Citizen Miyano BND-64

Est. $220,000 - $310,000 Possible older model Specs verified 2026-03-28 · citizenmachinery.co.uk Updated 2026-10-03

This model was not found in Citizen Machinery's current lineup when we checked on 2026-10-02 (lineup page). It may be a superseded or older model; the specifications below are as we last recorded them.

Citizen Miyano BND-64 Mill-Turn Machines

Image: citizenmachinery.co.uk, Citizen Machinery

Key Specifications

X Travel

185 mm (7.28 in)

Y Travel

+40/-35 mm

Z Travel

460 mm (18.11 in)

Rapid Traverse

20 m/min (787 ipm)

max bar capacity sp1

64 mm (2.52 in)

max bar capacity sp2

51 mm (2.0 in)

How much does the Citizen Miyano BND-64 cost?

Estimated price range

Est.$220,000 - $310,000

Our best estimate for a mill-turn / multi-tasking machine in this class — not a quote from Citizen Machinery. Configuration moves it a long way.

Overview

The Citizen Miyano BND-64 is the 64 mm member of the BND fixed-headstock family: its main spindle takes bar up to 64 mm (2.52 in) and its second spindle up to 51 mm (2.0 in), both running to 4,500 rpm. A 12-station turret with a Y axis carries live tools driven at 6,000 rpm. Citizen does not have the BND-64 in its current lineup.

The main spindle motor is rated 18.5/15 kW (25/20 hp), which suits the larger stock: roughing 64 mm bar takes more torque than 51 mm work, and that rating is what makes full-diameter cuts practical.The second spindle has an 11/7.5 kW (15/10 hp) motor. Its 51 mm capacity is the number to check when quoting, because a part whose back end is larger than that where it is gripped cannot be transferred.

The turret moves 185 mm (7.28 in) in X with +40/-35 mm of Y, and rapids at 20 m/min (787 ipm). Live tools have a 2.2 kW drive, so cross holes, flats and light milling are realistic but heavy face milling is not. Compared with the Miyano BND-51SY, which lists 175 mm (6.89 in) of X, live tools at 5,000 RPM and a 6 in power chuck, the BND-64 has more X stroke and faster live tools, and it is listed with a Fanuc 0i-TF control.

The table gives the Z stroke in two different values and no clear machining length or machine weight, so confirm those on any machine offered. As a used machine, the control, spindle bearings and turret indexing are the first things to inspect.

Full Specifications

Parameter	Value
Max Bar Capacity Sp1	64 mm (2.52 in)
Max Bar Capacity Sp2	51 mm (2.0 in)
Main Spindle Speed	4,500 RPM
Main Spindle Power	18.5/15 kW (25/20 hp)
Sub Spindle Speed	4,500 RPM
Sub Spindle Power	11/7.5 kW (15/10 hp)
Turret Stations	12
Live Tool Speed	6,000 RPM
Live Tool Power	2.2 kW
X-Axis Travel	185 mm (7.28 in)
Z-Axis Travel	460 mm (18.11 in)
Y-Axis Travel	+40/-35 mm
Rapid Traverse Rate	20 m/min (787 ipm)
CNC Control	Fanuc 0i-TF
Maximum Machining Length	Bar
Z Axis	435mm
Y Axis	+40mm/-35mm
B Axis	530mm

Specifications sourced from citizenmachinery.co.uk — verified 2026-03-28

Strengths & Limitations

Strengths

64 mm (2.52 in) bar capacity on the main spindle and 51 mm (2.0 in) on the second spindle
18.5/15 kW (25/20 hp) main spindle motor for roughing larger bar
Live tools at 6,000 rpm and 185 mm (7.28 in) of X, against 5,000 RPM and 175 mm (6.89 in) on the Miyano BND-51SY
Second spindle with an 11/7.5 kW (15/10 hp) motor running to 4,500 rpm
Y-axis travel of +40/-35 mm on the 12-station turret

Limitations

Both spindles stop at 4,500 rpm, which limits cutting speed on small diameters
Live tool drive is 2.2 kW, modest beside the 18.5/15 kW main spindle, so heavy milling is limited
Not in Citizen's current lineup; Z stroke, machining length and weight are not stated clearly, so confirm them on the machine
The second spindle takes 51 mm, so parts larger than that at the transfer point cannot be passed over

Best For

Bar work up to 64 mm with back-end finishing Larger turned parts with cross holes and milled flats Buyers wanting a used fixed-headstock lathe with a Fanuc 0i-TF control

Frequently Asked Questions

01 What bar sizes does the Miyano BND-64 take?

The main spindle takes bar up to 64 mm (2.52 in) and the second spindle up to 51 mm (2.0 in). Both run to 4,500 rpm, the main spindle on 18.5/15 kW (25/20 hp) and the second on 11/7.5 kW (15/10 hp).

02 How does the BND-64 differ from the Miyano BND-51SY?

The Miyano BND-51SY lists 175 mm (6.89 in) of X travel, live tools at 5,000 RPM and a 6 in power chuck. The BND-64 has 185 mm (7.28 in) of X, live tools at 6,000 rpm and a Fanuc 0i-TF. Both are listed with a 12-station turret and 20 m/min (787 ipm) rapids.

03 What live tooling does the BND-64 have?

A 12-station turret with live tools at up to 6,000 rpm on a 2.2 kW drive, and a Y axis of +40/-35 mm. That covers cross drilling, tapping and flats on large bar parts; heavy milling is beyond the drive.

04 What should a buyer confirm on a used BND-64?

The table gives the Z stroke as two different values and has no clear machining length or machine weight, so confirm those from the machine's documentation. Also check the Fanuc 0i-TF control, both spindles and the turret indexing.
