And High Productivitybt40fjv	CAT No.40
Double Columnhigh Accuracy And High Productivitybt50fjv	CAT No.50
Double Columnhigh Accuracy And High Productivity5 Face Machiningfjv 5 Face	CAT No.50
5 Face Double Column Machining Centershigh Torque Spindleangle Headfjw	CAT No.50
5 Face Double Column Machining Centersuniversal Headsimultaneous 5 Axis Controlversatech	CAT No.50
Environmentally Friendlyhcn Neo	15.75" × 15.75" / 19.69" × 19.69"
Best Selling Machineshcn	up to 19.69" × 19.69"
From 315 315	CAT No.50
Difficult Machining Materialhigh Efficiency Machiningmega	31.5" × 31.5"
Quill Axislarge Workpieceshcn Q	49.21" × 39.37" to 62.99" × 49.21"
Ultra High Accuracy	31.5" × 31.5"
Mass Productionspace Savingff	19.69" × 19.69"
Mass Production Line Constructionpallet Size 400 Mm 400 Mmun	15.75" × 15.75"

Specifications sourced from mazak.com — verified 2026-03-28

Strengths & Limitations

Strengths

60.5-inch X-travel on a 68.5-inch table handles long mold bases, structural parts, and multi-part fixtures that standard VMCs cannot accommodate
Integral spindle/motor design eliminates belts for reduced vibration, less maintenance, and smoother power delivery
2,000 kg table load supports heavy steel and cast iron workpieces, mold bases, and fixture plates without weight concerns
18,000 RPM high-speed spindle option enables competitive aluminum machining alongside general steel work
1.3-second tool-to-tool changes keep non-cutting time minimal even on programs with frequent tool changes
MAZATROL SmoothG with Quick Mazatrol provides both conversational and EIA programming for maximum shop-floor flexibility

Limitations

CAT 40 taper limits tool rigidity for very heavy roughing compared to CAT 50 platforms; the VCN-535C offers BT 50 in a smaller envelope
Large footprint requires significant floor space; the extended X-travel means more linear space than standard VMCs
Starting at $185K with options reaching $300K, the VCN-700D is a significant investment over mid-size alternatives
30-tool standard magazine is modest for a machine of this size; budget for the 48-tool option on complex programs

Best For

Mold and die shops machining long mold bases, frames, and die plates requiring 60+ inches of X-travel Job shops producing structural components, machine bases, and industrial frames in steel and cast iron Manufacturers using multi-part tombstone or fixture plate setups where the long table accommodates multiple parts per cycle Shops needing a production-grade long-bed VMC with Mazak's SmoothG control and service network Automotive tooling manufacturers machining large die shoes, fixture plates, and checking fixtures

Frequently Asked Questions

01 What does a Mazak VCN-700D cost new?

New VCN-700D machines start around $185,000 for a base configuration and can reach $300,000 with the 18K RPM spindle, 48-tool magazine, through-spindle coolant, probing, and 4th-axis integration. Used VCN-700D machines from 2015-2020 sell for $90,000-$160,000.

02 What is the difference between the VCN-700 and VCN-700D?

The VCN-700D features Mazak's integral spindle/motor design that eliminates belts and couplings, plus the updated SmoothG control. Earlier VCN-700 models used belt-driven spindles and older Mazatrol controls. The D-series delivers better spindle performance, lower vibration, and improved thermal management.

03 How does the VCN-700D compare to the Haas VF-10?

Both target the long-bed VMC segment. The VCN-700D provides higher spindle speeds (up to 18K vs 8.1K RPM), faster tool changes (1.3 sec vs ~5 sec), and the SmoothG control with Mazatrol. The Haas VF-10 costs substantially less. Choose the Mazak for production speed and surface finish; choose the Haas for budget-conscious long-bed work.

04 Can the VCN-700D accept a 4th-axis rotary table?

Yes. The 2,000 kg table load and generous 27.5-inch Y-travel accommodate rotary tables for 4th-axis work. Mazak offers factory-integrated 4th-axis options with direct SmoothG control, and third-party rotary tables are also compatible.
