Citizen Miyano ABX-64SYY2
This model was not found in Citizen Machinery's current lineup when we checked on 2026-10-02 (lineup page). It may be a superseded or older model; the specifications below are as we last recorded them.
Image: citizenmachinery.co.uk, Citizen Machinery
Key Specifications
Max Spindle
Tool Capacity
Spindle Power
max bar capacity
max work length
sub spindle speed
How much does the Citizen Miyano ABX-64SYY2 cost?
Estimated price range
Our best estimate for a cnc lathes / turning center in this class — not a quote from Citizen Machinery. Configuration moves it a long way.
Overview
The Citizen Miyano ABX-64SYY2 is the large-bar, two-turret version of Citizen's ABX twin-spindle turning centres: 64 mm (2.52 in) bar capacity through a 65.5 mm (2.58 in) spindle bore, a 4,000 rpm main spindle on 15/11 kW, a 5,000 rpm sub-spindle on 7.5/5.5 kW and a tool capacity of 24. It is not in Citizen's current lineup, so it will usually be found as a used machine.
The bar size is the reason to choose it. The Miyano ABX-51SYY2 on the same frame takes 51 mm (2.01 in) bar through a 52 mm (2.05 in) bore and runs its main spindle to 5,000 rpm, so the 64 version gives up top speed for larger stock. For parts between those two bar sizes, that is the difference between running from bar and sawing blanks. The maximum machining length is 118 mm (4.65 in).
Both turrets carry driven tools, rated at 6,000 rpm and 40 Nm maximum on an AC 4.5 kW revolving tool motor, and the rapids are 16 m/min on X, 30 m/min on Z and 12 m/min on Y. Turning tools have 20 mm square shanks and boring holders fit 25 mm or 40 mm holes; the turret indexes in 0.25 sec per position. Drilling is listed to 20 and tapping to M14x2.
The Miyano ABX-64THY2 adds a third turret and takes 36 tools at 11,350 kg (25,022 lb). This two-turret machine weighs 10,900 kg (24,030 lb) on a 3,290 × 2,204 mm (130 × 86.8 in) footprint, carries 400 L of coolant and runs a FANUC 31i-B control. Plan the foundation and rigging for that weight before anything else.
Full Specifications
| Parameter | Value |
|---|---|
| Max Bar Capacity | 64 mm (2.52 in) |
| Max Work Length | 118 mm (4.65 in) |
| Sub Spindle Speed | 5,000 rpm |
| Sub Spindle Power | AC 7.5 / 5.5 kW |
| Number of Turrets | 3 |
| Turret Stations | 2 |
| Max Live Tools | 24 |
| Live Tool Speed | 6,000 rpm |
| Live Tool Torque | 40 Nm max |
| Rapid Traverse X | 16 m/min |
| Rapid Traverse Z | 30 m/min |
| Rapid Traverse Y | 12 m/min |
| CNC Control | FANUC 31i-B |
| Max Work Length Sp1 | 125 mm |
| Max Work Length Sp2 | 125 mm |
| Max Bar Diameter Sp1 | 51 mm |
| Max Bar Diameter Sp2 | 51 mm |
| Max Power Chuck Diameter Sp1 | 165 mm |
| Max Power Chuck Diameter Sp2 | 165 mm |
| Inner Dia of Draw Tube Sp1 | 52 mm |
| Inner Dia of Draw Tube Sp2 | â 52 mm |
| Chucking System Sp1 Sp2 | Hydraulic cylinder |
| Collet Chuck Type Sp1 | H-S22/177E |
| Collet Chuck Type Sp2 | H-S22 / DIN177E |
| Tool Shank Size | 20 mm Sq. |
| ID Tool Hole Size | 25 mm / 40 mm Dia. |
| Index Time | 0.25 SEC / 1 POS |
| Revolving Tools Max | 36 |
| Drilling Tapping Capacity | Max â 20 / Max M14x2 |
| Hd1 Hd2 | 16 / 20 / 12 |
| Hd3 | 16 / 20 / 12 |
| Sp2 Zs | 30 m / min |
| Spindle Motor Sp1 | AC 15 / 11 kW |
| Spindle Motor Sp2 | AC 7.5 / 5.5 kW |
| Revolving Tool Motor | AC 4.5 kW |
| Coolant Tank Capacity | 400 L |
| Hydraulic Lube Tank | 10 L / 4 L |
| Machine Weight | 10,900 kg (24,030 lb) |
| Power Capacity Fuse | 49 KVA / 150A |
| Max Machining Length | 118 mm (4.65 in) |
| Bar Capacity | 64 mm (2.52 in) |
| Max Spindle Speed | 4,000 rpm |
| Spindle Bore | 65.5 mm (2.58 in) |
| Tool Capacity | 24 |
| Spindle Motor Power | AC 15 / 11 kW |
| Live Tool Power | AC 4.5 kW |
| Coolant Capacity | 400 L |
| Floor Space Required | 3,290 × 2,204 mm (130 × 86.8 in) |
| Power Consumption | 48 KVA / 150A |
Specifications sourced from marucit.com — verified 2026-09-24
Strengths & Limitations
Strengths
- 64 mm (2.52 in) bar capacity through a 65.5 mm (2.58 in) spindle bore
- Main spindle 15/11 kW and sub-spindle 7.5/5.5 kW, so both ends of a part can be machined in one cycle
- Driven tools rated at 6,000 rpm and 40 Nm maximum on an AC 4.5 kW motor
- Tool capacity of 24 across two turrets, with 0.25 sec indexing per position
- 30 m/min Z rapid traverse, against 20 m/min on the three-turret Miyano ABX-64THY2
Limitations
- Main spindle tops out at 4,000 rpm, below the 5,000 rpm of the Miyano ABX-51SYY2, which limits surface speed on small diameters
- Maximum machining length is 118 mm (4.65 in), so longer shafts are outside its range
- At 10,900 kg (24,030 lb) it needs a substantial floor and rigging plan
- Two turrets and 24 tools, against 36 tools on the Miyano ABX-64THY2, for parts with long tool lists
Best For
Frequently Asked Questions
01
Bar size and spindle speed. The Miyano ABX-51SYY2 takes 51 mm (2.01 in) bar through a 52 mm (2.05 in) bore with a 5,000 rpm main spindle. The Miyano ABX-64SYY2 takes 64 mm (2.52 in) bar through a 65.5 mm (2.58 in) bore, with a 4,000 rpm main spindle.
02
The Miyano ABX-64THY2 has a third turret, a tool capacity of 36 and a 20 m/min Z rapid, and weighs 11,350 kg (25,022 lb). The Miyano ABX-64SYY2 has two turrets, 24 tools, a 30 m/min Z rapid and weighs 10,900 kg (24,030 lb).
03
Revolving tools run to 6,000 rpm with 40 Nm maximum torque, driven by an AC 4.5 kW motor. Y travel is available for off-centre work, with a 12 m/min Y rapid. Drilling is listed to 20 and tapping to M14x2.
04
It is not in Citizen's current lineup. A used machine should be checked against its own documentation, especially the bar capacity, the tool configuration on each turret and the control, which is listed as FANUC 31i-B.
05
A footprint of 3,290 × 2,204 mm (130 × 86.8 in) and a floor for 10,900 kg (24,030 lb). The coolant tank holds 400 L and the hydraulic and lubrication tanks hold 10 L and 4 L.
