Hardinge Talent 42/65
Key Specifications
Max Turn Length
bar capacity
max turning diameter
x axis travel
z axis travel
spindle speed
Overview
The Hardinge Talent 42/65 is a compact CNC turning center from Hardinge, the American manufacturer synonymous with precision turning. The 42/65 designation indicates 42 mm bar capacity with a 65 mm chuck, making it ideal for small precision parts from bar stock.
The Talent 42/65 handles bar stock up to 42 mm (1.65 in) diameter with a maximum turning diameter of 260 mm (10.2 in) over the cross slide. X-axis travel is 160 mm (6.3 in) and Z-axis is 305 mm (12.0 in). The spindle runs at 6,000 rpm with approximately 11 kW (15 hp).
The 12-station turret accepts both OD and ID tools. Optional C-axis and live tooling add milling, drilling, and tapping capability for complete part processing in a single setup. Rapid traverse is 24 m/min on X and 30 m/min on Z.
Hardinge is known for collet-ready spindles with exceptional TIR (total indicated runout), typically under 0.005 mm. This makes the Talent ideal for precision turned parts requiring tight concentricity. Runs on Fanuc 0i-TF control.
Machine weight is approximately 3,200 kg with a compact footprint. The Talent series competes with Haas ST-10/15, Doosan Lynx 2100, and Citizen Cincom at the small-parts end.
New machines price $70,000-$110,000. Used trade $30,000-$60,000.
Full Specifications
| Parameter | Value |
|---|---|
| Bar Capacity | 42 mm (1.65 in) |
| Max Turning Diameter | 260 mm (10.2 in) |
| Max Turning Length | 305 mm (12.0 in) |
| X Axis Travel | 160 mm (6.3 in) |
| Z Axis Travel | 305 mm (12.0 in) |
| Spindle Speed | 6,000 rpm |
| Spindle Motor | 11 kW (15 hp) |
| Spindle Bore | 42 mm (1.65 in) |
| Collet Type | 5C or 16C collet-ready |
| Turret | 12-position |
| Live Tooling | Optional C-axis with live tools |
| Rapid Traverse X | 24 m/min (945 ipm) |
| Rapid Traverse Z | 30 m/min (1,181 ipm) |
| Spindle Runout | < 0.005 mm TIR |
| CNC Control | Fanuc 0i-TF |
| Machine Weight | 3,200 kg (7,055 lb) |
| Power Supply | 200/220V, 3-phase |
Specifications sourced from hardinge.com — verified 2026-03-28
Strengths & Limitations
Strengths
- Hardinge collet-ready spindle with < 0.005 mm TIR for exceptional concentricity
- 42 mm bar capacity handles the most common small bar stock sizes
- Optional C-axis and live tooling for complete part processing in one setup
- Fanuc 0i-TF control is industry standard for turning
- Compact footprint fits in tight shop floor layouts
- Hardinge brand carries premium reputation in precision turning
Limitations
- 42 mm bar capacity limits maximum bar stock diameter
- 6,000 rpm spindle speed is moderate by modern standards
- 12-tool turret may limit complex parts with many operations
- Hardinge pricing is premium vs Korean or Taiwanese competitors
- X-axis travel of 160 mm limits large-diameter facing operations
Best For
Frequently Asked Questions
01
New $70,000-$110,000. Used $30,000-$60,000.
02
42 mm bar capacity through the spindle, 65 mm maximum chuck diameter for chucked work.
03
Yes. Optional C-axis with live tooling adds milling, drilling, and tapping for complete part processing.
04
Hardinge is known for collet-ready spindles with < 0.005 mm TIR, providing exceptional concentricity for precision turned parts.
05
Fanuc 0i-TF.
