Amada VENTIS 4020 AJe

$800,000 - $1,300,000 Updated 2026-03-19

Key Specifications

Accuracy

+/-0.03 mm (+/-0.0012 in)

work area

4,068 x 2,044 mm (160 x 80 in)

laser type

High-brightness fiber laser with Locus Beam Control (LBC)

laser power options

6 kW / 9 kW

beam control

Locus Beam Control (LBC) -- infinite locus pattern beam oscillation

cutting modes

Quality Mode / Kerf Control Mode / Productivity Mode

Overview

The Amada VENTIS 4020 AJe is the large-format variant of Amada’s VENTIS fiber laser cutting platform, combining the exclusive Locus Beam Control (LBC) beam oscillation technology with a 4,068 x 2,044 mm (160 x 80 in) working area for processing oversized sheets. The VENTIS 4020 AJe brings the same dross-free cutting and up to 3x speed advantage on stainless steel and aluminum that defines the 3015 model, but in a format that handles standard 4x8 ft sheets and larger panels.

Available in 6 kW and 9 kW configurations, the VENTIS 4020 AJe operates in three modes: Quality Mode for pristine surface finish and dross elimination, Kerf Control Mode for stable automated processing, and Productivity Mode for maximum speed. The LBC system creates infinite locus patterns to freely manipulate the laser beam during cutting, controlling kerf width, heat input, and melt ejection independently -- a capability unique to Amada that no competitor has replicated.

The large-format VENTIS is particularly valuable for architectural and decorative fabrication where large stainless steel and aluminum panels must be cut with flawless edge quality. The AMNC 4ie control manages cutting parameters automatically, and the AJe automation package handles nozzle changes, focus adjustments, and parameter updates without operator intervention. At 9 kW, the machine cuts stainless steel to 25 mm and aluminum to 20 mm with edge quality that eliminates secondary deburring.

New VENTIS 4020 AJe machines price between $800,000 and $1,300,000 depending on laser power and automation. The large-format LBC platform has no direct competitor offering equivalent beam oscillation technology in this sheet size.

Full Specifications

Parameter	Value
Work Area	4,068 x 2,044 mm (160 x 80 in)
Laser Type	High-brightness fiber laser with Locus Beam Control (LBC)
Laser Power Options	6 kW / 9 kW
Beam Control	Locus Beam Control (LBC) -- infinite locus pattern beam oscillation
Cutting Modes	Quality Mode / Kerf Control Mode / Productivity Mode
Max Cutting Speed Advantage	Up to 3x faster than conventional 6-8 kW fiber lasers
Max Cutting Thickness Mild Steel 9kw	25 mm (0.98 in)
Max Cutting Thickness Stainless 9kw	25 mm (0.98 in)
Max Cutting Thickness Aluminum 9kw	20 mm (0.79 in)
Positioning Accuracy	+/-0.03 mm (+/-0.0012 in)
Acceleration	1.2 G across full work area
Rapid Traverse Xy	120 m/min (4,724 ipm)
Automatic Nozzle Change	Yes (AJe -- nozzle, focus, parameter auto-change)
CNC Control	Amada AMNC 4ie with touchscreen interface
Table Load Capacity	1,500 kg (3,307 lb)
Machine Weight	23,000 kg (50,706 lb)

Specifications sourced from amada.com — verified 2026-03-28

Strengths & Limitations

Strengths

Large 4,068 x 2,044 mm work area combined with LBC beam oscillation -- the only large-format fiber laser with this technology
Dross-free cutting on stainless steel and aluminum eliminates secondary finishing on large architectural and decorative panels
Up to 3x faster cutting speeds than conventional fiber lasers on stainless and aluminum with massive productivity gains
1,500 kg table load capacity handles heavy large-format sheets
Three operating modes allow optimization for quality, consistency, or speed based on job requirements
AMNC 4ie control with Industry 4.0 connectivity for modern production management

Limitations

$800K-$1.3M price tag is a significant investment even for large fabrication operations
6 kW and 9 kW maximum power limits thick mild steel cutting compared to 15 kW ENSIS 4020 models
Large footprint requires substantial floor space and dedicated automation for maximum utilization
LBC technology is Amada-exclusive -- service dependency on a single manufacturer

Best For

Architectural metalwork and building facade fabricators cutting large stainless steel and aluminum panels with pristine cosmetic edges Transportation and rail vehicle manufacturers processing large aluminum body panels where dross-free edges reduce assembly labor Commercial kitchen and food processing equipment builders working with large stainless steel sheets Sign and display fabricators cutting large-format aluminum and stainless panels for corporate and retail installations Elevator and escalator manufacturers processing large decorative stainless panels with cosmetic finish requirements

Frequently Asked Questions

01 Why choose the VENTIS 4020 over the ENSIS 4020?

Choose the VENTIS 4020 if your primary materials are stainless steel and aluminum and edge quality is a key differentiator. The LBC beam oscillation delivers dross-free edges and faster cutting speeds on these materials. Choose the ENSIS 4020 if you need higher laser power (up to 15 kW) or a more general-purpose machine for diverse material mixes.

02 What sheet sizes can the VENTIS 4020 AJe handle?

The 4,068 x 2,044 mm work area handles both standard 4x8 ft and 5x10 ft sheets, plus larger format panels. This makes it versatile for shops processing multiple sheet sizes.

03 Is the dross-free cutting advantage real on large sheets?

Yes, and the economic impact is amplified on large sheets. On a 4x8 ft stainless panel with dozens of cut features, eliminating deburring can save 30-60 minutes of hand finishing per sheet.

04 What automation options are available for the VENTIS 4020?

The VENTIS 4020 AJe integrates with Amada large-format automation including ASF-EU 4020 tower storage, dual shuttle tables, and SortMaster automated part sorting. Full automation adds $300K-$600K to base cost.
