GF Machining AgieCharmilles CUT S 600

$200,000 - $320,000 Updated 2026-03-19

Key Specifications

X Travel

605 mm (23.8 in)

Y Travel

405 mm (15.9 in)

Z Travel

356 mm (14.0 in)

travel u

700 mm (27.6 in)

travel v

450 mm (17.7 in)

max workpiece weight

1,500 kg (3,307 lb)

Overview

The GF Machining Solutions AgieCharmilles CUT S 600 is the mid-range model in the CUT S performance series, stepping up from the CUT S 400 with significantly larger X/Y/Z travels of 605 x 405 x 356 mm and U/V travel of 700 x 450 mm. The increased Z travel of 356 mm (vs 256 mm on the 400) is particularly significant — enabling taller workpieces and deeper cuts that are common in large progressive die sections and thick mold plates.

The CUT S 600 supports wire diameters from 0.05 to 0.30 mm with the same Ra 0.08 micrometers surface finish capability as the entire CUT S family. Maximum workpiece weight capacity of 1,500 kg handles the heaviest die blocks and mold bases encountered in production die and mold shops. Taper capability of +/-30 degrees over 356 mm height, with optional 45-degree capacity, covers virtually all stamping die clearance and extrusion die taper requirements.

The UNIQUA HMI provides modern touchscreen control with integrated technology databases, automatic parameter selection, and collision protection. The 605 mm X travel opens the machine to larger progressive die sections, automotive body panel tooling, and medium-format aerospace structural components that cannot fit in the CUT S 400 envelope.

With machine dimensions of 2,200 x 3,500 x 2,490 mm, the CUT S 600 occupies a moderate production footprint while delivering the work envelope of a large-format wire EDM. This positions it as the workhorse of the CUT S family for shops handling a mix of medium and large workpieces.

Full Specifications

Parameter	Value
X-Axis Travel	605 mm (23.8 in)
Y-Axis Travel	405 mm (15.9 in)
Z-Axis Travel	356 mm (14.0 in)
Travel U	700 mm (27.6 in)
Travel V	450 mm (17.7 in)
Max Workpiece Weight	1,500 kg (3,307 lb)
Wire Diameter Standard	0.20 or 0.25 mm
Wire Diameter Range	0.05 - 0.30 mm (optional)
Surface Finish	Ra 0.08 µm (best)
Max Taper Angle	+/-30 deg / 356 mm (45 deg optional)
CNC Control	UNIQUA HMI
Machine Dimensions	2,200 x 3,500 x 2,490 mm
Dielectric	Deionized water
Main Specifications	CUT S 400
Dimensions	2060 x 2920 x 2345 mm81.1 x 114.96 x 92.33 in
Part Dimensions	800 x 600 x 250 mm31.5 x 23.62 x 9.84 in
Max Part Weight	1000 Kg2204 lbs
Axes Travel Xyz	405 x 315 x 256 mm15.94 x 12.4 x 10.07 in
Uv Travel	500 x 350 mm19.68 x 13.78 in
Taper Angle Height	± 30/256 mm (45° optional)± 30/10.07 in (45° optional)
Wire Guide	Ø0.20 or 0.25 mm0.008 or 0.0100 in
Wire Guides	Ø0.05 - 0.3 mm0.002 - 0.012 in
Best Ra	0.08 µm

Specifications sourced from gfms.com — verified 2026-03-28

Strengths & Limitations

Strengths

605 x 405 mm X/Y travel handles large progressive die sections and thick mold plates
356 mm Z travel enables taller workpieces and deeper cuts than the CUT S 400 (256 mm Z)
1,500 kg workpiece weight capacity accommodates the heaviest production die blocks
Ra 0.08 micrometers surface finish with multi-pass skim cut technology
Ultra-fine 0.05 mm wire capability for micro-detail features on large workpieces
UNIQUA HMI with integrated collision protection and technology databases

Limitations

Larger footprint (2,200 x 3,500 mm) requires more floor space than the CUT S 400
At $200K-$320K, significant step up from the CUT S 400 for the additional envelope
Lacks the CUT X series AI-driven discharge optimization
1,500 kg rated capacity may still be limiting for the largest stamping die blocks

Best For

Progressive die shops cutting large multi-station die sections and automotive stamping tooling Mold shops working with thick mold plates requiring 356 mm Z travel capacity Production wire EDM departments handling a mix of medium and large workpieces Shops needing large taper angles (+/-30 or 45 deg) on taller workpieces Facilities requiring 1,500 kg workpiece capacity for heavy die blocks

Frequently Asked Questions

01 How does the CUT S 600 compare to the CUT S 400?

The CUT S 600 has 49% more X travel (605 vs 405 mm), 29% more Y travel (405 vs 315 mm), 39% more Z travel (356 vs 256 mm), and 50% more workpiece weight capacity (1,500 vs 1,000 kg). Both share the same wire diameter range, surface finish capability, UNIQUA control, and taper specifications. Choose the 600 when workpiece size or weight exceeds the 400's capacity.

02 Why is the increased Z travel significant?

The CUT S 600's 356 mm Z travel (vs 256 mm on the 400) enables cutting taller workpieces and making deeper cuts — critical for thick progressive die sections, tall mold inserts, and heavy steel blocks. The 100 mm additional Z often determines whether a part can be cut in a single setup.

03 Can the CUT S 600 handle automotive stamping dies?

Yes. The 605 x 405 mm X/Y travel, 356 mm Z travel, 1,500 kg capacity, and +/-30 deg taper (45 deg optional) cover most automotive stamping die wire EDM requirements — die section profiles, clearance angles, and insert pockets.

04 What surface finish quality can the CUT S 600 achieve?

Ra 0.08 micrometers best surface finish with multi-pass skim cuts — identical to all CUT S family members. The larger work envelope does not compromise finish capability.
