FANUC Robodrill D74C
Image: fanuc.co.jp, FANUC
Key Specifications
X Travel
Y Travel
Z Travel
Max Spindle
Tool Capacity
control
How much does the FANUC Robodrill D74C cost?
Estimated price range
Our best estimate for a vertical machining centers (vmc) in this class — not a quote from FANUC. Configuration moves it a long way.
Overview
With 700 mm of X travel over 400 mm of Y, the FANUC Robodrill D74C is the long-bed shape of vertical machining center: the working area is 75% wider than it is deep. Z is selectable at 400 mm or 330 mm and the control is the Series 31i-B Plus.
That proportion suits long, narrow parts and rows of small ones. A bar, rail or extrusion can lie along X, or several vises can stand side by side, but nothing deeper than the 400 mm of Y can be covered in one setup. Where depth matters more, the Robodrill α-D14LiBADV Plus Y500 is listed with 500 mm of Y on the same 700 mm of X.
The magazine and spindle are open choices. FANUC lists a servo driven turret for 14, 21 or 28 tools and a spindle driven turret for 14 or 21. Spindles are grouped by top speed: 10000 min-1 (Basic, High-torque), 12000 min-1 (High-acceleration, Tapping) and 24000 min-1 (High-speed). On a 700 mm bed carrying several fixtures, the 28-tool turret is the one that lets different parts share a setup without reloading tools.
Full Specifications
| Parameter | Value |
|---|---|
| X-Axis Travel | 700 mm |
| Y-Axis Travel | 400 mm |
| Z-Axis Travel | 400 / 330 mm (selectable) |
| Tool Capacity | Servo driven turret: 14 / 21 / 28; Spindle driven turret: 14 / 21 |
| CNC Control | Series 31i-B Plus |
| Max Spindle Speed | Basic / High-torque: 10000 min-1; High-acceleration / Tapping: 12000 min-1; High-speed: 24000 min-1 |
Specifications sourced from fanuc.co.jp — verified 2026-10-03
Strengths & Limitations
Strengths
- 700 mm of X travel, 75% more than the 400 mm of Y, for long parts or several fixtures in a row
- Up to 28 tools on the servo driven turret, enough to keep tooling for more than one part loaded
- Z can be specified at 400 mm or 330 mm
- Spindle options reach 24000 min-1 (High-speed) or stay at 10000 min-1 with the High-torque type
Limitations
- Y travel is 400 mm; the 500 mm Y is listed on the Robodrill α-D14LiBADV Plus Y500, not on this model
- The spindle driven turret is limited to 14 or 21 tools
- No table load is listed for the D74C, which matters on a long bed that invites multiple vises; confirm it before planning fixtures
Best For
Frequently Asked Questions
01
X travel is 700 mm and Y travel is 400 mm. Z is selectable at 400 mm or 330 mm. The envelope is long, not deep, so it favours parts laid along X or several small fixtures set side by side.
02
Yes. The Robodrill α-D14LiBADV Plus Y500 is listed with 700 mm of X, 500 mm of Y and 400 mm of Z, against the 400 mm of Y on the D74C. Both are listed with the Series 31i-B Plus control family.
03
Pick by the tools you run. FANUC lists Basic and High-torque spindles at 10000 min-1, High-acceleration and Tapping spindles at 12000 min-1 and a High-speed spindle at 24000 min-1. Small cutters in aluminium want the top speed; larger drills and face mills point to the High-torque type.
