Yamazaki Mazak CNC Lathes / Turning Centers

Mazak Quick Turn 100MY

Est. $80,000 - $135,000 Specs verified 2026-10-02 · mazak.com Updated 2026-10-02

Key Specifications

X Travel

7 in (178 mm)

Y Travel

3.94 in (100 mm)

Z Travel

15 in (381 mm)

Max Spindle

6,000 rpm

Max Turn Length

13 in (330 mm)

bed length type

12 in (305 mm)

How much does the Mazak Quick Turn 100MY cost?

Estimated price range

Est.$80,000 - $135,000

Our best estimate for a cnc lathes / turning center in this class — not a quote from Yamazaki Mazak. Configuration moves it a long way.

Overview

The Mazak Quick Turn 100MY is the 6 in chuck Quick Turn with a milling turret and a Y-axis; Mazak's model list also shows it with the bolt-on turret. It is a compact machine by its table: Ø11 in (279 mm) maximum turning diameter, 13 in (330 mm) maximum turning length and Ø2 in (51 mm) bar capacity, under a Ø22 in (559 mm) swing.

The spindle runs to 6,000 rpm and is rated 11 kW (15 HP) on the 30 min. rating. The table gives no continuous figure, so long roughing cycles should be planned below that number. Every model in the Quick Turn series has a built-in motor spindle, which Mazak describes as having no gears or belts.

Axis travels are 7 in (178 mm) in X, 15 in (381 mm) in Z and 3.94 in (100 mm) in Y. That Y stroke is the point of the model: it allows flats, keyways and off-centre drilling on parts that would otherwise go on to a machining center. The table lists a turret tool storage capacity of 12. Tooling for this chuck size is a Ø32 mm boring bar shank and a 20 mm turning tool shank, per Mazak's series page.

A W-axis travel of 14 in (356 mm) is also listed. Mazak's configuration for the 100MY names no second spindle, so ask what that axis carries on the machine being quoted. Two series-level points are worth knowing. The control Mazak describes for the Quick Turn series is MAZATROL SmoothG, with G code programming also available. And the optional X and Z scale feedback is marked as not available for the 100 series.

Full Specifications

Parameter	Value
Bed Length Type	12 in (305 mm)
Max Swing	Ø22 in (559 mm)
Max Turning Diameter	Ø11 in (279 mm)
Max Turning Length	13 in (330 mm)
Max Bar Capacity	Ø2 in (51 mm)
Chuck Size	6 in
Max Spindle Speed	6,000 rpm
Spindle Power Intermittent	11 kW (15 HP) (30 min. rating)
Turrets Tool Storage Capacity	12
X-Axis Travel	7 in (178 mm)
Y-Axis Travel	3.94 in (100 mm)
Z-Axis Travel	15 in (381 mm)
W Axis Travel	14 in (356 mm)

Specifications sourced from mazak.com — verified 2026-10-02

Strengths & Limitations

Strengths

Y-axis travel of 3.94 in (100 mm) on a 6 in chuck machine, for off-centre milling and drilling
6,000 rpm spindle, against 5,000 rpm on the 8 in chuck Quick Turn 200MY
Built-in motor spindle with no gears or belts, as on every Quick Turn model
12-position turret capacity, with Ø32 mm boring bar and 20 mm turning tool shanks
Ø2 in (51 mm) bar capacity for bar-fed small parts

Limitations

No second spindle in Mazak's configuration (Milling, Y-axis, Bolt-on), so the back face needs a second chucking
Small turning envelope: Ø11 in (279 mm) by 13 in (330 mm), against Ø15 in (381 mm) and 21 in (533 mm) on the Quick Turn 200MY
Scale feedback for X and Z, an option elsewhere in the series, is not available for the 100 series
The table gives only a 30 min. rating for the 11 kW (15 HP) spindle and no figures for the rotary tools

Best For

Small bar-fed parts up to Ø2 in (51 mm) with milled features Chucked parts under Ø11 in (279 mm) in diameter and 13 in (330 mm) long Off-centre drilling and keyways within 3.94 in (100 mm) of Y travel Small-diameter turning that benefits from 6,000 rpm

Frequently Asked Questions

01 What does MY mean on the Quick Turn 100MY?

Mazak's model list gives the configuration of the QUICK TURN 100MY as Milling, Y-axis, Bolt-on. So the turret drives rotary tools, it can move in Y by 3.94 in (100 mm), and tools mount on a bolt-on turret, which Mazak describes as the standard type in the series with a VDI turret as an option.

02 How big a part can the Quick Turn 100MY turn?

Maximum turning diameter is Ø11 in (279 mm) and maximum turning length 13 in (330 mm), with a Ø22 in (559 mm) swing. Bar capacity is Ø2 in (51 mm) through the 6 in chuck. X travel is 7 in (178 mm) and Z travel 15 in (381 mm).

03 How does it compare with the Quick Turn 200MY?

The Quick Turn 200MY is the next size with the same Y-axis layout: an 8 in chuck, Ø15 in (381 mm) maximum turning diameter, 21 in (533 mm) turning length and 5,000 rpm. The Quick Turn 100MY has a 6 in chuck, Ø11 in (279 mm) and 13 in (330 mm), and runs to 6,000 rpm. Y travel is 4 in (102 mm) on the Quick Turn 200MY and 3.94 in (100 mm) here.

04 What is the spindle power of the Quick Turn 100MY?

The table lists 11 kW (15 HP) at the 30 min. rating and a top speed of 6,000 rpm. No continuous rating is shown on the model's table, so treat the figure as a short-duty rating. The spindle is a built-in motor type, which Mazak fits to all models of the Quick Turn series.

05 Can scale feedback be ordered on the Quick Turn 100MY?

Mazak lists high-accuracy scale feedback for the X- and Z-axis as an option in the Quick Turn series and notes that it is not available for the 100 series. C-axis positioning in 0.0001° increments is described as standard equipment for the series, with contouring given as optional.
