ShopSabre SideKick 12
Image: shopsabre.com, ShopSabre
Key Specifications
Rapid Traverse
Repeatability
machine dimensions
cutting area
z clearance
z axis travel
How much does the ShopSabre SideKick 12 cost?
Price estimate
We do not have a price for the ShopSabre SideKick 12 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The ShopSabre SideKick 12 is the largest SideKick plasma table, with a 78 x 146 in (1,981 x 3,708 mm) cut area for 6x12 plate. It gives a shop the biggest sheet format ShopSabre cuts with plasma without moving up to the servo-driven ShopMaster series.
Who needs a table this wide? Trailer and truck-body builders cutting deck and side panels, tank and hopper fabricators, and shops that nest long gussets and stringers. For them the gain is fewer remnants and fewer seams. A second use is throughput on smaller material: two 4x6 sheets, or a 4x8 and a stack of drops, can be laid side by side and cut in one program while the operator unloads the first.
The gantry spans 78 in on this model, the widest in the series, and still gives 8 in (203 mm) of clearance. It is a welded, stress-relieved and milled steel tube, which holds its shape under the heat of long cuts better than a light beam would. Both ends of it are driven, by rack and pinion through planetary gears.
Listed performance does not fall off with size: 1,500 ipm (38.1 m/min) rapid traverse and +/- 0.002 in (0.051 mm) repeatability, as on the SideKick 4. Cutting capacity is up to 2 in (51 mm), with oxy-fuel recommended above 1 in (25 mm). The footprint is 105 x 166 x 67 in (2,667 x 4,216 x 1,702 mm). A water table on a machine this size holds a lot of water, so floor loading and a drain route belong in the site plan.
Full Specifications
| Parameter | Value |
|---|---|
| Machine Dimensions | 105 x 166 x 67 in (2,667 x 4,216 x 1,702 mm) |
| Cutting Area | 78 x 146 in (1,981 x 3,708 mm) |
| Z Clearance | 8 in (203 mm) |
| Z Axis Travel | 9 in (229 mm) |
| Cutting Capacity | Up to 2 in (51 mm); oxy-fuel recommended for over 1 in (25 mm) |
| Repeatability | +/- 0.002 in (0.051 mm) |
| Rapid Traverse Rate | 1,500 ipm (38.1 m/min) |
| Drive Motors | Closed loop motors with planetary gear drive |
| Drive System | Ball screw Z-axis with planetary drives; rack-and-pinion X and Y axes with ShopSabre Floating Drive Technology |
| Linear Guides | 25 mm linear guide rails and bearings on all axes |
| CNC Control | Ethernet/network-ready controller with an at-machine PC running Windows OS |
| Torch Height Control | Digital torch height control with Ohmic Touch material sensing |
| Software | Hypertherm ProNest LT and EnRoute Fabrication (12-month license) |
| Well Equipped Plasma Cutter | Hypertherm Powermax45 SYNC with machine torch |
| Well Equipped Water Table | Welded, leak-tested 3 in (76 mm) water table |
Specifications sourced from shopsabre.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 78 x 146 in (1,981 x 3,708 mm) cut area, the largest SideKick table
- Dual-driven steel tube gantry spanning 78 in with 8 in (203 mm) of clearance
- Room to run two smaller sheets side by side in one program
- Rapid traverse and repeatability are listed the same as on the SideKick 4
- Oxy-fuel attachments are offered for plate beyond plasma range
Limitations
- 105 x 166 in (2,667 x 4,216 mm) footprint, delivered assembled
- Closed-loop motors at 1,500 ipm (38.1 m/min); the ShopMaster Pro 12 has AC servos at 2,500 ipm
- The packaged Powermax45 SYNC is a small cutter for a table sized for 6x12 plate
- No weight or plate load figure in the table
Best For
Frequently Asked Questions
01
The cut area is 78 x 146 in (1,981 x 3,708 mm), which covers a 6x12 plate with margin. The table itself measures 105 x 166 x 67 in (2,667 x 4,216 x 1,702 mm).
02
The ShopMaster Pro 12 cuts 74 x 146 in, uses AC digital servo motors, lists a 2,500 ipm rapid traverse, includes a 24 in water table with an air bladder and has a cutting capacity of up to 6 in. The SideKick 12 has the wider 78 in table, 1,500 ipm and a capacity of up to 2 in.
03
The Well Equipped package names a Hypertherm Powermax45 SYNC. ShopSabre lists cutter options from Thermal Dynamics and Hypertherm, and for a table this size most buyers will look at a larger power source. Oxy-fuel is recommended for material over 1 in (25 mm).
04
No. ShopSabre states that the SideKick ships fully assembled with no setup required. The consequence is a single piece 105 in (2,667 mm) wide and 166 in (4,216 mm) long to unload and move into position.
