Mazak VC-Ez 26X
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
Rapid Traverse
Spindle Power
Overview
The Mazak VC-Ez 26X is the largest model in the VC-Ez X entry-level 5-axis machining center series, extending the family's accessible 5-axis philosophy to a bigger work envelope. Built at Mazak's Florence, Kentucky facility, the 26X provides a larger trunnion table and more linear travel than the 16X and 20X siblings, targeting shops that need 5-axis capability for mid-size parts.
The trunnion-style rotary table provides A-axis tilt from -120 to +30 degrees and 360-degree continuous C-axis rotation with 0.0001-degree indexing resolution. The larger table accommodates workpieces and fixtures that exceed the 500 mm capacity of the 20X, making the 26X suitable for medium aerospace structural components, mold inserts, and multi-feature industrial parts.
The 12,000 RPM CAT No. 40 spindle with 15 kW (20 hp) delivers more cutting power than the smaller VC-Ez X models, matching the demands of the larger work envelope. The standard 30-tool magazine expands to 50 tools. Rapid traverse of 36 m/min on all linear axes and the MX Hybrid Roller Guideway system provide fast, accurate motion. Thermal Shield technology maintains dimensional accuracy during extended 5-axis machining cycles.
The MAZATROL SmoothEz5 CNC with 15-inch touchscreen continues the VC-Ez X philosophy of simplified 5-axis operation. The control supports both conversational programming for straightforward 3+2 work and full G-code for complex simultaneous 5-axis toolpaths from CAM systems.
New VC-Ez 26X machines price between $225,000 and $300,000 depending on options. The 26X fills the gap between the entry-level 20X and the production-focused VARIAXIS j for shops that need more table capacity without jumping to the next tier.
Full Specifications
| Parameter | Value |
|---|---|
| Table Diameter | 600 mm (23.6 in) approx. |
| A Axis Range | +30 to -120 degrees |
| C Axis Range | 360 degrees continuous |
| Rotary Indexing | 0.0001 degree increments |
| Max Spindle Speed | 12,000 RPM |
| Spindle Taper | CAT No. 40 |
| Spindle Motor Power | 15 kW (20 hp) |
| Tool Capacity | 30 standard (50 optional) |
| Rapid Traverse Rate | 36 m/min (1,417 ipm) |
| CNC Control | MAZATROL SmoothEz5 CNC |
| Display | 15-inch touchscreen |
| Guideway Type | MX Hybrid Roller Guideway |
| Thermal Compensation | Thermal Shield |
| Manufactured In | Florence, Kentucky, USA |
| Table Size | 19.69" |
| Tool Shank | CAT No. 40 |
| Max Spindle Speed | 12000 min-1(rpm) |
Specifications sourced from mazak.com — verified 2026-03-28
Strengths & Limitations
Strengths
- Largest work envelope in the VC-Ez X family, handling mid-size 5-axis parts that exceed the 20X capacity
- 15 kW spindle provides more cutting power than the smaller VC-Ez X models for machining larger steel components
- Entry-level SmoothEz5 CNC makes 5-axis operation accessible without the complexity of SmoothAi or SmoothG
- Trunnion table with 0.0001-degree indexing delivers precise 3+2 positioning for multi-surface access
- Built in Kentucky with domestic delivery and Mazak North American service support
- 50-tool optional magazine accommodates complex 5-axis programs with many tools
Limitations
- 12,000 RPM spindle max without high-speed option limits high-speed finishing on aluminum 5-axis parts
- Pricing approaches the VARIAXIS j range, where shops get roller gear cam drives and more advanced control options
- CAT No. 40 taper limits tool rigidity compared to HSK or BIG-PLUS interfaces on premium 5-axis machines
- No roller gear cam rotary drives means less stiffness and positioning accuracy than VARIAXIS series
- SmoothEz5 control lacks the AI features of SmoothAi for complex simultaneous 5-axis programming
Best For
Frequently Asked Questions
01
New VC-Ez 26X machines start around $225,000 and reach $300,000 with options like 50-tool magazine, cobot automation, probing, and through-spindle coolant. At the upper end, pricing overlaps with the VARIAXIS j base configurations.
02
The VARIAXIS j offers roller gear cam rotary drives, higher spindle speed options, and SmoothAi control for advanced simultaneous 5-axis work. The VC-Ez 26X is simpler with SmoothEz5 and standard roller guides. For demanding 5-axis contouring, the VARIAXIS j is superior. For 3+2 positioning and basic 5-axis, the 26X offers a larger table at a competitive price.
03
Yes, for aluminum and mild alloy steel aerospace components. The 5-axis capability provides the multi-surface access needed for brackets, fittings, and structural parts. For titanium and nickel alloy aerospace work, the VARIAXIS series with more spindle power and rigidity is recommended.
04
The VC-Ez 26 is a 3-axis VMC with a rectangular table. The VC-Ez 26X adds a trunnion rotary table for 5-axis capability (A and C axes), uses the SmoothEz5 control instead of SmoothEz, and has a circular table. The 26X costs roughly $135,000-$165,000 more than the 3-axis 26.
