Yamazaki Mazak Mill-Turn / Multi-Tasking Machines

Mazak INTEGREX i-150S

Est. $260,000 - $380,000 Possible older model Updated 2026-10-02

This model was not found in Yamazaki Mazak's current lineup when we checked on 2026-10-02 (lineup page). It may be a superseded or older model; the specifications below are as we last recorded them.

Key Specifications

X Travel

370 mm (14.57 in)

Y Travel

200 mm (7.87 in)

Z Travel

435 mm (17.13 in)

Tool Capacity

24 tools (36 or 48 optional)

max machining diameter

Φ13.39"

max machining length

15.16"

How much does the Mazak INTEGREX i-150S cost?

Estimated price range

Est.$260,000 - $380,000

Our best estimate for a mill-turn / multi-tasking machine in this class — not a quote from Yamazaki Mazak. Configuration moves it a long way.

Overview

The Mazak INTEGREX i-150S is a compact mill-turn machine built around a 6 in chuck, a B-axis milling spindle and a second spindle. Mazak's series page lists one model, the INTEGREX i-150, so the figures given here for the S are listed ones and should be confirmed with Mazak before a second-spindle machine is specified.

What Mazak says about the i-150 series is mostly about fitting capability into a small footprint. Bar capacity is Ø2.56 in, which Mazak calls equivalent to a higher class of machine, in less floor space than similar machines with a 6 in or 8 in chuck and a second spindle. The Y axis uses an orthogonal structure with a stroke of ±3.94 in. The B axis is driven by a roller gear cam with no backlash, indexes in 0.0001-degree increments and has closed-loop scale feedback as standard equipment. A chiller circulates temperature-controlled oil through the spindle and built-in motor housing, and the Thermal Shield function compensates for heat displacement. The series page describes the i-150 with a tailstock unit and a work handling system that reverses the workpiece for continuous OP1 and OP2 machining.

The listed figures for the S give a maximum machining diameter of 13.39 in and length of 15.16 in, with travels of 370 mm (14.57 in) in X, 200 mm (7.87 in) in Y and 435 mm (17.13 in) in Z. Main and sub spindles are both listed at 5,000 rpm, with 15 kW (20 hp) and 11 kW (15 hp). The milling spindle is listed as HSK-A63, 12,000 rpm and 11 kW (15 hp), with 20,000 rpm optional, on a B axis of 200° (-10° to +190°). Listed tool capacity is 24 tools, with 36 or 48 optional.

Full Specifications

Parameter	Value
Max Machining Diameter	Φ13.39"
Max Machining Length	15.16"
X-Axis Travel	370 mm (14.57 in)
Y-Axis Travel	200 mm (7.87 in)
Z-Axis Travel	435 mm (17.13 in)
B Axis Range	200° (-10° to +190°)
C Axis Rotation	360° continuous (both spindles)
Main Spindle Speed	5,000 RPM
Main Spindle Power	15 kW (20 hp)
Sub Spindle Speed	5,000 RPM
Sub Spindle Power	11 kW (15 hp)
Milling Spindle Speed	12,000 RPM (20,000 RPM optional)
Milling Spindle Power	11 kW (15 hp)
Milling Spindle Taper	HSK-A63
Chuck Size	6″
Bar Capacity	65 mm (2.56 in)
Tool Capacity	24 tools (36 or 48 optional)
Rapid Traverse Xz	36 m/min (1,417 ipm)
Floor Space	5.8 m²
Machine Weight	7,000 kg (15,432 lb)
CNC Control	MAZATROL SmoothAi CNC

Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.

Strengths & Limitations

Strengths

Ø2.56 in bar capacity, which Mazak rates as equivalent to a higher class of machine
Y-axis stroke of ±3.94 in on an orthogonal Y-axis structure
B axis driven by a roller gear cam, indexing in 0.0001-degree increments with scale feedback as standard
Listed floor space of 5.8 m² and machine weight of 7,000 kg (15,432 lb)
Listed sub spindle at 5,000 rpm and 11 kW (15 hp) for second-operation work

Limitations

Mazak's series page lists only the INTEGREX i-150, so the second-spindle configuration and its figures need confirming with Mazak
Listed machining length is 15.16 in and Z travel 435 mm (17.13 in), which rules out longer shaft work
The listed magazine is 24 tools; 36 or 48 tools are options
Milling power is listed at 11 kW (15 hp), and the 20,000 rpm milling spindle is optional

Best For

Small bar-fed parts up to Ø2.56 in Complex small parts needing B-axis milling within ±3.94 in of Y Cells where floor space is tight, at a listed 5.8 m² Short parts machined on both ends in one cycle

Frequently Asked Questions

01 Does Mazak list an INTEGREX i-150S?

Mazak's series page for the INTEGREX i-150 lists a single model, the INTEGREX i-150. It describes that machine with a tailstock unit and a work handling system that reverses the workpiece for continuous OP1 and OP2 machining. The second spindle shown on this page, at 5,000 rpm and 11 kW (15 hp), is a listed figure; ask Mazak to confirm the configuration before relying on it.

02 How large a part does the i-150S take?

The listed maximum machining diameter is 13.39 in and the maximum machining length 15.16 in. Bar capacity is 65 mm (2.56 in) and the chuck size is 6 in. Listed travels are 370 mm (14.57 in) in X, 200 mm (7.87 in) in Y and 435 mm (17.13 in) in Z.

03 What does Mazak say about B-axis positioning on the i-150?

The B axis is driven by a roller gear cam with no backlash and can be indexed and positioned in 0.0001-degree increments. Closed-loop control with a scale feedback system is standard equipment, and a clamping brake system holds the axis during positioning and indexing. The listed B-axis range on this page is 200° (-10° to +190°).

04 How does the i-150 series deal with heat?

A chiller unit circulates temperature-controlled oil through the spindle and the built-in motor housing to reduce elongation. The Thermal Shield function suppresses changes in cutting edge position using spindle rotation speed and temperature sensor information. Temperature and compensation data are shown on the CNC screen, where the operator can adjust the compensation.
