Nakamura-Tome NTY3-100V

Est. $400,000 - $600,000 Specs verified 2026-10-03 · nakamura-tome.com Updated 2026-10-03

Image: nakamura-tome.com, Nakamura-Tome

Key Specifications

Max Spindle

6,000 rpm (Ø65 mm option, L only: 5,000 rpm)

Tool Capacity

Up to 72 stations

Spindle Power

11 / 7.5 kW (Ø51 mm option: 11 / 7.5 kW , 15 / 11 kW(optional))

Max Turn Length

588 mm (23.1 in)

turret configuration

3 turrets with Y-axis

y axis

All 3 turrets

How much does the Nakamura-Tome NTY3-100V cost?

Estimated price range

Est.$400,000 - $600,000

Our best estimate for a mill-turn / multi-tasking machine in this class — not a quote from Nakamura-Tome. Configuration moves it a long way.

Overview

The Nakamura-Tome NTY3-100V is a three-turret turning center in which all 3 turrets carry a Y-axis, giving up to 72 stations on a machine sized for a 6 in chuck. It turns up to 200 mm (7.9 in) in diameter and 588 mm (23.1 in) in length, and its spindle runs to 6,000 rpm on 11 / 7.5 kW. ChronoCut is listed as standard.

Three Y-axis turrets are the whole point of this machine. With three tool carriers able to reach off-centre features, a small, feature-dense part has Y-axis tools available on all three turrets, and with 72 stations a part needing dozens of tools can be run without swapping holders between jobs. The trade is size: the envelope and spindle are those of a small machine, so the extra turrets pay off in tool count and Y-axis reach rather than in part size.

Standard bar capacity is 42 mm (1.7 in). The Ø51 mm option takes 51 mm (2 in) bar and can be paired with a 15 / 11 kW motor in place of 11 / 7.5 kW. The Ø65 mm option, L spindle only, passes 65 mm (2.6 in) bar with top speed reduced to 5,000 rpm.

The frame measures 3,864.2 × 2,245.7 × 2,255.3 mm (W × D × H). The WY-100V is listed with the same 200 mm (7.9 in) by 588 mm (23.1 in) envelope and 6,000 rpm spindle, on a 3,849.1 mm wide frame, but its table names no third turret. For bigger parts with the same three-turret idea, the NTY3-150V is listed at Ø225 mm (8.9 in) of turning diameter, 685 mm (27 in) of length and 15 / 11 kW.

Full Specifications

Parameter	Value
Turret Configuration	3 turrets with Y-axis
Tool Capacity	Up to 72 stations
Y Axis	All 3 turrets
Chronocut	Standard
Chuck Size	6 in
Turret Stations	72
Max Turning Diameter	200 mm (7.9 in)
Max Turning Length	588 mm (23.1 in)
Max Bar Capacity	42 mm (1.7 in) (Ø51 mm option: 51 mm (2 in); Ø65 mm option, L only: 65 mm (2.6 in))
Max Spindle Speed	6,000 rpm (Ø65 mm option, L only: 5,000 rpm)
Spindle Motor Power	11 / 7.5 kW (Ø51 mm option: 11 / 7.5 kW , 15 / 11 kW(optional))
Floor Space Required	3,864.2 × 2,245.7 × 2,255.3 mm (W × D × H)

Specifications sourced from nakamura-tome.com — verified 2026-10-03

Strengths & Limitations

Strengths

Three turrets, all with Y-axis, for off-centre work from three tool carriers
Up to 72 stations, enough to keep many jobs tooled at once
ChronoCut listed as standard equipment
6,000 rpm spindle suited to small diameters
Bar capacity can be raised to 51 mm (2 in), or 65 mm (2.6 in) on the L spindle

Limitations

Standard bar capacity is only 42 mm (1.7 in)
Turning diameter is limited to 200 mm (7.9 in) on a 6 in chuck
11 / 7.5 kW standard power limits heavy cuts; 15 / 11 kW needs the Ø51 mm option
The Ø65 mm option is L spindle only and lowers top speed to 5,000 rpm

Best For

Small bar parts with many off-centre holes and flats Off-centre drilling and milling from three Y-axis turrets High-mix work that keeps up to 72 tools loaded Bar parts up to 42 mm (1.7 in), or 65 mm (2.6 in) with the option

Frequently Asked Questions

01 How many turrets have a Y-axis on the NTY3-100V?

All 3. The table lists three turrets with Y-axis and up to 72 stations in total. That lets off-centre holes, flats and slots be cut from any of the three, which matters on parts with many such features.

02 How does the NTY3-100V compare with the NTY3-150V?

The NTY3-150V is the larger machine, listed at Ø225 mm (8.9 in) of turning diameter and 685 mm (27 in) of length, with 15 / 11 kW and up to 72 stations. The NTY3-100V turns 200 mm (7.9 in) and 588 mm (23.1 in) on 11 / 7.5 kW with a 6 in chuck.

03 What bar options does the NTY3-100V have?

42 mm (1.7 in) is standard at 6,000 rpm. The Ø51 mm option gives 51 mm (2 in) bar, with 15 / 11 kW available. The Ø65 mm option, L spindle only, gives 65 mm (2.6 in) bar at 5,000 rpm.

04 How much floor space does the NTY3-100V need?

It measures 3,864.2 × 2,245.7 × 2,255.3 mm (W × D × H). Add room for a bar feeder behind the spindle and access to all three turrets for tool setting.
