DMG Mori Vertical Machining Centers (VMC)

DMG Mori DMF 360 Linear

$700,000 – $1,100,000 Updated 2026-03-17

Key Specifications

X axis travel mm

3600

Y axis travel mm

1000

Z axis travel mm

800

table size mm

3600 × 1000

max table load kg

5000

spindle speed rpm

15000

Overview

The DMG Mori DMF 360 Linear is a high-performance gantry-style vertical machining center engineered for the productive machining of large, complex workpieces. Its traveling-column design and linear drive technology deliver exceptional dynamic performance, combining rapid traverse rates with outstanding positioning accuracy across an extended X-axis travel of 3,600 mm.

Linear motor drives on all primary axes eliminate mechanical transmission components such as ballscrews, reducing maintenance requirements and providing direct force transmission for superior contouring accuracy. The result is a machine well-suited to aerospace structural components, large mold and die work, and energy-sector parts that demand both volumetric precision and high material removal rates.

The DMF 360 Linear accommodates workpieces up to 3,600 × 1,000 mm on the table, with a generous load capacity that supports heavy castings and billets. Spindle options include high-torque motor spindles and optional right-angle heads, enabling five-sided machining of large prismatic parts in a single setup without repositioning.

Integration with DMG Mori's CELOS control ecosystem — running on a Siemens or Heidenhain controller — provides operators with a modern, app-based HMI for process monitoring, tool management, and machine diagnostics. The DMF 360 Linear is a proven choice for job shops and tier-1 suppliers requiring flexible, large-format vertical machining capability.

Full Specifications

Parameter	Value
X Axis Travel Mm	3600
Y Axis Travel Mm	1000
Z Axis Travel Mm	800
Table Size Mm	3600 × 1000
Max Table Load Kg	5000
Spindle Speed Rpm	15000
Spindle Power KW	35
Spindle Torque Nm	255
Rapid Traverse M Min	80
Tool Storage Capacity	60
Max Tool Diameter Mm	125
Max Tool Length Mm	400
Max Tool Weight Kg	8
Positioning Accuracy Mm	0.006
Repeatability Mm	0.004
Drive Type	Linear motors (X/Y/Z)
CNC Control	Siemens 840D sl / Heidenhain TNC 640
Machine Weight Kg	35000
41 In	1,050 mm
43 In	1,100 mm
42 In	1,070 mm
39 In	1,000 mm
2205 Lbs	1,000 kg

Specifications sourced from si.dmgmori.com — verified 2026-03-28

Strengths & Limitations

Strengths

Linear motor drives deliver high rapid traverse speeds with exceptional contouring accuracy
3,600 mm X-axis travel accommodates very large aerospace and energy-sector workpieces
Traveling-column design provides excellent table accessibility for loading heavy parts
CELOS control interface with comprehensive process monitoring and diagnostics

Limitations

High acquisition cost limits accessibility for smaller job shops
Large footprint requires substantial floor space and foundation preparation
Linear drive system requires specialized maintenance knowledge

Best For

Aerospace structural components and fuselage frames Large mold and die machining in automotive and heavy industry Energy sector components such as turbine housings and large valve bodies

Frequently Asked Questions

01 What is the maximum workpiece size the DMF 360 Linear can accommodate?

The DMF 360 Linear offers 3,600 mm of X-axis travel and 1,000 mm of Y-axis travel, with a table load capacity of up to 5,000 kg, enabling machining of very large prismatic components in a single setup.

02 Does the DMF 360 Linear support five-sided machining?

Yes. With optional right-angle milling heads or a rotary/tilt table attachment, the DMF 360 Linear can perform five-sided machining of large workpieces, reducing setups and improving geometric consistency.

03 What control system does the DMF 360 Linear use?

The machine is available with either a Siemens 840D sl or a Heidenhain TNC 640 control, both integrated with DMG Mori's CELOS app-based operator interface for process management and monitoring.
