Nakamura-Tome Mill-Turn / Multi-Tasking Machines

Nakamura-Tome NTX 1000

Est. $350,000 - $600,000 Updated 2026-10-03

Key Specifications

Tool Capacity

24 (standard), up to 120

Max Turn Length

1,100 mm (43.3 in)

max turning diameter

390 mm (15.4 in)

swing over slide

440 mm (17.3 in)

l spindle bar capacity

90 mm (3.5 in)

l spindle chuck size

10 inch

How much does the Nakamura-Tome NTX 1000 cost?

Estimated price range

Est.$350,000 - $600,000

Our best estimate for a mill-turn / multi-tasking machine in this class — not a quote from Nakamura-Tome. Configuration moves it a long way.

Overview

The Nakamura-Tome NTX 1000 is listed as a twin-spindle B-axis turn-mill center with a 390 mm (15.4 in) turning diameter, 1,100 mm (43.3 in) of turning length and 440 mm (17.3 in) of swing over the slide. The L spindle takes 90 mm (3.5 in) bar and a 10 inch chuck; the R spindle takes 65 mm bar and an 8 inch chuck. Both are built-in motors rated 22 kW / 18.5 kW. This model does not appear on Nakamura-Tome's current product pages, so check every listed figure on the machine itself.

The B-axis tool spindle swivels ±115° (230° total) and runs to 8,000 RPM as standard or 12,000 RPM as an option, rated 18.5 kW (24.8 hp) / 11 kW. Y-axis stroke is 160 mm (6.3 in). Tool capacity is 24 as standard and up to 120, with a 1.5 seconds tool-to-tool change, and a lower turret adds driven tools rated 5.5 kW / 3.7 kW.

The listed distance between centers is 978 mm (38.5 in), shorter than the 1,100 mm (43.3 in) turning length, so ask how each figure is measured before quoting a long shaft. With equal 22 kW / 18.5 kW on both spindles and 90 mm (3.5 in) bar on the L side, the listed figures describe a machine for heavy bar and chucked parts machined complete on both ends.

Full Specifications

Parameter	Value
Max Turning Diameter	390 mm (15.4 in)
Max Turning Length	1,100 mm (43.3 in)
Swing Over Slide	440 mm (17.3 in)
L Spindle Bar Capacity	90 mm (3.5 in)
L Spindle Chuck Size	10 inch
R Spindle Bar Capacity	65 mm (2.5 in)
R Spindle Chuck Size	8 inch
L Spindle Motor	22 kW / 18.5 kW (built-in)
R Spindle Motor	22 kW / 18.5 kW (built-in)
B Axis Range	±115° (230° total)
B Axis Tool Spindle Speed	8,000 RPM (standard) / 12,000 RPM (option)
B Axis Tool Spindle Power	18.5 kW (24.8 hp) / 11 kW
Y Axis Stroke	160 mm (6.3 in)
Tool Capacity	24 (standard), up to 120
Tool Change Time	1.5 seconds (tool-to-tool)
Lower Turret Driven Tool Power	5.5 kW / 3.7 kW
Distance Between Centers	978 mm (38.5 in)
CNC Control	Nakamura-Tome NTIS (FANUC 31i-B based)

Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.

Strengths & Limitations

Strengths

Both spindles rated 22 kW / 18.5 kW, so the second operation is as strong as the first
90 mm (3.5 in) bar capacity on the L spindle with a 10 inch chuck
B-axis tool spindle swivelling ±115° (230° total), rated 18.5 kW (24.8 hp) / 11 kW
Tool capacity from 24 up to 120, with a 1.5 seconds tool-to-tool change
160 mm (6.3 in) of Y-axis stroke

Limitations

Tool spindle runs to 8,000 RPM as standard; 12,000 RPM is an option
R spindle takes 65 mm bar against 90 mm (3.5 in) on the L spindle
Distance between centers of 978 mm (38.5 in) is shorter than the listed turning length, which needs explaining
Not on Nakamura-Tome's current product pages; the listed figures need checking on the machine

Best For

Heavy bar work up to 90 mm (3.5 in) finished on both ends Parts up to 390 mm (15.4 in) in diameter with angled features High-mix work with a magazine of up to 120 tools

Frequently Asked Questions

01 What size parts fit the NTX 1000?

The listed figures give 390 mm (15.4 in) of turning diameter, 440 mm (17.3 in) of swing over the slide and 1,100 mm (43.3 in) of turning length. Distance between centers is listed separately as 978 mm (38.5 in), so confirm which figure limits a long shaft held between centers.

02 What are the NTX 1000 spindle ratings?

Both the L and R spindles are listed as built-in motors rated 22 kW / 18.5 kW. The L spindle takes 90 mm (3.5 in) bar with a 10 inch chuck; the R spindle takes 65 mm bar with an 8 inch chuck.

03 What does the NTX 1000 B-axis tool spindle offer?

It swivels ±115° (230° total), runs to 8,000 RPM as standard or 12,000 RPM as an option, and is rated 18.5 kW (24.8 hp) / 11 kW. Y-axis stroke is 160 mm (6.3 in) and the tool change is 1.5 seconds tool-to-tool.

04 How many tools does the NTX 1000 carry?

24 as standard and up to 120 in the magazine, plus a lower turret with driven tools rated 5.5 kW / 3.7 kW. Check how many tools the machine you are offered actually has, because this model is not on Nakamura-Tome's current product pages.
