Mazak INTEGREX i-400S

$400,000 - $600,000 Updated 2026-03-16

Key Specifications

X Travel

615 mm (24.2 in)

Y Travel

250 mm (9.84 in)

Z Travel

1,585 mm (62.4 in)

Tool Capacity

36 tools (72 or 110 optional)

max machining diameter

658 mm (25.9 in)

max machining length

1,519 mm (59.8 in)

Overview

The Mazak INTEGREX i-400S is the dual-spindle version of Mazak's mid-range multi-tasking platform, combining the i-400's generous work envelope with a fully programmable sub spindle for complete done-in-one processing of medium-to-large parts. The addition of the sub spindle transforms the i-400 from a capable mill-turn into a true production multi-tasking machine that can process both ends of a part without operator intervention.

The main spindle delivers 30 kW (40 hp) at 3,300 RPM through a 10-inch chuck with 102 mm (4.0 in) bar capacity. The sub spindle runs at 4,000 RPM with 22 kW (30 hp) and an 8-inch chuck, providing genuine back-working capability for heavy turning, drilling, and milling on the B-end. The milling spindle hits 12,000 RPM with 22 kW (30 hp) through a Capto C6 interface, with a 20,000 RPM option for high-speed finishing on aluminum and composites.

The B-axis covers 240 degrees (-30 to +210) with 0.0001-degree resolution on a roller cam drive. Combined with 250 mm (9.84 in) of Y-axis travel and continuous C-axis on both spindles, the i-400S can attack any feature angle on both part ends. X-axis travel spans 615 mm, Z-axis runs 1,585 mm, and the W-axis (sub spindle) provides 1,562 mm of travel for part transfer and long-shaft back-working.

The standard 36-tool ATC expands to 72 or 110 tools with Capto C6 shanks. An NC tailstock with 1,562 mm of travel supports long shafts during heavy cuts on the main spindle side. Current machines ship with MAZATROL SmoothAi featuring Ai Thermal Shield. At approximately 16,200 kg (35,714 lb), the i-400S demands solid foundation work and adequate floor space. New machines price between $400,000 and $600,000, with used units from 2014-2020 trading between $180,000 and $380,000. Specs sourced from Mazak published data and dealer documentation.

Full Specifications

Parameter	Value
Max Machining Diameter	658 mm (25.9 in)
Max Machining Length	1,519 mm (59.8 in)
X-Axis Travel	615 mm (24.2 in)
Y-Axis Travel	250 mm (9.84 in)
Z-Axis Travel	1,585 mm (62.4 in)
Travel W	1,562 mm (sub spindle)
B Axis Range	240° (-30° to +210°)
C Axis Rotation	360° continuous (both spindles)
Main Spindle Speed	3,300 RPM
Main Spindle Power	30 kW (40 hp)
Sub Spindle Speed	4,000 RPM
Sub Spindle Power	22 kW (30 hp)
Milling Spindle Speed	12,000 RPM (20,000 RPM optional)
Milling Spindle Power	22 kW (30 hp)
Milling Spindle Taper	Capto C6
Chuck Size	10 in (main, A2-8) / 8 in (sub)
Bar Capacity	102 mm (4.0 in)
Tool Capacity	36 tools (72 or 110 optional)
Rapid Traverse Xz	50 m/min (1,969 ipm)
Rapid Traverse Y	40 m/min (1,575 ipm)
Machine Weight	16,200 kg (35,714 lb)
CNC Control	MAZATROL SmoothAi CNC
Modelintegrex I 400s 1500ubrandmazaktypemultitasking Machining Centerscontrolcontact Sales Rep	Contact Sales Rep.
Modelintegrex I 400s 1500ubrandmazaktypemultitasking Machining Centerscontrol	Contact Sales Rep.
Model	INTEGREX I-400S-1500U
Brand	MAZAK
Type	Multitasking Machining Centers
X2421y1024z624power40 Hp	RPM3,300 RPM# Axis5ControlCNC
X	24.21"
Y	10.24"
Z	62.4"
Power	40 hp
Rpm	3,300 RPM
Axis	5
Cnc Control	CNC
Looking To Purchase A New Mazak Integrex I 400s 1500u	Contact Sales Rep.

Specifications sourced from machinetools.com — verified 2026-03-28

Strengths & Limitations

Strengths

Dual-spindle configuration with 22 kW sub spindle provides genuine back-working capability for heavy turning and milling on both part ends, not just light finishing
102 mm (4.0 in) bar capacity and 10-inch main chuck handle medium-to-large bar stock and chucked work that exceeds the i-200S's 65 mm limit
1,519 mm machining length with NC tailstock support accommodates long aerospace shafts, landing gear components, and oil-field tubulars in a single setup
12,000 RPM Capto C6 milling spindle with 22 kW delivers true machining center performance for complex 5-axis contouring across the full B-axis range
240-degree B-axis with 0.0001-degree resolution and roller cam drive ensures zero-backlash positioning for precision angular features on both part ends
SmoothAi control with Ai Thermal Shield provides active thermal compensation during long multi-tasking cycles, critical for maintaining tolerances across 4-8 hour production runs

Limitations

3,300 RPM main spindle is slower than the i-200S's 5,000 RPM, limiting high-speed turning performance on smaller-diameter aluminum and non-ferrous materials
16,200 kg machine weight and 5+ meter footprint require substantial foundation engineering and rigging planning that adds $15,000-$30,000 to installation costs
New price starting at $400K represents a major capital investment; ROI requires consistent elimination of multiple setups per part across significant production volume
Dual-spindle programming is complex; expect 4-6 months ramp-up time and custom post processor development for synchronized simultaneous operations
Periodic B-axis laser calibration at $250+/hour from Mazak service is recommended every 12-18 months, plus sub spindle alignment verification adds to ongoing maintenance costs

Best For

Aerospace manufacturers producing landing gear, structural components, and turbine hardware requiring complete both-end processing in a single setup on medium-to-large parts Energy sector shops machining oil and gas components with complex OD/ID features, cross-holes, and long geometries on parts up to 102 mm bar diameter Production environments running lights-out with bar feeders where automatic part transfer between spindles enables complete processing without operator intervention Defense contractors producing ordnance and guidance components where maintaining datum relationships across both part ends eliminates refixturing tolerance stack-up Shops upgrading from the single-spindle i-400 that need done-in-one capability without stepping up to the larger i-500 or i-600 class machines

Frequently Asked Questions

01 What does a new Mazak INTEGREX i-400S cost?

Base i-400S configurations start around $400,000. Production-ready setups with 20,000 RPM milling spindle, high-pressure through-spindle coolant, expanded tool magazine, and automated part handling typically run $480,000-$600,000. Used i-400S machines from 2014-2020 trade between $180,000 and $380,000 depending on hours, spindle condition, control generation, and options.

02 What is the difference between the i-400 and i-400S?

The i-400 has a single turning spindle with NC tailstock support. The i-400S adds a fully programmable sub spindle with 22 kW (30 hp) and 4,000 RPM for back-working operations. The sub spindle adds roughly $50,000-$80,000 to the price but eliminates the need for a second operation on parts requiring both-end machining. The i-400S also adds approximately 700 kg of machine weight.

03 Can the i-400S do simultaneous cutting on both spindles?

The i-400S can perform turning on the sub spindle while the milling spindle works on the main spindle side, but true simultaneous turning on both spindles requires the i-400ST variant with its lower turret. The S model sequences operations between spindles during part transfer, while the ST can overlap cutting time between the milling spindle and lower turret.

04 How does the i-400S compare to the DN Solutions SMX 3100ST?

The DN Solutions SMX 3100ST offers similar capability at roughly 70-80% of the Mazak's price, with comparable work envelope and dual spindles. The Mazak counters with faster rapids, the MAZATROL SmoothAi control ecosystem, and a significantly larger North American service network. The SMX 3100ST includes a lower turret standard (comparable to the i-400ST), giving it more simultaneous cutting flexibility at a lower price point.
