United Grinding Studer S41
Key Specifications
X Travel
Y Travel
Z Travel
Max Spindle
Spindle Power
Max Turn Length
How much does the United Grinding Studer S41 cost?
Estimated price range
Our best estimate for a cnc grinding machine in this class — not a quote from United Grinding Group. Configuration moves it a long way.
Overview
A Studer S41 is specified first by its length. Z travel is either 1'150 mm (45.3 inch) or 1'750 mm (68.9 inch), which goes with a length of 1'000 mm (40") or 1'600 mm (63 inch). Everything else in the table is common to both versions.
The wheel spindle is rated 15 kW (20 hp) and runs up to 4'500 rpm. It carries a grinding wheel of up to 508 mm (20 inch) in diameter and 100 mm (3.9 inch) in width. A wheel that wide lets a single plunge cover a long bearing seat, and the 15 kW (20 hp) is there to drive it across the full face. It also allows a profiled wheel to finish a shoulder and a diameter together.
Three linear axes are listed, which is one more than a plain cylindrical grinder has. X travel is 350 mm (13.8 inch) and rapid traverse is 20'000 mm/min (787 inch/min) in both X and Z. On the longer version that rate keeps the wheelhead from spending the cycle crossing between seats at opposite ends of a shaft. Y travel is 100 mm (3.9 inch). A Y axis moves the wheel off the center line of the part, which form and thread work can need; the table does not say which wheelhead it is fitted to, so ask before assuming it is on the machine quoted.
The control is listed as Fanuc 31i + StuderWIN / StuderGRIND, that is, the CNC with Studer's own software on top of it. A shop already programming other Studer machines in StuderWIN will find the same environment here.
Full Specifications
| Parameter | Value |
|---|---|
| Control System | Fanuc 31i + StuderWIN / StuderGRIND |
| X-Axis Travel | 350 mm (13.8 inch) |
| Y-Axis Travel | 100 mm (3.9 inch) |
| Z-Axis Travel | 1'150 mm (45.3 inch) / 1'750 mm (68.9 inch) |
| Max Spindle Speed | 4'500 /min (4'500 rpm) |
| Spindle Motor Power | 15 kW (20 hp) |
| Max Grinding Wheel Diameter | 508 mm (20 inch) |
| Max Grinding Wheel Width | 100 mm (3.9 inch) |
| Max Tool Diameter (full magazine) | 549 mm (21.6 inch) |
| Rapid Traverse X | 20'000 mm/min (787 inch/min) |
| Rapid Traverse Z | 20'000 mm/min (787 inch/min) |
| Max Turning Length | 1'000 mm (40") / 1'600 mm (63 inch) |
| Max Turning Diameter | 549 mm (21.6 inch) |
| Table Load Max | 250 kg (550 lbs) |
Specifications sourced from studer.com — verified 2026-10-03
Strengths & Limitations
Strengths
- 15 kW (20 hp) wheel spindle running up to 4'500 rpm
- Grinding wheel up to 508 mm (20 inch) in diameter and 100 mm (3.9 inch) wide
- Rapid traverse of 20'000 mm/min (787 inch/min) on both X and Z
- A Y axis with 100 mm (3.9 inch) of travel in addition to X and Z
- Control listed as Fanuc 31i + StuderWIN / StuderGRIND
Limitations
- No version has less than 1'150 mm (45.3 inch) of Z travel, where the Studer Favorit starts at 500 mm (19.7 inch)
- X travel is 350 mm (13.8 inch), slightly less than the 370 mm (14.6 inch) of the Studer Favorit
- Spindle speed stops at 4'500 rpm, far below the 60'000 rpm listed for the Studer S100
- The table gives no machine weight, footprint or electrical supply
Best For
Frequently Asked Questions
01
Two. Z travel is 1'150 mm (45.3 inch) or 1'750 mm (68.9 inch), and the corresponding length is given as 1'000 mm (40") / 1'600 mm (63 inch). X travel is 350 mm (13.8 inch) and Y travel is 100 mm (3.9 inch) on both.
02
The control system is listed as Fanuc 31i + StuderWIN / StuderGRIND. StuderWIN and StuderGRIND are Studer's own software, so the operator works in Studer's environment and not directly in the base CNC. Ask which software modules are included in the quotation.
03
The grinding wheel can be up to 508 mm (20 inch) in diameter and 100 mm (3.9 inch) wide. Spindle power is 15 kW (20 hp) and maximum spindle speed is 4'500 rpm. That pairing is aimed at external grinding with broad wheels.
04
Rapid traverse is 20'000 mm/min (787 inch/min) in X and the same in Z. No rapid rate is listed for the Y axis, which has 100 mm (3.9 inch) of travel and is a positioning axis more than a feed axis.
05
The Studer Favorit has an 11.5 kW (15.4 hp) spindle, 370 mm (14.6 inch) of X travel and an X rapid of 15,000 mm/min (590 inch/min), and it is offered from 500 mm (19.7 inch) of Z travel upward. The S41 has 15 kW (20 hp), 20'000 mm/min (787 inch/min) in X, and only the two long Z travels.
