Yamazaki Mazak Vertical Machining Centers

Mazak VTC-760C

$320,000 - $420,000 Updated 2026-03-19

Key Specifications

X Travel

3,000 mm (118.1 in)

Y Travel

760 mm (29.9 in)

Z Travel

660 mm (26.0 in)

Max Spindle

10,000 RPM

Spindle Taper

BT 50

Tool Capacity

30 (arm-type ATC); 48 optional

Overview

The Mazak VTC-760C is the largest 3-axis traveling column machining center in the VTC lineup, delivering 3,000 mm (118.1 in) of X-axis travel for shops machining oversized parts that push the limits of standard long-bed VMCs. With nearly 10 feet of X-stroke, the VTC-760C handles full-length structural members, large die plates, press bolsters, and multi-part production setups that would otherwise require repositioning.

The BT 50 spindle turns at 10,000 RPM with 30 kW (40 hp), matching the heavy-cutting capability of the smaller VTC-530C and VTC-300C. The 50-taper provides the tool rigidity for large face mills, heavy boring bars, and aggressive roughing parameters. A 30-tool arm-type ATC handles BT 50 tooling with expanded magazine options available.

The fixed table measures 3,500 x 760 mm (137.8 x 29.9 in) with a load capacity of 4,000 kg (8,818 lb). The 760 mm Y-travel and 660 mm Z-travel match the VTC-530C, maintaining a consistent work envelope depth and height across the product line. The traveling column keeps the massive table and heavy workpieces stationary, which is critical at these part weights.

Built on a heavy cast iron base with roller guides, the VTC-760C weighs approximately 16,500 kg (36,376 lb). The MAZATROL SmoothG CNC provides full conversational and G-code capability. Rapid traverse reaches 36 m/min.

New VTC-760C machines run $320,000-$420,000. The machine competes with the Okuma MCR-BII, Johnford DMC-4100, and large-format DMG Mori DMF machines. For shops that need 10 feet of X-travel with BT 50 power in a single-setup traveling column configuration, the VTC-760C is the top of Mazak's 3-axis VTC range.

Full Specifications

Parameter	Value
X-Axis Travel	3,000 mm (118.1 in)
Y-Axis Travel	760 mm (29.9 in)
Z-Axis Travel	660 mm (26.0 in)
Max Spindle Speed	10,000 RPM
Spindle Taper	BT 50
Spindle Motor Power	30 kW (40 hp)
Tool Capacity	30 (arm-type ATC); 48 optional
Table Size	82.68" × 25"
Max Table Load	4,000 kg (8,818 lb)
Rapid Traverse Rate	36 m/min (1,417 ipm)
Machine Weight	16,500 kg (36,376 lb)
CNC Control	MAZATROL SmoothG
Machine Type	Vertical traveling column
Guide Type	Linear roller guides (all axes)
Tool Shank	CAT No.50
Max Spindle Speed	6000 min-1(rpm)

Specifications sourced from mazak.com — verified 2026-03-28

Strengths & Limitations

Strengths

3,000 mm (118.1 in) X-travel is the longest in the VTC 3-axis lineup, covering parts nearly 10 feet long on a single setup
BT 50 spindle with 30 kW provides heavy-duty cutting capability matched to the machine's large work envelope
4,000 kg table load supports the heaviest workpieces without concern for dynamic loads on the fixed table
137.8-inch table enables production fixturing of multiple large parts per cycle
Traveling column architecture keeps massive workpieces stationary for best accuracy and operator safety
Consistent VTC-series platform with shared tooling, programming, and operator training across the 300C/530C/760C range

Limitations

16,500 kg machine weight demands heavy foundation preparation and limits installation flexibility
10,000 RPM BT 50 spindle is not suited for high-speed aluminum work; shops needing speed should consider the VTC-530/20
Starting at $320K, the VTC-760C is a major capital investment
Very large footprint with 10+ feet of linear X-travel requires careful shop layout planning

Best For

Aerospace manufacturers machining full-length wing ribs, spars, and structural beams in a single setup Rail and heavy equipment shops machining long chassis members, side frames, and structural components Press tooling manufacturers machining full-size bolster plates and die shoes exceeding 8 feet Energy sector shops machining large turbine casings, generator frames, and long shaft components Contract manufacturers specializing in oversized steel and cast iron parts for industrial equipment

Frequently Asked Questions

01 What does a Mazak VTC-760C cost new?

New VTC-760C machines run $320,000-$420,000 depending on options. Used units from 2005-2018 sell for $120,000-$250,000 depending on hours and configuration.

02 How does the VTC-760C compare to the VTC-530C?

The VTC-760C provides 500 mm more X-travel (3,000 vs 2,500 mm), a larger table (3,500 vs 3,000 mm), and higher table load (4,000 vs 3,500 kg). Both share BT 50 spindles and traveling column architecture. The 760C is for shops that need the maximum X-travel in the 3-axis VTC range.

03 Can the VTC-760C do 5-axis work?

The standard VTC-760C is a 3-axis machine. For 5-axis traveling column work with B-axis tilting heads, Mazak offers the VTC-800/30SR and VTC-800/30HD series. The VTC-760C can accommodate 4th-axis rotary tables for indexing applications.

04 What foundation does the VTC-760C require?

At 16,500 kg, the VTC-760C requires a reinforced concrete foundation, typically 250+ mm thick, with proper vibration isolation. Consult the Mazak installation guide for specific soil and floor requirements.
